Запчасти Case IH 300B-SERIES (182) - 4025AA BREAK AWAY COUPLING PLUG, G30463 BREAK AWAY SOCKET, G30455 SERVICE KIT FOR COUPLINGS (08) - HYDRAULICS

Схема запчастей Case IH 300B-SERIES - (182) - 4025AA BREAK AWAY COUPLING PLUG, G30463 BREAK AWAY SOCKET, G30455 SERVICE KIT FOR COUPLINGS (08) - HYDRAULICS

Артикул

Название

Примечание

Количество

A9631ASY

SPARE PART

- coupling plug piston

1шт.

A11325

X

RETAINER - for 08372AB seal

1шт.

8372AB

SEAL - coupling piston

1шт.

8375AB

SPRING - coupling piston

1шт.

8381AB

BODY - coupling plug male

1шт.

8386AB

"O" RING - coupling plug piston sleeve

1шт.

8859AB

PISTON - coupling plug

1шт.

4025AA

X

PLUG - break-away, complete (Includes all items above)

2шт.

A11325

X

RETAINER - 08372AB seal, G30463 break-away coupling socket

1шт.

G16517

SPACER

- flow control, G30463 break-away coupling socket

1шт.

G30463

SOCKET - break-away, complete, G30463 coupling socket

1шт.

G48506

SPRING

- coupling socket piston, G30463 break-away

1шт.

6119A

X

PISTON - coupling socket, G30463 break-away

1шт.

8371AB

BODY - female coupling socket, G30463 break-away

1шт.

8372AB

SEAL - female piston, G30463 break-away coupling socket

1шт.

8377AB

"O" RING - coupling socket body, G30463 break-away

1шт.

8378AB

SLEEVE - ball retaining, G30463 break-away coupling socket

1шт.

8379AB

SPRING - retaining sleeve, body ball, G30463 break-away coupling socket

1шт.

8380AB

SNAP RING - sleeve, G30463 break-away coupling socket

1шт.

8635AB

BALL - locking, G30463 break-away coupling socket

8шт.

G30455

SERVICE KIT FOR 4025AA AND G30463 COUPLINGS (includes 1-A49634, 1-A11325, 1-G48506, 1-6119A, 2-08372AB, 1-08375AB, 1-08377AB, 1-08386AB and 1-08859AB)

1шт.

A11161

ADAPTER,7/8" - 18 NPT x 1/2" NPT

PLUG - adapter, to connect "CASE" hydraulic hose with 7/8" - 10 male thread to 1/2" female pipe connection (Has 1/2" male pipe threads on one end and 7/8" - 18 female threads on other end), for break-away couplings

1шт.

9466AB

PLUG - adapter, to connect "CASE" break-away couplings to hydraulic hose lines having 1/2" pipe threads (Has 1/2" female pipe thread on one end and 7/8" - 18 male thread on other end)

1шт.

Выбрано товаров: 23
