Запчасти Case IH 454 (06-06) - RADIATOR AND CONNECTIONS Cooling

Схема запчастей Case IH 454 - (06-06) - RADIATOR AND CONNECTIONS Cooling
8
2
3
5
9
7
4
6
10
12
11
1

Артикул

Название

Примечание

Количество

1

537162R1

FILLING STRIP

GASKET, LOWER RADIATOR

1шт.

2

3113084R3

RADIATOR

ASS, SYNCHROMESH DRIVE TRACTORS

1шт.

2

3113085R3

RADIATOR

ASSY, HYDROSTATIC DRIVE TRACTORS

1шт.

413-716

BOLT,Hex, 7/16" - 14 x 1", Gr 5

7/16-14 X 1 HEX HD

4шт.

103322

LOCK WASHER,7/16"

4шт.

7500032

BUSHING

5/16-18 ZND

1шт.

3

47240D

PAD

RADIATOR

4шт.

23042R1

WASHER

17/32 X 1 X 22 GA

1шт.

4

394788R1

GASKET

GASKET, RADIATOR BAFFLE

2шт.

5

3113083R1

PLUG, DRAIN

454/004692 UP

1шт.

5

531184R1

VALVE

PLUG, DRAIN, UP TO 454/004691

1шт.

6

527474R2

HOUSING

SHROUD, FAN

1шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

4шт.

95-11028

WASHER,1/4"

9/32 X 5/8 X .051

4шт.

7

705935R91

HOSE CLAMP

OPTIONAL, W/39149H

2шт.

7

39149H

HOSE CLAMP

OPTIONAL, W/705935R91

2шт.

8

402189R1

LARGE HOSE,1.50" ID, 2.00" ID x 10.39", SAE 20R2

HOSE,LARGE Outlet

1шт.

9

706082R91

CLAMP

HOSE, OPTIONAL, W/39205H

2шт.

9

39205H

CLAMP

HOSE, OPTIONAL, W/706082R91

2шт.

10

402191R1

HOSE,1.50" ID, 2.00" ID x 8.98", SAE 10R2

Inlet

1шт.

11

532029R1

CAP ASSY.

RADIATOR

1шт.

12

3115522R1

HOSE

PIPE OVERFLOW 29-1/2

1шт.

3113528R1

CLIP

PIPE

2шт.

Выбрано товаров: 23
