Запчасти Case IH 990 (N02-1) - SERVICE PARTS, DECALS AND INSTRUCTION PLATES Service Parts

1

K917151

PRODUCT GRAPHIC

DECAL - air cleaner

1шт.

2a

K917240

DECAL

- engine stop control (990, 995, 996, 990G, 995G, 996G)

1шт.

2b

K952670

PRODUCT GRAPHIC

DECAL - engine stop control (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

3

K952669

DECAL

- hand throttle control (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

4

K947548

DECAL

- alternator warning

1шт.

5

K917425

PRODUCT GRAPHIC

DECAL - negative earth

1шт.

6a

K940726

PRODUCT GRAPHIC

DECAL - gear positions, twelve speed (990, 995, 996, 990G, 995G, 996G)

1шт.

6b

K952588

DECAL

- gear positions, twelve speed (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

7a

K923367

DECAL

- power take-off operation (990, 995, 996, 990G, 995G, 996G)

1шт.

8

K949760

DECAL

- power take-off warning

1шт.

9a

K950497

DECAL

- independent PTO clutch (990, 995, 996, 990G, 995G, 996G)

1шт.

9b

K919809

PRODUCT GRAPHIC

DECAL - independent PTO clutch (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

10a

K950194

DECAL

- isolating switch with Thermostart (990, 995, 996, 990G, 995G, 996G)

1шт.

10b

K953665

DECAL

- isolating switch with Thermostart (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

11a

K952685

DECAL

- operating warning, left-hand (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

11b

K952686

DECAL

- operator warning, right-hand (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

12

K921551

PRODUCT GRAPHIC

DECAL - belt pulley

1шт.

13

K952971

DECAL

- implement warning (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

2шт.

14

K953599

PRODUCT GRAPHIC

DECAL - overturning warning (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

15

K945069

DECAL

- seat belt warning (990, 995, 996, 990G, 995G, 996G)

1шт.

16

K952168

DECAL

- steering wheel hub (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

17a

K952481

IDENTITY PLATE

PLATE - type approval, standard clearance (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

17b

K954166

PLATE

- type approval, high clearance (990Q, 995Q, 996Q, 990SK, 995SK, 996SK)

1шт.

18

K954684

PLATE

- tractor serial number, except Germany

1шт.

18b

PLATE - tractor serial number, Germany (990, 995, 996, 990G, 995G, 996G)

1шт.

K624090

RIVET

- 1/8 x 3/16 in.

4шт.

K913882

PLATE

- tractor specification (Germany only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K112051

SCREW - no. 4 x 1/4 in. (Germany only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K952727

PRODUCT GRAPHIC

DECAL - battery warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953239

DECAL

- fan warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953240

DECAL

- rotating machine warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953241

DECAL

- hitch warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953242

DECAL

- starter warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953243

DECAL

- booster charge connections (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953244

DECAL

- universal safety sign (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953245

DECAL

- operating instructions, OSHA (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K953573

DECAL

- cooling system warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.

K954075

PRODUCT GRAPHIC

DECAL - power take-off warning (North America only) (990, 995, 996, 990G, 995G, 996G)

1шт.
