Артикул
Название
Примечание
Количество
1
1255639C1
SHEET
blower box mounting, replaces 142989C1 by also ordering the following parts
1шт.
118520C2
SCREW
7шт.
28439R1
WASHER, .266 x .50 x .036 PHC
7шт.
24392R1
HARDWARE,Cross Pan Hd, #10 x 1/2"
SCREW, no. 10-16 x 1/2 PHC P/HDCR tap
6шт.
2
109106C2
BOX
ASSY, pressurizer blower
1шт.
24392R1
HARDWARE,Cross Pan Hd, #10 x 1/2"
SCREW, no. 10-16 x 1/2 PHC P/HDCR tap
7шт.
3
109390
GROMMET,5/16" ID x 23/32" x .062", Diag Cut
rubber, blower cable
1шт.
4
187954
GROMMET,1" ID x 1 3/4" x .062"
rubber, heater hose
2шт.
5
109246C94
BLOWER
ASSY, pressurizer, refer to pressurizer blower this group, for list of components
1шт.
5
143166C91
BLOWER
ASSY, pressurizer, refer to pressurizer blower this group, for list of compnents
1шт.
23986R1
SELF-TAP SCREW,Hex Wash Hd, 1/4" x 1/2"
SCREW, SELF TAPPING, Hex Wash Hd, 1/4" x 1/2"
8шт.
6
109262C1
HEATER TUBE,.625" OD, 42.38, 7.75, 9" Length
TUBE, heater inlet
1шт.
7
109283C1
TUBE
INSULATION, heater inlet tube
1шт.
8
111610C1
CLAMP
plastic tube
2шт.
24392R1
HARDWARE,Cross Pan Hd, #10 x 1/2"
SCREW, no. 10-16 x 1/2 PHC P/HDCR tap
2шт.
118676
WASHER,0.22" ID x 0.5" OD x 0.05" Thk
.219 x .500 x .036 PHC
2шт.
118461C1
COVER
molded rubber, tip
2шт.
9
HOSE, heater inlet, tube to valve, use 23 in. of 5/8 ID heater hose from a roll of hose marked, 117724C1
1шт.
10
274085R91
HOSE CLAMP,#10, 0.56/1.06 Type F Worm
CLAMP, no. 10 hose
8шт.
11
111221C4
VALVE
heater control
1шт.
12
111282C1
KNOB
heater control
1шт.
13
109134C1
BRACKET
heater control valve
1шт.
24388R1
SELF-TAP SCREW,Cross Pan Hd, #10 x 3/8"
SCREW, SELF TAPPING, Cross Pan Hd, #10 x 3/8"
2шт.
159920
SCREW,Cross Pan Hd, #10 - 24 x 1/2"
2шт.
120217
LOCK WASHER,#10
WASHER, LOCK, #10
2шт.
160515
SCREW,Cross Pan Hd, 1/4" - 20 x 1/2"
2шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
2шт.
120375
NUT,Hex, 1/4" - 20, Gr 5
2шт.
14
HOSE, heater control valve to core, use 20 in. of 5/8 ID heater hose from a roll of hose marked, 117724C1
1шт.
15
539056R3
CORE
heater
1шт.
24388R1
SELF-TAP SCREW,Cross Pan Hd, #10 x 3/8"
SCREW, SELF TAPPING, Cross Pan Hd, #10 x 3/8"
4шт.
16
HOSE, heater core outlet, use 14 in. of 5/8 ID heater hose from a roll of hose marked, 117724C1
1шт.
17
109263C1
HEATER TUBE
TUBE, heater outlet
1шт.
18
111619C1
STRAP
adjustable
5шт.
19
143481C92
CAB FILTER
PACKAGE, cab panel filter, replaces 109215C1
1шт.
19
87543798
CAB FILTER
Charcoal cab filter
1шт.
20
109240C1
CAB FILTER
FILTER, air recirculation
1шт.
21
221-89
REDUCER,Hex, 1/2" x 3/8" NPT
BUSHING, 1/2 x 3/8 reducing pipe
1шт.
22
301803R91
VALVE
ASSY, heater inlet shut-off
1шт.
23
HOSE, heater inlet, use 46 in. of 5/8 ID heater hose from a roll of hose marked, 117724C1
1шт.
24
HOSE, heater outlet, use 56 in. of 5/8 ID heater hose from a roll of hose marked, 117724C1
1шт.
25
301803R91
VALVE
ASSY, heater outlet shut-off
1шт.
26
118095C1
STRIP
foam, filler, tractor w/o air conditioning
2шт.
27
111619C1
STRAP
adjustable tie
1шт.
28
118102C1
STRIP, foam, filler, tractor w/o air conditioning
2шт.
29
928357C1
CLAMP, straight, single heater hose inlet
1шт.
30
(Not used in this application)
1шт.
31
(Not used in this application)
1шт.
32
143326C1
CLAMP
closed tube
1шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
120375
NUT,Hex, 1/4" - 20, Gr 5
1шт.
33
313318C1
CLAMP, no. 14 hose
2шт.
Выбрано товаров: 53
