Артикул
Название
Примечание
Количество
1
118184C94
DUCT
ASSY, headliner, consists of ref nos. 2, 3, 4, 5, 6, 7, 10, 11, 12, 13, 14, 15, 16 & 31
1шт.
1
143151C93
DUCT
ASSY, headliner radio, deluxe cabs, consists of ref nos. 2, 3, 4, 5, 6, 7, 10, 11, 12, 13, 14, 15, 16 & 31
1шт.
160568
SCREW,Cross Pan Hd, 1/4" - 20 x 1 1/4"
1/4 x 1-1/4 PHC P/HDCR mach
6шт.
118151C1
CLIP
U-shaped spring
16шт.
2
118144C1
SEAL
intake rear long
2шт.
3
118145C1
SEAL
intake rear short
2шт.
4
117632C4
SHEET
rear headliner foam, used w/118184C94
1шт.
4
1262101C1
SHEET
rear headliner foam, panel, used w/143151C93
1шт.
5
111666C1
BRACKET
door support
1шт.
1250628C2
SPACER
spacer
6шт.
26614R1
SCREW,Cross Pan Hd, 1/4" x 1 1/4"
1/4 x 1-1/4 PHC P/HDCR tap
4шт.
28482R1
SCREW, 1/4 x 1-3/8 PHC P/HDCR tap
2шт.
6
111668C1
SEAL
recirculation door short
2шт.
7
111669C1
SEAL
recirculation door long
2шт.
8
109282C1
GRILLE
recirculation
1шт.
9
111296C1
BUTTON
KNOB, grille retainer
6шт.
10
117621C1
DOOR
ASSY, recirculation
1шт.
11
111670C2
ROD
recirculation control
1шт.
12
428497C1
REINFORCEMENT
rod end
2шт.
13
117610C1
CHANNEL
ASSY, slide
1шт.
14
111675C1
STUD
control
1шт.
15
118183C1
PANEL
recirculation control trim
1шт.
27749R1
SCREW
no. 8-18 x 2-3/4 PHC O/HDCR tap
4шт.
16
111683C1
KNOB
air control
1шт.
160568
SCREW,Cross Pan Hd, 1/4" - 20 x 1 1/4"
1/4 x 1-1/4 PHC P/HDCR mach
4шт.
111685C1
NUT
spacer
4шт.
17
118152C1
SEAL
SEAL, duct front lower A/C
1шт.
Cabs with serial no. 107806 and below.
1шт.
143382C1
CLIP
U-shaped spring
8шт.
18
118172C1
SEAL
SEAL, duct front lower heater
1шт.
Cabs with serial no. 107806 and below.
1шт.
118151C1
CLIP
U-shaped spring
10шт.
19
489348C1
RETAINER
rear headliner assy, replaces 117718C2
2шт.
20
118155C2
STRIP
headliner
2шт.
24392R1
HARDWARE,Cross Pan Hd, #10 x 1/2"
SCREW, no. 10-16 x 1/2 PHC P/HDCR tap
4шт.
21
118194C2
PANEL
front headliner
1шт.
143012C1
FASTENER
push-in
7шт.
Cabs with serial no. 103499 and below.
1шт.
118520C2
SCREW
shoulder tap
7шт.
Cabs with serial no. 103500 and above.
1шт.
28439R1
WASHER, .266 x .50 x .036 PHC
7шт.
26625R1
SELF-TAP SCREW,Cross Pan Hd, 1/4" x 1 1/4"
SCREW, 1/4-14 x 1-1/4 PHC P/HDCR tap
6шт.
118773
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
.281 x .625 x .051 PHC
6шт.
22
118207C1
SEALING STRIP
SEAL, front headliner
2шт.
23
117756C1
SEAL, front headliner corner
2шт.
24
109227C1
VENT
ASSY, air discharge
3шт.
25
117611C2
SPACER
friction
9шт.
26
109505C1
RETAINER
headliner side LH
1шт.
Cabs with serial no. 107806 and below.
1шт.
26
118539C1
RETAINER
headliner side LH
1шт.
Cabs with serial no. 107807 and above.
1шт.
For cabs with deluxe trim.
1шт.
27679R1
SELF-TAP SCREW
1/4-14 x 1-1/4 PHC O/HDCR tap
5шт.
27
109506C1
RETAINER
headliner side RH
1шт.
Cabs with serial no. 107806 and below.
1шт.
27
118540C1
RETAINER
headliner side RH
1шт.
Cabs with serial no. 107807 and above.
1шт.
For cabs with deluxe trim.
1шт.
27679R1
SELF-TAP SCREW
1/4-14 x 1-1/4 PHC O/HDCR tap
5шт.
28
118299C1
SUPPORT
ASSY, headliner rear
1шт.
24392R1
HARDWARE,Cross Pan Hd, #10 x 1/2"
SCREW, no. 10-16 x 1/2 PHC P/HDCR tap
7шт.
29
109507C1
SUPPORT
headliner corner LH
1шт.
29
109508C1
SUPPORT
headliner corner RH
1шт.
27679R1
SELF-TAP SCREW
1/4-14 x 1-1/4 PHC O/HDCR tap
2шт.
30
118206C1
SEALING STRIP
SEAL, front headliner
1шт.
31
118345C1
BUMPER
recirculation door
1шт.
32
118543C1
VISOR, SUN
VISOR ASSY, sun
2шт.
For cabs with deluxe trim.
1шт.
27114R1
SCREW
no. 10 x 1/2 PHC O/HDCR mach
8шт.
33
118537C1
RETAINER
visor arm
1шт.
For cabs with deluxe trim.
1шт.
159911
SPACER
SCREW, no. 10 x 3/8 PHC P/HDCR mach
2шт.
118542C1
NUT
10-24 twin spring
1шт.
34
118150C1
SEAL
duct front side w/air conditioning
2шт.
Cabs with serial no. 107806 and below.
1шт.
34
118173C1
SEAL
SEAL, duct front side w/o air conditioning
2шт.
Cabs with serial no. 107806 and below.
1шт.
34
1250479C2
SEAL
duct front seal
1шт.
Cabs with serial no. 107807 and above.
1шт.
143382C1
CLIP
U-shaped spring
1шт.
118171C1
PACKAGE
KIT, fastener 2 in. TGL type
1шт.
117995C1
PACKAGE
KIT, trim panel fastener 3/4 TGL type
1шт.
Выбрано товаров: 82
