Запчасти Case IH 885 (G12) - BRAKES, FRONT WHEEL BRAKES, 885 TRACTORS, OPTIONAL EQUIPMENT (5.1) - BRAKES

1

K972798

BEAM

COMPENSATOR BEAM

1шт.

2

K971935

ROD

PUSH ROD

1шт.

3

K971936

SHIM

Retaining plate

1шт.

4

K613982

SCREW

SETSCREW, No. 10 UNF x 3/8 in

2шт.

K19488

SPRING WASHER

SPRING WASHER, 3/16 in

2шт.

5

K971937

SLEEVE

ADJUSTING SLEEVE, short

1шт.

K617051

NUT

LOCKNUT, 5/16 UNF

2шт.

6

K943521

CYLINDER

MASTER CYLINDER, (Girling 64067685)

1шт.

7

K972640

CAP

RUBBER CAP, master cylinder

1шт.

8

K602806

BOLT

SETSCREW, 5/16 UNC x 1-1/8 in

2шт.

K19481

SPRING WASHER

SPRING WASHER, 5/16 in

2шт.

9635082

NUT,5/16" - 18, Gr 5

5/16 UNC

2шт.

9

K940532

PIPE

master, Serial Range: cylinder-tee-piece

1шт.

10

K19932

RING

CLIP, pipe to frame platform

1шт.

K19388

SETSCREW, 2 BA x 1/2 in

1шт.

K11109

NUT

2 BA

1шт.

11

K972200

3 WAY CONNECTION

TEE-PIECE

1шт.

12

K920206

LIGHT SWITCH

SWITCH, stop lamps (Lucas 54337405)

1шт.

13

K972887

COVER

stop lamp switch

1шт.

14

K972838

SUPPORT

PLATE, tee-piece

1шт.

15

9627874

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5, Full Thd

SETSCREW, 5/16 UNC x 5/8 in, plate to tee-piece

1шт.

K19481

SPRING WASHER

SPRING WASHER, 5/8 in, Serial Range: plate-tee-piece

1шт.

9635082

NUT,5/16" - 18, Gr 5

5/16 UNC, plate to tee-piece

1шт.

K19471

WASHER

5/16 in, Serial Range: plate-sump

2шт.

16

K972378

PIPE

, Serial Range: tee-piece-hose

1шт.

17

K14393

CABLE

CLIP, Serial Range: pipes-sump

2шт.

18

K602807

SCREW

SETSCREW, 5/16 UNC x 1-1/4 in, Serial Range: pipes-sump

2шт.

K19481

SPRING WASHER

SPRING WASHER, 5/16 in, Serial Range: pipes-sump

2шт.

K627020

BUSHING

DISTANCE PIECE, Serial Range: pipes-sump

2шт.

19

K945038

BRACKET, hose

1шт.

20

K603306

BOLT

SETSCREW, 5/8 UNC x 1-1/2 in, Serial Range: bracket-frame

1шт.

K19485

WASHER

SPRING WASHER, 5/8 in, Serial Range: bracket-frame

1шт.

21

K972385

HOSE

FLEXIBLE PIPE

1шт.

K626447

WASHER

COPPER WASHER, 3/8 in

1шт.

K617052

NUT

LOCKNUT, 3/8 UNF

1шт.

K626479

WASHER

3/8 in

1шт.

22

K972194

FITTING

TEE-PIECE

1шт.

23

K627020

BUSHING

DISTANCE PIECE, Serial Range: tee-piece-bracket

1шт.

24

K600006

BOLT

1/4 UNC x 1-1/2 in, Serial Range: tee-piece-bracket

1шт.

K19480

SPRING WASHER

SPRING WASHER, 1/4 in, Serial Range: tee-piece-bracket

1шт.

K607000

NUT

1/4 UNC, Serial Range: tee-piece-bracket

1шт.

25

K943541

PIPE

left-hand

1шт.

26

K19932

RING

CLIP, Serial Range: pipe-axle

1шт.

27

K11189

SCREW

3/16 Whitworth x 1/2 in, Serial Range: pipe-axle

1шт.

K19488

SPRING WASHER

SPRING WASHER, 3/16 in, Serial Range: pipe-axle

1шт.

K19415

NUT

3/4 Whitworth, Serial Range: pipe-axle

1шт.

28

K953691

SUPPORT

BRACKET, left-hand, replaces K972441

1шт.

29

K972385

HOSE

FLEXIBLE PIPE

1шт.

K626447

WASHER

COPPER WASHER, 3/8 in

1шт.

K617052

NUT

3/8 UNF

1шт.

K626479

WASHER

3/8 in

1шт.

30

K943543

PIPE

right-hand

1шт.

31

K953701

SUPPORT

BRACKET, right-hand, replaces K943540

1шт.

32

K972385

HOSE

FLEXIBLE PIPE

1шт.

K626447

WASHER

copper washer, 3/8 in

1шт.

K617052

NUT

locknut, 3/8 UNF

1шт.

K626479

WASHER

3/8 in

1шт.

33

K943507

BRAKE

assembly, left-hand, (Girling 64027186), Includes: Ref. 33A - 41

1шт.

K943508

BRAKE

assembly, right-hand, (Girling 64027188), Includes: Ref. 33A - 41

1шт.

33a

K964506

PLATE

back plate, left-hand (Girling 64270176)

1шт.

33b

K964507

PLATE

back plate, right-hand (Girling 64270177)

1шт.

34

K964516

CAM

snail cam kit (Girling GA11)

1шт.

35a

K964511

WHEEL

cylinder, left-hand (Girling 390073W) (1-1/4")

1шт.

35b

K964512

WHEEL

cylinder, right-hand (Girling 390072W) (1-1/4")

1шт.

K964513

KIT

seal kit, wheel cylinder (Girling SP2051)

1шт.

36

K964519

SCREW

vent screw, 3/8 UNF

1шт.

K964515

NUT

locknut (Girling 64100031), Serial Range: cylinder-backplate

2шт.

K964514

SPRING

washer (Girling 40S32), Serial Range: cylinder-backplate

2шт.

37a

K964508

SHOE

brake shoes, pair, left-hand (Girling 64373880/4)

1шт.

37b

K964505

SHOE

brake shoes, pair, right-hand (Girling 64373882/4)

1шт.

In the heading on Figure G13, Front Wheel Brakes is not applicable.

1шт.

38

K964517

PLATE

anchor plate, brake shoe (Girling 64374134)

1шт.

39

K964518

SCREW

setscrew, anchor plate (Girling 64225091)

2шт.

40

K964509

SPRING

shoe to backplate (Girling 64375240)

1шт.

41

K964510

SPRING

shoe to shoe (Girling 64372716)

1шт.

42

K600503

BOLT

3/8 UNC x 1-1/16 in, brakes to stub axles

12шт.

232-1416

LOCK NUT,3/8"-16, GC

Nyloc nut, 3/8 UNC, brakes to stub axles

12шт.

43

K943502

BRAKE

drum, 10 in dia.

2шт.

44

K604210

SCREW

1/2 UNC x 1-3/8 in, Serial Range: drum-hub

4шт.

The description Frt Wheel Brakes in the heading of page G13b is not applicable. 10/17-95

1шт.

K954144

Girling brake fluid, UNIVERSAL

1шт.
