Запчасти Case IH 300B-SERIES (026) - SPARK IGNITION ENGINES, MAIN FUEL TANK (03) - FUEL SYSTEM

A7336

CUSHION

BUSHING - rubber, fuel tank support

3шт.

G10690

SUPPORT - front, fuel tank (300B Series)

1шт.

5/16" x 1" NC hex. hd. bolt w/lockwasher

2шт.

G10691

SUPPORT - rear, fuel tank (300B Series)

1шт.

5/16" x 5/8" hex. hd. mach. screw w/Shakeproof lockwasher

2шт.

G10772

GASKET

- fuel tank sender

1шт.

G10945

LINE - fuel, Serial Range: tank-carburetor

1шт.

68F - 5/16" x 1/8" connector, includes 60F - 5/16" sleeve and 61F - 5/16" nut

1шт.

G10994

X

NUT - lock, fuel tank stud

3шт.

G11050

X

CARBURETOR - Marvel-Schebler Model #TSX-635 (300B Series)

1шт.

69F - 5/16" x 1/8" elbow, includes 60F - 5/16" sleeve and 61F - 5/16" nut

1шт.

5/16" x 1" NC hex. hd. bolt w/lockwasher

2шт.

G13087

CABLE PULLING GRIP

CABLE - fuel tank sender to fuel gage

1шт.

G13271

CAP

- fuel tank

1шт.

G13324

SENDER UNIT

SENDER - fuel gage

1шт.

#10-32 x 7/16" rd. hd. self-tapping screw (Sems)

5шт.

G13995

TANK - fuel (300B Series)

1шт.

G14080

TANK - fuel (400B Series)

1шт.

G17028

SUPPORT - front, fuel tank (400B Series)

1шт.

5/16" x 1" NC hex. hd. bolt w/lockwasher

2шт.

G17099

SUPPORT - rear, fuel tank (400B Series)

1шт.

5/16" x 5/8" hex. hd. mach. screw w/Shakeproof lockwasher

2шт.

G45103

CARBURETOR

- Marvel-Schebler Model #TSX-749 (400B Series)

1шт.

69F-5/16" x 1/8" elbow, includes 60F-5/16" sleeve and 61F-5/16" nut

1шт.

3/8" x 1" NC hex. hd. bolt w/lockwasher

2шт.

G45162

CARBURETOR - Zenith Model 62AJ10 (400B Series alternate)

1шт.

G46826

GASKET

- carburetor to manifold (400B Series)

1шт.

526AB

GASKET - carburetor to manifold (300B Series)

1шт.

3990AB1

STRAINER - fuel

1шт.

30577HT

WASHER - fuel tank support

3шт.

A11205

VALVE

- fuel strainer, shutoff, parts for O3990AB1

1шт.

A11208

GASKET

- fuel strainer, parts for O3990AB1

1шт.

A11209

BOWL

- fuel strainer, parts for O3990AB1

1шт.

A11210

ADJUSTER

CUP AND NUT - fuel strainer, parts for O3990AB1

1шт.

A11211

FILTER SCREEN

SCREEN ASSEMBLY - fuel strainer, parts for O3990AB1

1шт.

A11212

BAIL

ASSEMBLY - fuel strainer, parts for O3990AB1

1шт.

A11214

HEAD

- fuel strainer, parts for O3990AB1

1шт.

G11140

X

CARBURETOR (Marvel-Schebler Model #TSX-680), auxiliary fuel tank (low cost fuel)

1шт.

5/16" x 3/4" NC hex. hd. bolt w/lockwasher

2шт.

G13148

ROD - control, three-way value, auxiliary fuel tank (low cost fuel)

1шт.

G13271

CAP

- auxiliary fuel tank (low cost fuel)

1шт.

G14172

PAN - auxiliary fuel tank (low cost fuel)

1шт.

G14173

STRAP - tank hold down, auxiliary fuel tank (low cost fuel)

2шт.

1/4" NC hex. nut and lockwasher

4шт.

G15560

BRACKET - mounting, three-way value, auxiliary fuel tank (low cost fuel)

1шт.

G15561

BRACE - tank, auxiliary fuel tank (low cost fuel)

1шт.

5/16" x 3/4" NF hex. hd. bolt w/hex. nut and lockwasher

1шт.

5/16" x 1-1/4" NC hex. hd. bolt

1шт.

G45106

TANK - auxiliary fuel tank (low cost fuel)

1шт.

G46166

LINE - fuel, main tank to valve, auxiliary fuel tank (low cost fuel)

1шт.

68F-5/16" x 1/8" connector, includes 60F-5/16" sleeve and 61F-5/16" nut

1шт.

G46167

HUB

LINE - fuel, valve to carburetor, auxiliary fuel tank (low cost fuel)

1шт.

69F-5/16" x 1/8" elbow, includes 60F-5/16" sleeve and 61F-5/16" nut

1шт.

G46168

LINE - fuel, prime tank to valve, auxiliary fuel tank (low cost fuel)

1шт.

60F - 5/16" sleeve

1шт.

61F - 5/16" nut

1шт.

68F - 5/16" x 1/8" connector, includes 60F-5/16" sleeve and 61F-5/16" nut

1шт.

VT4071

STRAINER - auxiliary fuel tank (low cost fuel)

1шт.

VTA2773

VALVE - three-way, auxiliary fuel tank (low cost fuel)

1шт.

#6-32 x 5/16" hex. hd. cap screw

1шт.

1/4" x 5/8" rd. hd. mach. screw w/hex. nut and lockwasher

2шт.
