Запчасти Case IH 950 (134) - SELECTOR MECHANISM AND RAMSHAFT BRACKET (06) - POWER TRAIN

1

K24563

SPRING

1шт.

2

K17063

BALL

1шт.

3

K903484

Override Control Lever Assembly, Comprising Refs. 4 - 7, 10 and 11

1шт.

4

K903479

WINDOW STAY

Override Control Lever

1шт.

5

K623740

SPLIT PIN/SAFETY PIN

Spring Dowel Pin--3/16" dia.

1шт.

6

K903480

Housing

1шт.

7

K900380

O-RING,0.487" ID x 0.693" OD x 0.103"

O Ring

1шт.

8

K903412

GASKET

1шт.

9

K11209

Screw--1/4" B.S.F.x 3/4" L.

2шт.

10

K625123

SPRING

1шт.

11

K903400

LARGE PIN

Dog Clutch Assembly

1шт.

12

K621589

RING, SNAP

Circlip--1/2" dia. External

1шт.

13

K903406

WASHER

Retaining Washer

1шт.

14

K903407

PIN

Extension--(supplied with Ramshaft)

1шт.

15

K903464

PLATE

Locating Plate

1шт.

16

K620552

Wedglok Bolt--1/4" B.S.F. x 9/16" L.

1шт.

K19470

WASHER

--Plain, 1/4" dia.

1шт.

17

K903409

Striker Assembly

1шт.

18

K903482

Ramshaft Bracket Assembly Comprising 19 - 29

1шт.

19

K903356

INNER SHOE

Inner Plunger

1шт.

20

K625122

SPRING

1шт.

21

K903355

Outer Plunger

1шт.

22

K903357

Operating Lever

1шт.

23

K11160

SCREW

Grub Screw

1шт.

24

K903014

PIVOT ASSY.

Pivot Pin

1шт.

25

K11506

Plug--7/16" B.S.F. x 1/4" L.

2шт.

26

K903370

PIN

--Operating Lever

1шт.

27

K903295

Ramshaft Bracket

1шт.

K12250

FITTING

Greaser

1шт.

28

K86432

Breather Cap

1шт.

29

K30126

BEARING

1шт.

30

K36310

GASKET

1шт.

31

K19299

BOLT (SPREADER)

Bolt--1/2" B.S.F. x 5" L.

2шт.

32

K19290

X

Bolt--1/2" B.S.F. x 2 3/4" L.

2шт.

K11518

WASHER

Lockwasher--1/2" dia.

4шт.

33

K903296

Cover

1шт.

34

K903297

GASKET

1шт.

35

K903369

Bolt--Cover

1шт.

36

K623534

O-RING,0.352" OD x 0.103" Width

Sealing Ring

1шт.

37

K905120

SPARE PART

Oil Retainer--(White Felt)

1шт.
