Артикул
Название
Примечание
Количество
A7668
WHEEL
- steering (Before tractor #6120001)
1шт.
A8248
PLATE - name (Power Steering) (Before tractor #6120001)
1шт.
A8744
NUT
- steering wheel to shaft (Before tractor #6120001)
1шт.
A8835
SHAFT - upper, includes yokes (Before tractor #6120001)
1шт.
A20449
EMBLEM CASE/IH
MEDALLION - steering wheel (Tractor #6120001 and after)
1шт.
A20456
WHEEL (STEERING)
WHEEL - steering (Tractor #6120001 and after)
1шт.
3/4" N.F. hex. jam nut
1шт.
A20475
CAP
MEDALLION - steering wheel, power steering (Tractor #6120001 and after)
1шт.
A20683
SHAFT - upper, includes yokes (Tractor #6120001 and after)
1шт.
G1075
SUPPORT (Use G13391)
1шт.
G1184
SUPPORT (Use G13391)
1шт.
G1252
BRACKET - rear mounting, steering support
1шт.
3/8" x 2-1/4" N.C. hex. hd. bolt w/lockwasher
2шт.
G1284
SUPPORT - bearing, lower shaft
1шт.
5/8" x 1-1/2" N.C. hex. hd. bolt w/lockwasher
1шт.
G1303
BRACKET - L.H. front, steering support
1шт.
G10741
BUSHING,25.44mm ID x 27mm OD x 34.92mm L
- steering shaft, upper
2шт.
G10742
SEAL
- dust, upper steering shaft
1шт.
G10897
YOKE
- front universal joint
1шт.
G13391
SUPPORT - upper steering shaft (Includes 2 - G10741 bushings)
1шт.
1/4" str. fitting (Lincoln #5013)
2шт.
3/8" x 1-3/4" N.F. hex. hd. bolt w/hex. nut and lockwasher
2шт.
G16781
PIPE - R.H. front support (5-1/8" long)
1шт.
3/8" x 5-1/2" N.C. hex. hd. bolt w/lockwasher and plain washer
1шт.
G16807
PIPE - L.H. front support (3-3/4" long)
1шт.
3/8" x 4-1/4" N.C. hex. hd. bolt w/lockwasher and plain washer
1шт.
G17025
CYLINDER END CAP
BEARING HALF - G45108 shaft
2шт.
G45108
SHAFT - lower, includes yokes and bearing holders
1шт.
5/16" x 1" N.F. hex. hd. bolt w/hex. nut and lockwasher
2шт.
G45109
WASHER
SHAFT - intermediate, includes yokes
1шт.
10984AB
"O" RING - medallion (Tractor #6120001 and after)
1шт.
V20414
WASHER - cork, universal joint (See VTA3227)
12шт.
V20955
X
SNAP RING - universal joint (See VTA3227)
12шт.
VT3397
KEY - Woodruff, steering wheel and universal joint
2шт.
3556N
COLLAR - thrust, upper shaft (only Gen. Purpose w/Power Steering)
1шт.
1/4" x 3/8" N.C. Socket and hd. cup pt. set screw
1шт.
VTA3227
X
KIT - universal joint spider (Includes spider, 4 - bearings, 4 - V20414 washers and 4 - V20953 snap rings)
3шт.
B138-138
ROLL PIN - front universal joint (1/4" x 1-1/2")
1шт.
Выбрано товаров: 38
