Запчасти Case IH HYDRO 186 (02-01) - MISCELLANEOUS, PACKAGES AND ASSORTED GASKETS Accessories & Attachments / Miscellaneous

371418R91

PACKAGE

front wheel bearing overhaul, consists of

1шт.

G15215

ROLLER BEARING

BEARING ASSY, front wheel inner cone

1шт.

619387R1

BEARING CUP

BEARING, front wheel inner cup

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

BEARING ASSY, fron wheel outer cone

1шт.

618324R1

BEARING, front wheel outer cup

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub cap

1шт.

370254R91

OIL SEAL,57.02mm ID x 82.55mm OD x 6.86mm Thk

ASSY, front wheel oil

1шт.

48703D

RETAINER

front wheel oil seal

1шт.

1272428C91

SEAL PACKAGE

O-RING PACKAGE, chassis overhaul, replaces 386682R96, consists of

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot & selector drive shafts

2шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

1-1/4 x 1-1/2 x 1/8 clutch housing suction tube

2шт.

707253R1

O-RING,-222, 70 Duro, 1.484" ID x .139" Thk

1-1/2 x 1-3/4 x 1/8

1шт.

264681R1

O-RING,0.139" Thk x 6.48" ID, -260, Cl 5, 75 Duro

6-1/2 x 6-3/4 x 1/8 rear axle cap seal

2шт.

381884R1

O-RING,0.103" Thk x 0.987" ID, -120, Cl 6, 90 Duro

1 x 1-3/16 x 3/32 cover to seat support, small

3шт.

386867R1

O-RING,0.103" Thk x 1.11" ID, -122, Cl 6, 90 Duro

1-1/8 x 1-5/16 x 3/32 cover to seat support

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

2-5/16 x 2-1/2 x 3/32 cover to seat support, large

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

1-5/8 x 1-7/8 x 1/8 hydraulic filter suction tube

1шт.

293726R1

O-RING,0.139" Thk x 2.234" ID, -228, Cl 5, 75 Duro

2-1/4 x 1/8 hyd filter suction tube

1шт.

382997R1

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1/2 x 5/8 x 1/16 park lock actuating shaft

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot shaft

1шт.

355966R1

O-RING,0.424" ID x 0.103" Width

7/16 x 5/8 x 3/32 reverse shift pivot arm shaft

1шт.

385744R1

SEALING RING

rear frame pressure port oil

2шт.

388306R1

RING,32.77mm ID x 39.12mm OD x 3.17mm Thk

SEAL, rear frame pressure port oil

1шт.

387926R2

RING

O-RING, port cover seal

2шт.

128359

O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro

5/8 x 3/4 x 1/16 rear frame cover shift shafts

2шт.

529133R1

RING

rear axle carrier cap sealing

2шт.

381885R1

O-RING,0.103" Thk x 1.362" ID, -126, Cl 6, 90 Duro

1-3/8 x 1-9/16 class 6

1шт.

386683R95

GASKET

PACKAGE, chassis overhaul gasket, consists of

1шт.

380067R4

GASKET

CLUTCH, housing gasket

1шт.

384078R1

GASKET

CLUTCH, housing bottom cover gasket

1шт.

380112R1

GASKET

CLUTCH, housing cover gasket

1шт.

383330R1

GASKET

DRAFT CONTROL, adj opening cover gasket

1шт.

385757R2

GASKET

DRIVE, att opening cover gasket

1шт.

369860R1

GASKET,0.79mm Thk

FRONT WHEEL, hub gasket

2шт.

23977DB

GASKET

FUEL TANK, filler cap gasket

1шт.

381467R1

GASKET

INDEPENDENT PTO, opening cover gasket

1шт.

382257R2

GASKET

OIL FILTER, cover gasket

1шт.

382244R4

GASKET

PUMP, opening cover gasket

1шт.

380225R2

GASKET

REAR AXLE, carrier gasket

2шт.

380264R2

GASKET

REAR FRAME, cover gasket

1шт.

380315R1

GASKET

REAR FRAME, front cover gasket

1шт.

382416R1

GASKET

VALVE, adj opening cover gasket

1шт.

69298C92

STRIPPER PACKAGE

PACKAGE, drive plate service, consists of plate assy, drive (NSS)

1шт.

27876R1

BOLT,Hex, 1/2" - 13 x 7/8", Gr 8

1/2 x 7/8 PHC P/T type 8

6шт.

406579R1

WASHER

17/32 x 7/8 x 16 ga lubricant, spline, jar, (NSS) instructions, installing, (NSS)

6шт.

534791R91

GASKET

PACKAGE, hydrostatic transmission gasket service, consists of

1шт.

406498R1

GASKET

bottom front cover

1шт.

406500R1

GASKET

bottom rear cover

1шт.

396796R1

GASKET

cam pivot shaft housing

1шт.

406507R2

GASKET

drive housing to rear frame

1шт.

406495R2

GASKET

drive housing top cover

1шт.

396042R1

GASKET

left side cover

1шт.

406506R1

GASKET

lub block

1шт.

406716R2

GASKET

multiple control valve - HV

1шт.

406717R2

GASKET

multiple control valve - LT

1шт.

406548R1

GASKET

multi-valve body

1шт.

406502R1

GASKET

right side cover

1шт.

534792R91

STRIPPER PACKAGE

PACKAGE, hydrostatic transmission o-ring service, consists of

1шт.

369384R1

O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro

5-1, 90 Duro, .414" ID x .072" Thk, 5/16 OD tube, Bulkhead union

2шт.

383024R1

O-RING,0.07" Thk x 0.676" ID, -17, Cl 6, 90 Duro

11/16 x 13/16 x 1/16, charge tube fitting

1шт.

298385R1

O-RING,0.07" Thk x 0.676" ID, -17, Cl 5, 75 Duro

11/16 x 13/16 x 1/16, connector tube

1шт.

254954R1

O-RING,0.139" Thk x 1.046" ID, -215, Cl 5, 75 Duro

1-1/16 x 1-5/16 x 1/8, filter base

2шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk, Flared tube elbow & servo pressure port plug

3шт.

23072R1

O-RING,11.975" ID x 12.525" OD x 0.275"

12 x 12-1/2 x 1/4, front bearing support cover

1шт.

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, lub block, power steering pressure tube elbow & union

3шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32, lub block union, motor lub tube & strainer plug

3шт.

380910R1

O-RING,0.103" Thk x 2.987" ID, -151, Cl 5, 75 Duro

3 x 3-3/16 x 3/32, motor & pump trunnion

4шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

.644 x .818 x .087, power steering return tube union

1шт.

379457R1

O-RING,0.103" Thk x 2.175" ID, -139, Cl 5, 75 Duro

2-3/16 x 2-3/8 x 3/32, PTO front bearing cover

1шт.

254691R1

O-RING,-211, 70 Duro, .796" ID x .139" Thk

13/16 x 1-1/16 x 1/16, pump pressure port large

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32, pump pressure port small

1шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

1-1/4 x 1-1/2 x 1/8, pump suction port

1шт.

295204R1

O-RING,0.103" Thk x 2.8" ID, -149, Cl 5, 75 Duro

2-3/16 x 3 x 3/32, retainer

1шт.

379365R1

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

3/8 x 1/2 x 1/16, servo charge tube retainer

1шт.

307915R1

O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro

1-15/32 x 1-11/16 x 7/64, shuttle valve access plug

1шт.

406659R1

RING

anchor shaft support bushing

1шт.

406657R1

RING

control cylinder anchor shaft sealing

3шт.

66067C2

SEAL

SEAL, charge tube

4шт.
