Артикул
Название
Примечание
Количество
1
385798R1
SUPPORT
stray bar rear
1шт.
102635
NUT,3/8"-16, G5
1шт.
17841R1
SCREW, 3/8-16 x 5-1/2 hex-hd cap
1шт.
271564
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5
SCREW, 5/8-11 x 2-1/2 hex-hd cap
2шт.
NLS
NO LONGER SERVICED
SCREW, 5/8-11 x 4 hex-hd cap
2шт.
103325
LOCK WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
2
385799R1
AXLE PIN
PIN, stay bar rear pivot
1шт.
3
219-45
LUBE NIPPLE,65 Degree Elbow, 1/4" NPTF
FITTING, 1/4 65 deg angle drive type lub
2шт.
4
385806R11
BAR ASSY, stabilizer
1шт.
114505
JAM NUT,Jam, 1/2"-13, G5
2шт.
214442
NUT,1/2"-20, G8
1/2-20 hex.
8шт.
20167R1
BOLT,1/2" x 3", Gr 8
SCREW, 1/2-20 hex-hd cap
8шт.
179885
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
Adjustable screw Hex, 1/2"-13 x 1 1/2", G5, Full Thd
2шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
8шт.
5
385805R1
BUSHING
stabilizer bar
1шт.
6
385809R1
WASHER, stay bar extension gusset
8шт.
7
385810R4
BRACKET
BOLSTER, lower
1шт.
102635
NUT,3/8"-16, G5
1шт.
17892R1
BOLT,Hex, 3/8" - 16 x 6 1/4"
SCREW, 3/8-16 x 6-1/4 hex-hd cap
1шт.
323546R1
BOLT,Hex, 3/4" - 10 x 4", Gr 8
SCREW, 3/4-10 x 4 hex-hd cap
2шт.
20072R1
BOLT,Hex, 3/4" - 10 x 3 1/4", Gr 8
SCREW, 3/4-10 x 3-1/4 hex-hd cap
2шт.
8
379941R1
AXLE PIN,38.1mm OD x 219.2mm L
PIN, front axle pivot
1шт.
9
385812R1
ARM
steering center
1шт.
NLS
NO LONGER SERVICED
SCREW, 3/4-10 x 1-3/8 hex-hd cap
3шт.
10
385814R92
TIE-ROD
ROD ASSY, adj tie
2шт.
108643
COTTER PIN,5/32" x 1 3/8"
Pin, Split (Cotter), 5/32" x 1 3/8"
4шт.
11
385841R1
TUBE, tie rod
1шт.
12
384005R92
JOINT
END ASSY, tie rod, LH thd
1шт.
13
358901R1
SLOTTED NUT
tie rod end
4шт.
14
374061R1
JAM NUT
jam, LH
1шт.
15
384006R92
END
ASSY, tie rod, RH thd
1шт.
16
374062R1
JAM NUT
NUT, jam, RH thd
1шт.
17
385R91
AXLE ASSY, front, composed of ref. nos. 17 thru 55 & attaching parts, also includes carrier assy, 385774R91 & gasket, 69177R1
1шт.
17
385857R91
HOUSING ASSY, front axle, composed of ref. nos. 18, 19 & 20
1шт.
18
379943R1
BUSHING,38.11mm ID x 41.41mm OD x 38.1mm L
front axle pivot pin
2шт.
19
280668R91
PLUG
3/4 magnetic pipe
2шт.
20
268540C1
BREATHER
VENT, front axle housing
1шт.
21
387408R91
OIL SEAL
front axle housing
2шт.
22
899257R91
SPINDLE
ASSY, composed of ref. nos. 23, 24 & 25
2шт.
23
899255R1
STEP BOLT,7/16" x 2 3/4"
SCREW, wedge adjusting
2шт.
425-117
NUT,7/16"-20, G5
7/16-20 hex.
2шт.
496-21047
WASHER
15/32 x 59/64 x .065
2шт.
24
196513R91
SHIM KIT
PACKAGE, wheel brg adjusting shim
4шт.
25
385823R91
STRIPPER PACKAGE
PACKAGE, lock plate service
2шт.
26
267383C1
END ASSY.
STUB, axle
2шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex.
8шт.
181435
BOLT,Hex, 1/2" - 20 x 2", Gr 5
SCREW, 1/2-20 x 2 hex-hd cap
8шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
8шт.
27
129077H
BEARING
pivot cup
4шт.
28
680004R91
BEARING ASSY,31.75mm ID x 24.07mm W
ASSY, pivot cone
4шт.
29
899258R1
WEDGE
CAP, pivot bearing
2шт.
30
899253R1
CYLINDER END CAP
WEDGE, pivot bearing
2шт.
31
899267R1
RING
clamp
2шт.
32
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , PTF, Axle stub 1/8"-27 x .66 lg
4шт.
33
271841R91
CONE
BEARING ASSY, radial cone
4шт.
34
899266R1
PLATE ASSY.
PLATE, bearing adj
2шт.
179883
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
8шт.
35
259263C91
OIL SEAL
PACKAGE, hub seal service
2шт.
36
387409R91
YOKE
AND RING ASSY, less ref. no. 43
2шт.
37
387410R91
RING
ASSY, compensating
2шт.
20977R1
PLUG
1/2-14 auto sq-soc pipe
4шт.
38
387411R1
BUSHING
compensating ring
4шт.
39
387412R1
BUSHING
compensating ring
4шт.
40
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 1/4 x 3/16 PTF str lub, yoke & ring assy
4шт.
41
899263R1
YOKE
power
2шт.
42
385851R1
AXLE PIN
PIN, Serial Range: ring-yoke
4шт.
576484R1
LOCK PIN,3/16" x 1 3/4", Slotted
Pin, 3/16" x 1 3/4", Slotted
4шт.
43
196523R1
AXLE PIN
PIN, ring TC hub
4шт.
44
385850R91
HUB
W/TWO CUPS, 879079R1 wheel
2шт.
196528R1
AXLE PIN
PIN, wheel hub dowel
4шт.
45
879079R1
CUP ASSY.
BEARING, wheel hub cup
4шт.
46
385852R1
SHAFT
axle LH
1шт.
46
385853R1
SHAFT
axle RH
1шт.
47
899252R1
BUSHING
axle shaft tapered
16шт.
286897R1
SCREW
1/2-20 x 1-1/4 drilled hd cap
16шт.
385859R1
WIRE, 1/16 x 8 safety
8шт.
48
385855R1
ARM, steering LH
1шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex.
4шт.
181440
BOLT,Hex, 1/2" - 20 x 2 1/2", Gr 5
SCREW, 1/2-20 x 2-1/2 hex-hd cap
2шт.
181441
SCREW, 1/2-20 x 2-3/4 hex-hd cap
2шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
49
385856R1
ARM, steering RH
1шт.
25-118
NUT,1/2"-20, G5
1/2-20 x 2-1/2 hex-hd cap
2шт.
NLS
NO LONGER SERVICED
SCREW, 1/2-20 x 2-3/4 hex-hd cap
2шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
50
197595R1
STUD
wheel
24шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex.
24шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
24шт.
51
385854R2
COVER ASSY
COVER, wheel
2шт.
52
(Not used in this application)
1шт.
53
385858R91
CLAMP
wheel boot
2шт.
54
899260R1
RETAINER
wheel boot
4шт.
171716
SELF-TAP SCREW,Slotted Pan Hd, #10 x 3/8"
SCREW, 10-24 x 3/8 slt-pan-hd tap.
24шт.
115545
LOCK WASHER,Int Tooth, #10
WASHER, no. 10 int-tooth lock
24шт.
55
389050R1
BOOT
BOOT, wheel
2шт.
Выбрано товаров: 95
