Запчасти Case IH 885 (8-32) - SINGLE RATE SENSING UNIT (08) - HYDRAULICS

1

K202576

CASE

HOUSING - sensing unit, used with 885, 885H, 885Q, 885QH and 885Sk tractors (Replaces housing K915092)

1шт.

1

K942825

SPRING

HOUSING - sensing unit, used with 885N tractors, no longer available

1шт.

1

K915111

SPRING

HOUSING - sensing unit, used with 885G tractors, no longer available

1шт.

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , straight, taper (Replaces fitting K13176) 1/4"-28 NPT x .54" lg

1шт.

2

K926451

GASKET,0.56mm Thk

- housing

1шт.

3

413-832

BOLT,Hex, 1/2" - 13 x 2", Gr 5

(Replaces bolt K600806) Hex, 1/2"-13 x 2", G5

4шт.

4

413-852

BOLT,Hex, 1/2" - 13 x 3-1/4", Gr 5

- hex, 1/2 NC x 3-1/4 inch, one used with 885, 885H, 885Q, 885QH, 885Sk and 885G tractors, two used with 885N tractors (Replaces bolt K600815)

1шт.

4

413-844

BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 5

- hex, 1/2 NC x 2-3/4 inch, used with 885N tractors

1шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, (Replaces washer K19484) 1/2"

6шт.

5

41-3038

PLUG,Exp, 2 3/8"

- core (Replaces plug K623813) Exp, 2 3/8"

1шт.

6

K912371

CABLE

SUPPORT - cable, outer

1шт.

7

K913852

LARGE PIN

SUPPORT - cable, inner

1шт.

8

K915258

SHAFT

- housing

1шт.

9

37-1636

DOWEL,3/8" x 2 1/4"

PIN - dowel, 3/8 x 2-1/4 inch, hardened (Replaces pin K915117)

1шт.

10

K915266

COLLAR

- housing

1шт.

11

K915101

WASHER

- thrust, 0.375 inch

1шт.

11

K915112

WASHER

- thrust, 0.355 inch, no longer available

1шт.

11

K915113

WASHER

- thrust, 0.365 inch

1шт.

11

K915114

WASHER

- thrust, 0.385 inch, no longer available

1шт.

11

K915115

WASHER

- thrust, 0.395 inch, no longer available

1шт.

11

K915116

WASHER

- thrust, 0.405 inch

1шт.

12

K915263

SPRING

- housing

1шт.

13

K915262

SLEEVE

- shaft

1шт.

14

K623556

O-RING,0.139" Thk x 1.859" ID, -225, Cl 5, 75 Duro

- internal, 1-7/8 inch diameter

1шт.

15

K915261

FLANGE

PLATE - end

1шт.

16

K915096

SHIM,.005" Thk

1шт.

16

K915097

SHIM,.010" Thk

1шт.

16

K915098

SHIM,.030" Thk

1шт.

17

413-618

BOLT,Hex, 3/8" - 16 x 1-1/8", Gr 5

(Replaces bolt K602905) Hex, 3/8"-16 x 1 1/8", G5, Full Thd

4шт.

492-11038

LOCK WASHER,3/8"

(Replaces washer K19482) 3/8"

4шт.

18

K912373

CABLE

- with dirt excluder, used with 885, 885H, 885Q, 885QH, 885Sk and 885G tractors (Replaces cable K962896)

1шт.

18

K963493

LINK

CABLE - with dirt excluder, used with 885N tractors

1шт.

19

K911970

BOOT

EXCLUDER - dirt

1шт.

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , straight, taper (Replaces fitting K13176) 1/4"-28 NPT x .54" lg

1шт.

20

K690702

O-RING,1.59mm Thk x 6.75mm ID, 80 Duro

- internal, 1/4 inch diameter

1шт.
