Запчасти Case IH 950 (074) - INSTRUMENT PANEL AND FITTINGS (03) - FUEL SYSTEM

1

K903443

Instrument Panel

1шт.

2

K627870

PLUG

Button

1шт.

3

K903513

STRIP

Seating Strip

2шт.

4

K901854

Blanking-off Plate--Tractormeter

1шт.

5

K624791

SCREW

Sheet Metal Screw Panel Fixing

3шт.

6

K15539

Captive Nut Panel Fixing

3шт.

7

K11638

THERMOSTAT

Thermometer--Complete with Capillary Tube

1шт.

8

K903487

Blanking Plate--Thermometer

1шт.

K10518

BUCKLE

Clip--For Capillary Tube

3шт.

9

K19932

RING

Clip--To Block

1шт.

10

K11189

SCREW

--Rd. Hd. 3/16" Whit. x 1/2" L. Clip to Tank Support

1шт.

K19415

NUT

--Plain, 3/16" Whit. Clip to Tank Support

1шт.

K19488

SPRING WASHER

--Spring, 3/16" dia. Clip to Tank Support

1шт.

11

K901856

SPARE PART

Ignition and Oil Warning Light

1шт.

12

K901857

Lead--Switch to Warning Light

1шт.

13

K901836

IGNITION SWITCH

Lighting Switch--Lucas P.P.61

1шт.

14

K901981

KNOB

1шт.

K14658

O-RING,0.07" Thk x 0.239" ID

O Ring From Tractor 70348 Onwards

1шт.

15

K901982

PLATE

Escutcheon Plate

1шт.

16

K904243

Bracket--Instrument Panel Harness

1шт.

17

K624714

SCREW

--Mush. Hd. 2 B.A. x 3/8" L.

2шт.

K11109

NUT

--Plain, 2 B.A.

2шт.

K19488

SPRING WASHER

--Spring, 3/16" dia.

2шт.
