Запчасти Case IH 885N (7-02) - HYDRAULIC BRAKING SYSTEM, 885LP, 885Q AND 885SK TRACTORS (07) - BRAKES

Схема запчастей Case IH 885N - (7-02) - HYDRAULIC BRAKING SYSTEM, 885LP, 885Q AND 885SK TRACTORS (07) - BRAKES
16
26
32
11
30
29
36
15
21
31
25
14
1
34
36
9
12
11
32
22
23
18
27
13
5
20
13
19
33
10
24
28
35
2
17
4
6
8
7
3

Артикул

Название

Примечание

Количество

1

K941535

BRAKE

PEDAL - brake, left-hand with bushings, no longer available

1шт.

2

K941536

BRAKE

PEDAL - brake, right-hand with bushings, no longer available

1шт.

3

K628754

BUSHING

- brake pedals

4шт.

4

K950568

PIN

- pivot, pedals, no longer available

1шт.

5

K19552

GROOVED PIN,1/8" x 1 1/8", Type A

Pin, Grooved, 1/8" x 1 1/8", Type A

1шт.

6

K948974

LATCH

- locking, brake pedals

1шт.

7

K600500

SCREW

BOLT - special, 3/8 inch NC

1шт.

K626700

WASHER

- spring, 3/8 inch

1шт.

8

K624947

SPRING

- return

2шт.

9

K949253

SUPPORT

BRACKET - support, pedals, no longer available

1шт.

10

K602845

BOLT,Hex Hd, 5/16"-18 x 3/4"

SCREW - hex, 5/16 NC x 5/8 inch, bracket to cab

2шт.

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, , bracket to cab (Replaces washer K19481) 5/16"

2шт.

K626682

WASHER

- flat, 5/16 inch

1шт.

11

K622205

FORK

- end, 5/16 inch NC

2шт.

425-115

NUT,5/16"-24, G5

- hex, 5/16 inch NF (Replaces nut K616981)

2шт.

12

K625954

PIN

- clevis, 5/16 x 1-3/16 inch, no longer available

2шт.

432-48

COTTER PIN,1/16" x 1/2"

PIN, SPLIT (COTTER), (Replaces pin K623605) 1/16" x 1/2"

2шт.

13

K950544

CYLINDER,36.32mm Stroke

- master, Girling 73067017

2шт.

14

413-518

BOLT,Hex, 5/16" - 18 x 1-1/8", Gr 5

- hex, 5/16 NC x 1-1/8 inch, cylinder to cab (Replaces bolt k602844)

4шт.

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, , cylinder to cab (Replaces washer K19481) 5/16"

4шт.

15

K951958

PIPE

- master cylinder inlet, no longer available

1шт.

16

K951369

PIPE

- reservoir to master cylinder, used with 885Q tractors, no longer available

1шт.

16

K954504

PIPE

- reservoir to master cylinder, used with 885Sk and 885LP tractors, no longer available

1шт.

17

K627736

GROMMET

- 3/4 inch, no longer available

1шт.

18

K951526

RESERVOIR

- with filler cap

1шт.

K964488

CAP

- filler, reservoir

1шт.

K964813

COVER

- filler cap, blue, no longer available

1шт.

19

K624873

CLIP

- reservoir to cab bulkhead, no longer available

1шт.

20

K614946

SCREW,Pan, #10 - 32 x 3/4"

- hex, No. 10 NF x 3/4 inch, reservoir to cab bulkhead

1шт.

492-11010

LOCK WASHER,#10

WASHER, LOCK, , Reservoir to cab bulkhead #10

1шт.

225-14210

NUT,#10-32

Reservoir to cab bulkhead (Replaces nut K617080) #10-32

1шт.

21

K951959

BRAKE LINE

PIPE - master cylinder outlet, right-hand, used with 885Q and 885Sk tractors, no longer available

1шт.

21

K201759

BRAKE

PIPE - master cylinder outlet, right-hand, used with 885LP tractor, no longer available

1шт.

22

K652091

FITTING

TEE - no longer available

1шт.

23

K602845

BOLT,Hex Hd, 5/16"-18 x 3/4"

SCREW - hex, 5/16 NC x 3/4 inch, tee to bulkhead

1шт.

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, , tee to bulkhead (Replaces washer K19481) 5/16"

1шт.

24

K951976

LIGHT SWITCH

SWITCH - stop lamps, Lucas 30874A

1шт.

25

K954390

PIPE

- tee to balance valve, used with 885Q tractors, no longer available

1шт.

25

K954501

BRAKE

PIPE - tee to balance valve, used with 885Sk tractors, no longer available

1шт.

25

K201761

BRAKE

PIPE - tee to balance valve, used with 885LP tractors, no longer available

1шт.

26

K954391

BRAKE

PIPE - master cylinder to balance valve, used with 885Q tractors, no longer available

1шт.

26

K954502

BRAKE

PIPE - master cylinder to balance valve, used with 885Sk tractors, no longer available

1шт.

26

K201760

BRAKE

PIPE - master cylinder to balance valve, used with 885LP tractors, no longer available

1шт.

27

K625008

CLIP

- brake pipe

2шт.

28

K954407

BRACKET

- pipe clip, no longer available

1шт.

29

K952209

PIPE

BLOCK - packing, brake pipes, no longer available

1шт.

30

K950547

VALVE

- balance, Girling 73067018, no longer available

1шт.

31

413-432

BOLT,Hex, 1/4" - 20 x 2", Gr 5

Valve to cab (Replaces bolt K600152) Hex, 1/4"-20 x 2", G5

1шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, , Valve to cab (Replaces washer K626341) 1/4"

1шт.

32

K952451

PIPE

- flexible, 12 mm x 22 inch (559 mm) long, used with 885Q and 885Sk tractors, no longer available

2шт.

32

K200143

PIPE

- flexible, 12 mm x 11 inch (279 mm) long, used with 885LP tractors, no longer available

1шт.

K652100

LOCK NUT

- lock, 12 mm

2шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, (Replaces washer K626345) 1/2"

2шт.

33

K951919

BRACKET

- brake pipes, used with 885Q and 885Sk tractors, no longer available

1шт.

33

K201614

BRACKET

- brake pipes, used with 885LP tractors, no longer available

1шт.

413-614

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

Bracket to axle (Replaces bolt K602903) Hex, 3/8"-16 x 7/8", G5, Full Thd

1шт.

492-11038

LOCK WASHER,3/8"

bracket to axle (Replaces washer K19482) 3/8"

1шт.

34

K951281

PIPE

- left-hand slave cylinder, used with 885Q and 885Sk tractors, no longer available

1шт.

34

K201907

BRAKE

PIPE - left-hand slave cylinder, used with 885LP tractors, no longer available

1шт.

35

K951282

PIPE

- right-hand slave cylinder, used with 885Q and 885Sk tractors, no longer available

1шт.

35

K201906

BRAKE

PIPE - right-hand slave cylinder, used with 885LP tractors, no longer available

1шт.

36

K950557

CYLINDER

- slave, Girling 73067020, no longer available

2шт.

K964534

SCREW,M12 x 1

- bleed, M12

2шт.

K964572

SEAL KIT

- seal, mineral oil, master cylinder

2шт.

K964573

SEAL KIT

- seal, mineral oil, slave cylinder

2шт.

Выбрано товаров: 65
