Запчасти Case IH 806 (A-12[A]) - CHASSIS, RIGHT HAND SIDE OPERATOR MOUNTING STEP AND HANDLE, FARMALL TRACTORS Chassis, Radiator & Sheet Metal

395125R91

PARTS ACCESSORY, RH side operator mounting, also order grip, 388940R1 when applied to tractors up to serial no. 30573

1шт.

1

394820R1

HANDLE

operator mounting assist

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16-18 x 1 C-Z hex-hd cap

1шт.

180081

BOLT,Hex, 5/16"-18 x 1 1/4", G5

5/16"-18 x 1-1/4" C-Z hex-hd cap

1шт.

2

395123R1

STEP

ASSY, RH mounting

1шт.

271607

BOLT,Hex, 3/4" - 10 x 1 1/2", Gr 5

SCREW, 3/4-10 x 1-1/2 hex-hd cap

1шт.

Q3501

WASHER

25/32 x 1-1/4 x 16 ga.

1шт.

375250R1

SCREW,Flg, 5/8" - 11 x 2 1/4"

5/8-11 x 2-1/4 12 pt-hd cap

1шт.

3

379719R1

BRACKET, mounting step

1шт.

413-1044

BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5

SCREW, 5/8-11 x 2-3/4 hex-hd cap

2шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

4

20250R1

PIN, 3/16 x 2-1/4 rod end

1шт.

NLS

NO LONGER SERVICED

PIN, 1/16 x 1/2 cot.

1шт.
