Запчасти Case IH 400-SERIES (114B) - GEAR SHIFT PARTS, FOR ALL BUT ORCHARD MODELS (06) - POWER TRAIN
№
Артикул
Название
Примечание
Количество
A7028
BRACKET - gear shifter
1шт.
3/8" x 1-1/4" N.C. hex. bolt w/lockwasher
4шт.
A7030
FRAME
PLATE - gear shifter interlock gate detent (prior to tractor no. 8064880) (see A8653)
1шт.
1/4" x 3/4" N.C. hex. bolt w/lockwasher
2шт.
A7031
BRACKET
PLUNGER - gear shifter interlock gate detent
1шт.
A7032
SPRING
- gear shifter interlock gate detent plunger
1шт.
A7033
SPRING
PIN - gear shifter interlock gate stop
1шт.
A7034
SPARE PART
SHAFT - gear shifter, 1st and 2nd, 5th and 6th speeds
1шт.
A7035
SHAFT - gear shifter, 3rd, 4th, 7th and 8th speeds
1шт.
A7036
X
SHAFT - range gear shifter sliding, front (use A8590 and A8591)
1шт.
A7037
X
SHAFT - range gear shifter sliding, rear (use A8590 and A8591)
1шт.
A7038
SUPPORT
SHAFT - reverse gear shifter sliding
1шт.
A7039
SPRING
FORK - gear shifter, 1st, 2nd, 5th and 6th speeds (prior to tractor no. 8064880) (see A8650)
1шт.
A7041
X
FORK - range gear shifter (use A8449 with 7/16" x 1-1/4" bolt)
1шт.
3/8" x 1-1/4" N.C. hex. bolt w/lockwasher
1шт.
A7043
FORK - reverse gear shifter (prior to tractor no. 8064880) (see A8651)
1шт.
A7044
SET SCREW,3/8" - 16 x 7/8"
SET SCREW - gear shifter fork
3шт.
A7045
SET SCREW - reverse gear shifter fork
1шт.
A7085
WASHER
- for A7957 pivot stud
1шт.
A7593
COVER - top, transmission case, front
1шт.
1/2" x 1-1/2" N.C. hex. bolt w/lockwasher (Diesel tractors)
9шт.
1/2" x 1-1/2" N.C. hex. bolt w/lockwasher (Gasoline tractors)
11шт.
A7594
GASKET
- for A7593 top cover
1шт.
A7595
LEVER - hand, gear shift (prior to tractor no. 8064880) (see A8654)
1шт.
A7596
SOCKET
- gear shift hand lever ball
1шт.
3/8" x 1/2" N.C. hex. bolt
1шт.
A7597
STUD - gear shift hand lever socket
2шт.
3/8" N.F. hex. nut and lockwasher
2шт.
A7598
GASKET
- gear shift hand lever ball socket
1шт.
A7599
PIN - clutch foot pedal stop, in A7593 top cover
1шт.
A7923
SEAT
- gear shift lever socket ring
1шт.
A7943
PLATE - gear shift indicator (3-1/16" x 4-9/16") (see A8315)
1шт.
No. 10 - 24 x 3/8" N.C. truss head mach. screw (zinc plated)
2шт.
No. 10 N.C. mach. screw hex. nut (zinc plated)
2шт.
No. 10 shakeproof ext. - int. tooth lockwasher #4010-14-00 (zinc plated)
2шт.
A7957
STUD - pivot, gear shift indicator
1шт.
3/8" N.C. hex. jam nut and lockwasher
1шт.
A7962
SPRING - torsion, gear shift indicator
1шт.
A8314
SUPPORT - gear shift indicator
1шт.
A8315
PLATE
- gear shift indicator (3-1/16" x 4") (see A7943)
1шт.
No. 10-24 x 3/8" N.C. truss hd. mach. screw (zinc plated)
2шт.
No. 10 ext. - int. tooth shakeproof lockwasher #4010-14-00
2шт.
No. 10 - 24 Elastic stop nut N.C. thrd.
2шт.
A8449
X
FORK - range gear shifter
1шт.
7/16" x 1-1/4" N.F. hex. bolt w/lockwasher
1шт.
A8589
BLOCK - range gear shifter
1шт.
A8590
SHAFT
- range gear shifter sliding, front
1шт.
A8591
SHAFT - range gear shifter sliding, rear
1шт.
A8650
FORK - gear shifter, 1st, 2nd, 5th and 6th speeds (tractor no. 8064880 and after) (see A7039)
1шт.
A8652
GATE - gear shifter interlock
1шт.
A8653
PLATE - gear shifter interlock gate detent (tractor no. 8064880 and after) (see A7030)
1шт.
1/4" x 3/4" N.C. hex. bolt w/lockwasher
2шт.
A8654
LEVER - hand, hear shift (tractor no. 8064880 and after) (see A7595) (for all but orchard models)
1шт.
A8657
FORK - gear shift, 3rd, 4th, 7th and 8th speeds
1шт.
O3145AB
X
SPRING - gear shifter shaft detent ball
4шт.
O3501AB
X
BALL - gear shift lever
1шт.
O4864AB
X
PIN - gear shift lever socket
2шт.
O4866AB
X
SNAP RING - gear shift lever socket
1шт.
O5920AB
X
CAP - gear shift lever socket (rubber)
1шт.
O7210AB
X
BALL - gear shifter detent (1/2" dia.)
4шт.
O9599AB
X
"E" ring - regaining, for A7957 pivot stud
1шт.
O1829FH
X
ROLL PIN - for A8652 gear shift interlock gate (1/2" x 2")
2шт.
O2114FH
X
ROLL PIN - 1 for A7033 gate stop pin and 1 for A7028 gear shifter bracket (1/8" x 1")
2шт.
Выбрано товаров: 66
