Артикул
Название
Примечание
Количество
1
123032C93
VALVE
ASSY, motor control, refer to close center control valve this group for list of components
1шт.
20063R1
BOLT
3/8 x 5 pln type 8
2шт.
2
113888C93
VALVE
ASSY, aux control, refer to close center control valve this group for list of components
1шт.
20063R1
BOLT
3/8 x 5 pln type 8
2шт.
3
391912R1
O-RING,0.737" ID x 0.103" Width
3/4 x 15/16 x 3/32
8шт.
4
702788R1
O-RING,0.103" Thk x 0.362" ID, -110, Cl 6, 90 Duro
3/8 x 9/16 x 3/32
4шт.
5
139013C1
LINK
valve operating
2шт.
400862R1
BOLT,Hex, 5/16" - 18 x 0.85"
shoulder
4шт.
390304C1
WASHER
.344 x .688 x .065 HDN
2шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16 flange lock
2шт.
6
1259760C1
BALL KNOB
KNOB, motor control valve, black
1шт.
7
120466C91
HANDLE
ASSY, motor control valve
1шт.
8
120464C1
BUSHING,19.07mm ID x 20.68mm OD x 13.21mm L
valve operating lever
2шт.
9
1259761C1
BUTTON
KNOB, aux control valve, yellow
1шт.
10
120468C91
HANDLE
ASSY, aux control valve
1шт.
11
120476C1
SPACER
valve handle hub
2шт.
12
104532C2
SHAFT
control pivot
1шт.
179837
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
2шт.
13
661652R1
SNAP RING,#75, Ext
Control handle #75, Ext
2шт.
16066R1
WASHER
SPACER, inner & outer
1шт.
21018R1
WASHER
SPACER, outer
1шт.
14
104533C1
RETAINER
control platform seal
2шт.
15
104535C2
GASKET
control platform
1шт.
179795
TILLAGE BLADE
1/4 x 3/4 pln type 5
4шт.
16
128010C1
HYD TUBE
TUBE ASSY, motor valve raise
1шт.
17
128011C1
HYD TUBE
TUBE ASSY, motor valve drop
1шт.
18
127966C1
HYD TUBE
TUBE ASSY, 2nd valve raise
1шт.
19
127967C1
HYD TUBE
TUBE ASSY, 2nd valve drop
1шт.
20
9410978
ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring
7/8-14 37 deg hyd flared tube adj str thd 90 deg
4шт.
21
9410204
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
CONNECTOR, 7/8-14 37 deg hyd flared tube
4шт.
22
364885R1
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
5/8 OD tube
1шт.
23
486004R1
CLAMP
aux valve tubes
2шт.
24
104796C1
PLATE
isomount aux valve tubes
1шт.
25
104799C1
STRIP
isomount aux valve tubes
2шт.
180137
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
3/8 x 2-3/4 type 5
1шт.
9413953
LOCK NUT,3/8"-16, GB
NUT, 3/8 PHC P/T lock type 5
1шт.
26
544786R95
COUPLING, BREAK AWAY
COUPLER ASSY, female
2шт.
179880
BOLT,Hex, 1/2" - 13 x 7/8", Gr 5
1/2 x 7/8 pln type 5
4шт.
27
64757C1
PLUG
coupler dust
4шт.
28
535033R3
BRACKET
coupler mtg LH
1шт.
271556
WHEEL CYLINDER,Hex, 5/8" - 11 x 1 1/4", Gr 5
SCREW, 5/8-11 x 1-1/4 cap
2шт.
29
1259805C1
BRACKET
coupler mtg RH, replaces 104317C1
1шт.
271556
WHEEL CYLINDER,Hex, 5/8" - 11 x 1 1/4", Gr 5
SCREW, 5/8-11 x 1-1/4 cap
2шт.
Выбрано товаров: 44
