Запчасти Case IH 990A (43) - EXHAUST BRAKE, U371 (5.1) - BRAKES

K906799

NO LONGER SERVICED

Exhaust Valve Assembly

1шт.

1

K907032

VALVE

Housing 906799

1шт.

2

K904545

VALVE

906799

1шт.

3

K904537

VALVE

Lever 906799

1шт.

4

K19541

PIN

Split Pin, 5/32 x 1 1/8 in. 906799

1шт.

5

K906454

SPINDLE

Operating Spindle 906799

1шт.

6

K904547

BUSHING

Bush 906799

2шт.

7

K906798

LEVER

Operating Lever 906799

1шт.

8

K623740

SPLIT PIN/SAFETY PIN

Spring Dowel, 3/16 in. dia. 906799

3шт.

9

K904551

COLLAR

906799

1шт.

10

K608200

STUD

3/8 UNC x 1 5/16 in. 906799

2шт.

K68327

GASKET

, Serial Range: Gasket--Valve-Manifold

1шт.

11

K608220

STUD

3/8 UNC x 4 3/4 in.

2шт.

280136

NUT,3/8"-16, G8

(Replaces 607503) 3/8"-16, G8

4шт.

12

K906771

SPARE PART

Control Pedal

1шт.

13

K906451

CENTER AXLE

Pivot Pin

1шт.

14

K906794

SPARE PART

Control Rod

1шт.

K621587

RING, SNAP

E Clip, 3/8 in.

2шт.

15

K906654

BOOT

Eye End

1шт.

16

K906456

SPRING

Return Spring

1шт.

17

K906455

Anchor Bracket

1шт.

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg

1шт.

18

K15484

WASHER

--Special Nominal

1шт.

19

K906657

SPRING

--Control Rod

1шт.

231-1435

LOCK NUT,5/16"-18, GB

NUT - Nyloc, 5/16 UNC

1шт.

20

K906322

FLANGE

Exhaust Flange

1шт.

K904550

GASKET

--Flange

1шт.

K602902

SCREW

Setscrew, 3/8 UNC x 3/4 in. Spring anchor to fuel tank support, Replaces 602901

1шт.

280136

NUT,3/8"-16, G8

Spring anchor to fuel tank support 3/8"-16, G8

1шт.

K19482

SPRING WASHER

Spring Washer, 3/8 in. Spring anchor to fuel tank support

1шт.
