Запчасти Case IH 2500 (02-03) - PRODUCT GRAPHICS Accessories & Attachments / Miscellaneous

529467R1

PRODUCT GRAPHIC

INSTRUMENT FACE PANEL

1шт.

529482R2

DECAL

PRODUCT-GRAPHIC, INTERNATIONAL 574 NAME PLATE LH

1шт.

529483R2

DECAL

PRODUCT-GRAPHIC, INTERNATIONAL 574 NAME PLATE RH

1шт.

2752017R1

PRODUCT GRAPHIC

IH TRADEMARK

1шт.

529479R1

PRODUCT GRAPHIC

IH GRILLE EMBLEM

1шт.

445201

SPRING NUT,5/32", Push-on

5/32 MED SPRING

2шт.

537667R1

PRODUCT GRAPHIC

TRANSMISSION CONTROL W/FORWARD AND REVERSE

1шт.

535207R2

PRODUCT GRAPHIC

-INDUSTRIAL MODEL SYMBOL-

2шт.

3136674R2

BLADE

PRODUCT-GRAPHIC

1шт.

533764R92

DECAL KIT

PRODUCT-GRAPHIC, ATTACHMENT -SYNCHROMESH DRIVE TRACTORS-

1шт.

533765R93

DECAL

PRODUCT-GRAPHIC, ATTACHMENT -HYDROSTATIC DRIVE TRACTORS-

1шт.

1080068R1

PRODUCT GRAPHIC

BELT PULLEY SAFETY SHIELD

1шт.

1092850R1

PRODUCT GRAPHIC

-68-

2шт.

1092581R2

TAG

PRODUCT-GRAPHIC, ANTI-FREEZE

1шт.

192413

DRIVE SCREW,U, Rnd Hd, Metallic, #2 x 1/4"

NO 4-1/4 RD HD METALLIC DRIVE, Start Serial: 3108310R1

1шт.

530352R91

GASKET KIT

PACKAGE, HYDROSTATIC TRANSMISSION GASKET SERVICE -CONSISTS OF-

1шт.

400949R1

GASKET

BOTTOM COVER

1шт.

400951R1

GASKET

RELIEF VALVE ACCESS COVER

1шт.

400957R1

GASKET,0.76mm Thk

SERVO ACCESS COVER

1шт.

401019R2

GASKET

TOP COVER

1шт.

401028R1

GASKET

CHARGE PUMP MANIFOLD

1шт.

401033R1

GASKET

SUCTION PIPE ELBOW

1шт.

401056R1

GASKET

MULTIPLE VALVE BODY

1шт.

405193R1

GASKET

ACCESS COVER

1шт.

399814R3

GASKET

CLUTCH HOUSING TO REAR FRAME

1шт.

530372R91

O-RING

HYDROSTATIC TRANSMISSION O-RING SERVICE -CONSISTS OF-

1шт.

21460R1

SPARE PART O-RING, 2 X 2-3/16 X 3/32 -FRONT PTO BEARING COVER-

1шт.

295204R1

O-RING,0.103" Thk x 2.8" ID, -149, Cl 5, 75 Duro

2-3/16 X 3 X 3/32 -MOTOR TRUNNION-

2шт.

297459R1

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

7/8 OD TUBE -REGULATOR VALVE ASSY-

1шт.

343943R1

O-RING,6.234" ID x 0.139" Width

6-1/4 X 6-1/2 X 1/8 -TRANS CHARGE PUMP-

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 X 3/4 X 3/32 -CAM ACTUATING SHAFT-

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

1-5/8 X 1-7/8 X 1/8 -PUMP SUCTION PIPE-

2шт.

368269R1

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

3/4 OD TUBE -PRESSURE CHECK PLUG-

1шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

1/4 OD tube, Pressure check plug, Pressure tube elbow, Reg. valve housing, Pump servo elbow

4шт.

369384R1

O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro

5/16 OD tube, Motor servo tee, Valve shut-off bolt

2шт.

369908R1

O-RING,0.103" Thk x 0.799" ID, -117, Cl 5, 75 Duro

13/16 X 1 X 3/32 -PUMP SERVO TRUNNION-

1шт.

372821R1

O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro

1-1/16 X 1-1/4 X 3/32 -MOTOR SERVO TRUNNION-

1шт.

379181R1

O-RING,0.614" ID x 0.07" Width

5/8 X 3/4 X 1/16 -REG. VALVE ASSY-

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

2-5/16 X 2-1/2 X 3/32 -PUMP TRUNNION-

2шт.

384937R1

O-RING,0.07" Thk x 0.239" ID, -10, Cl 6, 90 Duro

1/4 X 3/8 X 1/16 -PRESSURE CHECK BUSHING- -SHUTTLE BLOCK CONNECTORS-

3шт.

384943R1

O-RING,0.739" ID x 0.07" Width

Charge Pump Seal, Exhaust Pipe Seal, Charge Jumper Tube

6шт.

388591R1

RING

VALVE HOUSING SEALING

1шт.

401017R1

RING

BACK UP

2шт.

539535R91

O-RING KIT

PACKAGE, BRAKE O-RING SERVICE -CONSISTS OF

1шт.

343932R1

O-RING,0.139" Thk x 9.984" ID, -274, Cl 6, 90 Duro

2шт.

21472R1

O-RING,0.139" Thk x 8.234" ID, -267, Cl 6, 90 Duro

2шт.

289506R1

O-RING,0.21" Thk x 7.475" ID, -367, Cl 5, 75 Duro

2шт.

372369R5

FLUID, HY-TRAN-USE AS REQUIRED-

1шт.

3118117R91

FILTER CARTRIDGE

PACKAGE, ELEMENT - CONSISTS -

1шт.

$

ELEMENT, HYDRAULIC OIL FILTER

6шт.

405462R1

GASKET,147.4mm ID x 154.51mm OD x 2.36mm Thk

Oil filter case

6шт.

375271R1

O-RING,0.426" ID x 0.07" Width

FILTER CASE SEAL

6шт.

3044506R93

FILTER, FUEL

ELEMENT

2шт.

3144477R92

FILTER

ELEMENT, FUEL - OPTIONAL -

2шт.

3136046R93

FILTER, ENGINE OIL

FILTER, OIL ASSY, - SPIN-ON

6шт.
