Артикул
Название
Примечание
Количество
1
372821R1
O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro
1-1/16 X 1-1/4 X 3/32 -PUMP SUCTION PORT-
1шт.
2
406764R1
PINION
GEAR, HYD PUMP DRIVEN -27T-
1шт.
2
19258R1
LOCK NUT,1/2"-20, GB
1/2-20 ESNA STOP
1шт.
3
406827R91
PUMP
ASSY, HYD GEAR -OPTIONAL W/406763R91-
1шт.
3
84573150R
REMAN-HYD PUMP
574 (1/71-12/77), 2500, Both INTERNATIONAL SERIES-A TRACTOR (EUROPE), S/N 10244 AND UP, ASSY, HYD GEAR, Reman for New PN 406827R91
1шт.
3
84573150C
CORE-HYDRAULIC PUMP
Return Number
1шт.
3
406763R91
PUMP
ASSY, HYD GEAR -OPTIONAL W/406827R91-
1шт.
3
84573150R
REMAN-HYD PUMP
574 (1/71-12/77), 2500, Both INTERNATIONAL SERIES-A TRACTOR (EUROPE), ASSY, HYD GEAR, S/N 10244 AND UP, Reman for New PN 406763R91
1шт.
3
84573150C
CORE-HYDRAULIC PUMP
Return Number
1шт.
3
179829
BOLT,Hex, 5/16" - 18 x 2 3/4", Gr 5
2шт.
3
166270
SCREW,Hex, 5/16" - 18 x 3 1/2"
SCREW 5/16-18 X 3-1/2 HEX HD CAP
2шт.
3
382331R1
SEALING WASHER,8.33mm ID x 12.7mm OD x 0.79mm Thk
PUMP MOUNTING BOLT
4шт.
4
- NOT USED -
1шт.
5
401736R3
GASKET
MULTIPLE CONTROL VALVE HV
1шт.
6
707253R1
O-RING,-222, 70 Duro, 1.484" ID x .139" Thk
1-1/2 X 1-3/4 X 1/8 INLET PORT
1шт.
7
405458R1
PLATE
MULTIPLE CONTROL VALVE
1шт.
8
387926R2
RING
RECTANGULAR
1шт.
9
65000C1
GASKET
MULTIPLE CONTROL VALVE BODY
1шт.
10
369751R1
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1/4 OD tube
1шт.
11
9410356
PLUG
7/16-20 STR THD O-RING BOSS
1шт.
12
66761C1
TUBE ASSY.
DRAFT CONTROL RETURN, 574, Start Serial: 100955
1шт.
12
66761C1
TUBE ASSY.
DRAFT CONTROL RETURN, 2500, Start Serial: 100005
1шт.
12
399997R1
TUBE
ASSY, DRAFT CONTROL RETURN, 574, Serial Range: -100954
1шт.
12
399997R1
TUBE
ASSY, DRAFT CONTROL RETURN, 2500, Serial Range: -100004
1шт.
13
66764C1
PIPE
ASSY, AUXILIARY VALVE PRESSURE, 574, Start Serial: 100955
1шт.
13
66764C1
PIPE
ASSY, AUXILIARY VALVE PRESSURE, 2500, Start Serial: 100005
1шт.
13
530133R1
TUBE
ASSY, AUXILIARY VALVE PRESSURE, 574, Serial Range: -100954
1шт.
13
530133R1
TUBE
ASSY, AUXILIARY VALVE PRESSURE, 2500, Serial Range: -100004
1шт.
14
9410204
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
ELBOW, 7/8-14 C-Z 37 DEG HYD FLARED TUBE SHORT SWIVEL, 574, Start Serial: 100955
2шт.
14
9410204
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
ELBOW, 7/8-14 C-Z 37 DEG HYD FLARED TUBE SHORT SWIVEL, 2500, Start Serial: 100005
2шт.
14
9411106
ELBOW
7/8-14 C-Z 37 DEG HYD FLARED STR THD 45 DEG, 574, Serial Range: -100954
2шт.
14
9411106
ELBOW
7/8-14 C-Z 37 DEG HYD FLARED STR THD 45 DEG, 2500, Serial Range: -100004
2шт.
15
364885R1
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
5/8 OD TUBE
2шт.
16
57714C91
NO LONGER SERVICED
VALVE ASSY, MULTIPLE CONTROL -FOR COMPONENTS, SEE LIST OF PARTS UNDER DETAILS OF MULTIPLE CONTROL VALVE-
1шт.
16
280161
BOLT,Hex, 3/8" - 16 x 3", Gr 5
9шт.
16
186283
BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5
3/8-16 X 3-1/2 HEX HD CAP
1шт.
16
103321
LOCK WASHER,3/8"
10шт.
17
539835R1
TUBE ASSY.
IPTO PRESSURE, 574, Start Serial: 102527
1шт.
17
539835R1
TUBE ASSY.
IPTO PRESSURE, 2500, Start Serial: 100027
1шт.
17
401738R1
TUBE
ASSY, IPTO PRESSURE, 574 -TRACTORS W/IPTO-, Serial Range: -102526
1шт.
17
401738R1
TUBE
ASSY, IPTO PRESSURE, 2500 -TRACTORS W/IPTO-, Serial Range: -100026
1шт.
18
9410200
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
7/16-20 C-Z 37 DEG HYD FLARED TUBE SHORT SWIVEL, 574, Start Serial: 102527
1шт.
18
9410200
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
7/16-20 C-Z 37 DEG HYD FLARED TUBE SHORT SWIVEL, 2500, Start Serial: 100027
1шт.
18
9411102
ELBOW,45 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
UNION, 7/16-20 37 DEG HYD FLARED TUBE SHORT SWIVEL, 574 -TRACTORS W/IPTO-, Serial Range: -102526
1шт.
18
9411102
ELBOW,45 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
UNION, 7/16-20 37 DEG HYD FLARED TUBE SHORT SWIVEL, 2500 -TRACTORS W/IPTO-, Serial Range: -100026
1шт.
19
369751R1
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1/4 OD tube, Tractors with IPTO
1шт.
20
9411115
TEE,7/16"-20, 37 Degree x 7/8"-14, O-Ring Br
7/16-20 C-Z 37 DEG HYD FLARED TUBE -TRACTORS W/IPTO-
1шт.
20
9403369
CAP,37 Degree, 7/16"-20
7/16-20 C-Z 37 DEG HYD FLARED TUBE
1шт.
22
9410977
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
3/4-16 C-Z 37 DEG HYD FLARED TUBE
1шт.
23
529617R3
TUBE
MCV DUMP -HYDROSTATIC DRIVE TRACTORS-
1шт.
24
3116263R1
3 WAY CONNECTION
TEE, MCV DUMP -HYDROSTATIC DRIVE TRACTORS-
1шт.
25
3116263R1
3 WAY CONNECTION
TEE, MCV DUMP
1шт.
26
21433R1
O-RING,0.103" Thk x 0.674" ID, -115, Cl 6, 90 Duro
11/16 X 7/8 X 3/32 -PUMP PRESSURE PORT-
1шт.
28
57577C91
VALVE
CHECK, 574, Start Serial: 100955
1шт.
28
57577C91
VALVE
CHECK, 2500, Start Serial: 100005
1шт.
28
56054C1
VALVE
SPARE PART CHECK, 574, Serial Range: -100954
1шт.
28
56054C1
VALVE
SPARE PART CHECK, 2500, Serial Range: -100004
1шт.
28
529865R1
SEAL
PUMP TO REAR FRAME RIB, NOT ILLUSTRATED
1шт.
28
406763R91
PUMP
ASSY, HYD GEAR, NOT ILLUSTRATED, -CONSISTS OF
1шт.
28
84573150R
REMAN-HYD PUMP
574 (1/71-12/77), 2500, Both INTERNATIONAL SERIES-A TRACTOR (EUROPE), ASSY, HYD GEAR, S/N 10244 AND UP, Reman for New PN 406763R91
1шт.
28
84573150C
CORE-HYDRAULIC PUMP
Return Number
1шт.
28
124546
WOODRUFF KEY,#6, 5/32" x 5/8", HT
Pump shaft, Not Illustrated
1шт.
28
534262R91
PACKAGE
KIT, SEAL PACK, NOT ILLUSTRATED
1шт.
28
372821R1
O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro
SUCTION PORT, NOT ILLUSTRATED
1шт.
28
350667R1
O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro
PRESSURE PORT, NOT ILLUSTRATED
1шт.
28
406827R91
PUMP
ASSY, HYD GEAR, NOT ILLUSTRATED, -CONSISTS OF
1шт.
28
84573150R
REMAN-HYD PUMP
574 (1/71-12/77), 2500, Both INTERNATIONAL SERIES-A TRACTOR (EUROPE), S/N 10244 AND UP, ASSY, HYD GEAR, Reman for New PN 406827R91
1шт.
28
84573150C
CORE-HYDRAULIC PUMP
Return Number
1шт.
28
16007R1
BALL
7/32 DIA, NOT ILLUSTRATED
1шт.
28
124546
WOODRUFF KEY,#6, 5/32" x 5/8", HT
Pump drive gear, Not Illustrated
1шт.
28
373244R91
SEAL
PUMP SHAFT, NOT ILLUSTRATED
1шт.
28
371523R1
SPRING
BALL CHECK, NOT ILLUSTRATED
1шт.
28
67249C91
SEAL KIT
PACKAGE, O-RING AND GASKET SERVICE, NOT ILLUSTRATED, CONSISTS OF :
1шт.
*
PLATE, NOT ILLUSTRATED
1шт.
*
DIAPHGRAM, NOT ILLUSTRATED
1шт.
*
SEAL, NOT ILLUSTRATED
1шт.
*
GASKET BACKUP, NOT ILLUSTRATED
1шт.
*
GASKET PROTECTOR, NOT ILLUSTRATED
1шт.
*
O RING, NOT ILLUSTRATED
1шт.
Выбрано товаров: 82
