Запчасти Case IH 950 (148) - TRANSMISSION BRAKE (06) - POWER TRAIN

K904199

Rear Half Main Frame

1шт.

K904182

Front End Plate--Gearbox

1шт.

1

K904184

SPARE PART

Handle

1шт.

2

K904201

Collar

1шт.

3

K11167

PIN

--1/4" dia.x 2" L. Mills G.P.1

1шт.

4

K65786

PAWL

1шт.

5

K900010

PAWL

Pin

1шт.

6

K65787

SPRING

1шт.

7

K621585

RING, SNAP

Circlip

2шт.

8

K904517

Support Bracket

1шт.

9

K19220

BOLT

--5/16" B.S.F. x 3/4" L., Serial Range: Bracket-Frame

4шт.

K19481

SPRING WASHER

Washer--Spring, 5/16" dia., Serial Range: Bracket-Frame

4шт.

K19471

WASHER

--Plain, 5/16" dia., Serial Range: Bracket-Frame

4шт.

10

K904214

Operating Lever

1шт.

11

K904359

PIN

--Adjusting Levers

1шт.

12

K626723

BELLEVILLE WASHER

Bellville Washer

6шт.

13

K19445

NUT

Locknut--5/8" B.S.F.

1шт.

14

K904361

BUSHING

Adjuster Bush

1шт.

15

K24710

NUT

Nyloc Nut--3/8" B.S.F.

1шт.

16

K904204

SHAFT

and Lever

1шт.

17

K24556

O-RING,0.734" ID x 1.012" OD x 0.139"

O Ring--O.S. 15

1шт.

18

K11128

CIRCLIP

--1" dia. External

1шт.

19

K904219

COUPLING, BREAK AWAY

Coupling--Camshaft

1шт.

20

K904108

WASHER

Thrust Washer

2шт.

21

K904178

CAMSHAFT

1шт.

22

K904105

BRACKET

Camshaft Bracket--R.H.

1шт.

23

K904104

CAMSHAFT

Bracket--L.H.

1шт.

24

K13107

Bolt--3/8" B.S.F. x 4 1/4" L.

4шт.

K19482

SPRING WASHER

Washer--Spring, 3/8" dia.

4шт.

25

K625107

SPRING

4шт.

26

K904094

PLATE

Retaining Plate

4шт.

27

K19202

SPARE PART

Bolt--1/4" B.S.F. x 7/8" L. Plate Fixing

8шт.

K19480

SPRING WASHER

--Spring, 1/4" dia. Plate Fixing

8шт.

28

K904106

BLOCK

Thrust Block

1шт.

29

K902393

DISC

Clutch Plate

3шт.

30

K902394

PLATE

Clutch Plate

4шт.

31

K904091

GEAR

Driven Gear

1шт.

32

K904109

BUSHING

Distance Piece

1шт.

33

K904107

Distance Piece

1шт.

34

K904055

Bevel Pinion Shaft

1шт.

35

K904089

CLUTCH

Ring

1шт.

36

K904103

PLATE

Packing Plate

1шт.

37

K19249

BOLT

--3/8" B.S.F. x 2" L. Ring and, Serial Range: Plate-Housing

4шт.

K19482

SPRING WASHER

Washer--Spring, 3/8" dia. Ring and, Serial Range: Plate-Housing

4шт.

38

K904087

HOUSING

Bearing Housing

1шт.

39

K12205

DOWEL

2шт.
