Запчасти Case IH 950 (124) - OIL FILTER AND PIPES, HYDRAULIC PUMP (06) - POWER TRAIN

K62794

OIL RESERVOIR

Oil Filter--Complete Comprising Refs. 1 - 4

1шт.

1

K63638

FILTER

Gauze Cover

1шт.

2

K904390

PLUG

Magnetic Filter--(Replaces 63525) From Tractor 67549 inclusive

1шт.

3

K904389

BUSHING

Distance Piece--(Replaces 63526) From Tractor 67549 inclusive

1шт.

4

K624300

SCREW

--Rd. Hd. 2 B.A. x 1 5/8" L. From Tractor 67549 inclusive

1шт.

K11109

NUT

--Plain, 2 B.A. From Tractor 67549 inclusive

1шт.

K19488

SPRING WASHER

--Spring, 3/16" dia. From Tractor 67549 inclusive

1шт.

K904388

WASHER

Locating Washer--(used with 904390) From Tractor 67549 inclusive

1шт.

5

K68123

O-RING,0.21" Thk x 1.85" ID, -328, Cl 5, 75 Duro

O Ring--(Black Rubber)

1шт.

6

K89128

Oil Suction Pipe--Sump, Serial Range: Filter-Pump

1шт.

K14971

Nyloc Nut--1/4" B.S.F.

1шт.

7

K64852

NO LONGER SERVICED

Special Washer

1шт.

8

K620503

Special Bolt--1/4" B.S.F. x 3/4" L.

4шт.

K19480

SPRING WASHER

--Spring, 1/4" dia.

4шт.

9

K15596

RING,3.63mm Thk x 31.34mm ID

O Ring--(Black Rubber)

1шт.

10

K89127

, Serial Range: Connector--Pipes-Pump

1шт.

11

K24676

O-RING,0.103" Thk x 0.612" ID, -114, Cl 6, 90 Duro

O Ring--(Black Rubber)

1шт.

12

K89170

SHIM

Clamping Plate

1шт.

13

K11209

Screw--C'sk. Hd. 1/4" B.S.F. x 3/4" L.

3шт.

14

K901889

SPARE PART

Oil, Serial Range: Pipe--Connector-Cylinder

1шт.

15

K11765

Banjo Bolt--18 mm.

1шт.

16

K626784

WASHER,23.24mm ID x 33.34mm OD x 2.34mm Thk

--Aluminium--23 mm. dia.

1шт.

17

K626782

WASHER

--Aluminium--18 mm. dia.

1шт.

18

K903391

SPARE PART

Oil Pipe--Connector to T.C.U. Valve

1шт.

19

K67801

NIPPLE, LUBE

Banjo Bolt--3/4" B.S.P.

1шт.

20

K626785

WASHER

--Copper Asbestos, 3/4" B.S.P.

2шт.

21

K904065

Special Elbow and, Serial Range: Pipe-P.T.O.

1шт.

22

K19200

BOLT

--1/4" B.S.F. x 5/8" L., Serial Range: Pipe-Housing

2шт.

K19480

SPRING WASHER

--Spring, 1/4" dia., Serial Range: Pipe-Housing

2шт.

23

K904343

Oil, Serial Range: Pipe--Elbow-Union

1шт.

24

K904338

Oil, Serial Range: Pipe--Union-Pipe

1шт.

25

K621614

Clip

1шт.

26

K11544

Bolt--1/4" B.S.F. x 1/2" L.

1шт.

K19480

SPRING WASHER

--Spring, 1/2" dia.

1шт.

27

K903078

Oil Pipe--Clutch Driveshaft

1шт.

28

K89433

Pipe Clip--Pipe to Frame (Clutch)

1шт.

29

K11287

Bolt--2 B.A. x 1/2" L.

1шт.

K11109

NUT

--Plain, 2 B.A.

1шт.

K19488

SPRING WASHER

--Spring, 3/16" dia.

1шт.
