Запчасти Case IH LUCAS (06) - K928643 GENERATOR, LUCAS NUMBER 22756, MODEL C40T

1

K928643

GENERATOR

ASSY. - (12 volt)

1шт.

2

K962791

BOLT - thru

2шт.

A47091

DRIVE ASSY. - tachometer

1шт.

4

NSS

NOT SOLD SEPARAT

GEAR BOX ASSY. - tachometer

1шт.

5

NSS

NOT SOLD SEPARAT

PLATE - tachometer gear box

1шт.

6

NSS

NOT SOLD SEPARAT

SCREW -, Serial Range: plate-box

2шт.

7

K963876

FRAME - commutator end

1шт.

8

K963773

BRUSH ASSY.

1шт.

9

K963781

SPRING SET - brush tension

1шт.

K963774

KIT - terminal

1шт.

10

NSS

NOT SOLD SEPARAT

BLADE - terminal

1шт.

11

NSS

NOT SOLD SEPARAT

HOUSING - terminal blade

1шт.

12

NSS

NOT SOLD SEPARAT

EYELET - terminal

1шт.

13

NSS

NOT SOLD SEPARAT

RIVET - terminal

1шт.

K963780

COIL

KIT - field coil

1шт.

14

NSS

NOT SOLD SEPARAT

COIL - field

2шт.

15

NSS

NOT SOLD SEPARAT

SHOE - pole

2шт.

16

NSS

NOT SOLD SEPARAT

SCREW - pole

2шт.

K963771

KIT

- bearing retention, commutator end

1шт.

17

NSS

NOT SOLD SEPARAT

RING - pressure

1шт.

18

NSS

NOT SOLD SEPARAT

COLLAR - bearing

1шт.

19

K963767

BEARING - armature shaft, commutator end

1шт.

20

K963777

ARMATURE

1шт.

K963770

KIT

- bearing retention, drive end

1шт.

21

NSS

NOT SOLD SEPARAT

PLATE - bearing retention

1шт.

22

NSS

NOT SOLD SEPARAT

RIVETS

3шт.

23

K963766

BEARING - armature shaft, drive end

1шт.

24

K963892

FRAME - drive end

1шт.

25

K963868

KIT

- hardware

1шт.
