Запчасти Case IH B414 (156[A]) - MISCELLANEOUS EQUIPMENT, PACKAGE ASSORTED GASKETS - CARBURETED ENGINE TRACTORS Miscellaneous Equipment

3047295R91

GASKET

SET, CRANKCASE (CARBURETED ENGINE), INCLUDES: REF. 1 - 18

1шт.

1

3044194R1

GASKET

CARBURETOR GASKET

1шт.

2

708285R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

3

703840R1

GASKET

CRANKCASE PAN GASKET

1шт.

4

709903R1

GASKET

CRANKCASE FRONT PLATE GASKET

1шт.

5

708903R91

HOLDER

CRANKSHAFT REAR OIL SEAL

1шт.

6

708907R1

GASKET

CRANKSHAFT REAR OIL SEAL RETAINER GASKET

1шт.

7

3045854R1

GASKET

CYLINDER HEAD GASKET

1шт.

8

3043370R1

GASKET

FUEL PUMP GASKET

1шт.

9

3061658R1

GASKET

FUEL PUMP GASKET

1шт.

10

3044211R1

GASKET

GOVERNOR HOUSING COVER GASKET

1шт.

11

3044212R1

GASKET

GOVERNOR HOUSING GASKET

1шт.

12

703851R1

GASKET

HYDRAULIC PUMP OPENING COVER GASKET

1шт.

13

3044210R1

GASKET

INTAKE AND EXHAUST MANIFOLD GASKET

2шт.

14

706592R1

GASKET

OIL FILTER BASE GASKET

1шт.

15

3405H

GASKET

OIL PAN DRAIN PLUG GASKET

1шт.

16

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

17

703896R1

GASKET

VALVE COVER GASKET

1шт.

18

703816R1

GASKET

WATER PUMP GASKET

1шт.

3044209R92

GASKET KIT

GASKET SET, VALVE GRINDING (CARBURETED ENGINE), INCLUDES: REF. 19 - 22

1шт.

19

3045854R1

GASKET

CYLINDER HEAD GASKET

1шт.

20

3044210R1

GASKET

INTAKE AND EXHAUST MANIFOLD GASKET

2шт.

21

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

22

703896R1

GASKET

VALVE COVER GASKET

1шт.

385584R91

PACKAGE, HYDRAULIC LIFT O-RING AND GASKET SERVICE, INCLUDES: REF. 23 - 43

1шт.

23

3061055R1

GASKET

AUXILIARY VALVE COVER PLATE

2шт.

24

751499R1

GASKET

HOUSING COVER PLATE

1шт.

25

3044392R1

GASKET

QUADRANT BRACKET

1шт.

26

3044367R1

GASKET

TOP COVER PLATE

1шт.

27

3044437R1

GASKET

VALVE BODY

1шт.

28

3044436R1

O-RING,0.21" Thk x 2.6" ID, -334, Cl 5, 75 Duro

CYLINDER

1шт.

29

704378R1

O-RING,0.139" Thk x 0.85" ID

DEPTH CONTROL

2шт.

30

707747R1

SCRAPER RING

O-RING, FLOW CONTROL VALVE BORE

1шт.

31

704753R1

GASKET,0.103" Thk x 0.674" ID, -115, Cl 6, 90 Duro

O-RING, PRESSURE OUTLET

2шт.

32

704348R1

O-RING,0.139" Thk x 1.687" ID, Cl 5

O-RING, SUCTION FILTER

1шт.

33

361883R1

O-RING

7/32 x 11/32 x 1/16

1шт.

34

706584R1

GASKET

O-RING, 1/4 x 3/8 x 1/16

2шт.

35

708444R1

GASKET,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

O-RING, 5/16 x 7/16 x 1/16

1шт.

36

355966R1

O-RING,0.424" ID x 0.103" Width

7/16 x 5/8 x 3/32

3шт.

37

704219R2

WASHER

O-RING, 9/16 x 3/4 x 3/32

4шт.

38

3045116R1

O-RING,0.103" Thk x 0.469" ID, Cl 6

O-RING, 21/32 OD x 15/32 ID

1шт.

39

254691R1

O-RING,-211, 70 Duro, .796" ID x .139" Thk

13/16 x 1-1/16 x 1/8

2шт.

40

702816R1

WASHER

O-RING, 1-1/4 x 1 x 1/8

1шт.

41

3045118R1

SEAL

WASHER, DOWTY

1шт.

42

751560R1

COPPER WASHER

9/32 x 23/32 x 16 GA

1шт.

43

704337R1

SEALING WASHER

WASHER, 1/2 BSP SEALING

2шт.
