Запчасти Case IH 885 (4-14) - HEADLAMPS AND REAR FLOODLAMPS (04) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 885 - (4-14) - HEADLAMPS AND REAR FLOODLAMPS (04) - ELECTRICAL SYSTEMS
16
4
17
14
18
6
16
5
14
15
19
17
7
18
9
8
15
19
1
3
13
20
12
10
11
2
20

Артикул

Название

Примечание

Количество

K915874

HEADLAMP

ASSEMBLY - double filament, Lucas 54051293, inboard headlamps, except tractors for Germany, no longer available, order beam 3072947R91, mounting K961759 and Ref. 37 - 40, Includes: Ref. 1 - 3

2шт.

K917233

LAMP

HEADLAMP ASSEMBLY - Hella 105s3-7, inboard headlamps, tractors for Germany only, no longer available, Includes: Ref. 1 - 3

2шт.

1

3072947R91

HEADLIGHT

BEAM - sealed, 12 volt, 40/40 watt, inboard headlamps, except tractors for Germany (Replaces unit K962146)

1шт.

2

K961759

MOUNTING PARTS

MOUNTING - rubber, inboard headlamps, except tractors for Germany

1шт.

3

K962345

KIT

- mounting, includes Spire nut and screws, inboard headlamps, except tractors for Germany, no longer available as a kit, order Ref. 37 - 40

1шт.

4

K604042

SCREW

- hex, No. 8 NC x 3/4 inch

4шт.

492-11010

LOCK WASHER,#10

WASHER, LOCK, , Inboard headlamps, tractors for Germany only #10

4шт.

225-14108

NUT,#8-32

- hex, No. 8 NC, inboard headlamps, tractors for Germany only

4шт.

K962769

LAMP

HEADLAMP ASSEMBLY - left-hand, outboard headlamps (Replaces headlamp K921082), Includes: Ref. 6 - 15

1шт.

5

K962770

LAMP

HEADLAMP ASSEMBLY - right-hand, outboard headlamps (Replaces headlamp K921083), Includes: Ref. 6 - 15

1шт.

6

K962349

BEZEL

RIM - headlamp, outboard headlamps

1шт.

7

K963481

DOOR

CATCH - rim, outboard headlamps (Replaces catch K960879)

1шт.

8

K960898

GASKET

- lens to rim, outboard headlamps, no longer available

1шт.

9

K960892

LENS

- outboard headlamps

1шт.

10

K960874

GASKET

- lens to reflector, outboard headlamps

1шт.

11

K960876

SPRING

RETAINER - spring, outboard headlamps

5шт.

12

K963546

REFLECTOR

- headlamp, outboard headlamps

1шт.

13

K963843

CONTACT

PLATE - center, with contacts, outboard headlamps (Replaces plate K963547)

1шт.

14

K963480

SCREW

- hex, rim catch, outboard headlamps

1шт.

15

K963855

CATCH

- rim retaining, outboard headlamps (Replaces catch K961612)

1шт.

16

K961613

PEDESTAL

- headlamp, outboard headlamps, no longer available

1шт.

17

K961614

NUT

- special, 9/16 inch, no longer available

1шт.

K944729

LAMP

HEADLAMP ASSEMBLY - left-hand, white bulb, outboard European headlamps, no longer available, Includes: Ref. 19 - 26, Washer, and Nut

1шт.

18

K944730

LAMP

HEADLAMP ASSEMBLY - right-hand, white bulb, outboard European headlamps, no longer available, Includes: Ref. 19 - 26, Washer, and Nut

1шт.

K944731

LAMP

HEADLAMP ASSEMBLY - left-hand, yellow bulb, outboard European headlamps, no longer available, Includes: Ref. 19 - 26, Washer, and Nut

1шт.

18

K944732

LAMP

HEADLAMP ASSEMBLY - right-hand, yellow bulb, outboard European headlamps, no longer available, Includes: Ref. 19 - 26, Washer, and Nut

1шт.

19

K962349

BEZEL

RIM - headlamp, outboard European headlamps

1шт.

20

K963481

DOOR

CATCH - rim, outboard European headlamps

1шт.

21

K963482

LIGHT ASSY.

REFLECTOR - headlamp, includes lens, outboard European headlamps, no longer available

1шт.

22

K960876

SPRING

RETAINER - spring, outboard European headlamps

5шт.

K944742

BULB

TUBE - bulb, No. B268, outboard European headlamps

1шт.

23

K963482

LIGHT ASSY.

SPRING - bulb retaining, outboard European headlamps, no longer available (Replaces spring K963485)

1шт.

24

K963480

SCREW

- hex, rim catch, outboard European headlamps

1шт.

25

K963855

CATCH

- rim retaining, outboard European headlamps (Replaces catch K961612)

1шт.

26

K961613

PEDESTAL

- headlamp, outboard European headlamps, no longer available

1шт.

K963483

WASHER

- shakeproof, 9/16 inch, outboard European headlamps, no longer available

1шт.

K961614

NUT

- special, 9/16 inch, no longer available

1шт.

27

K943977

LAMP

FLOODLAMP ASSEMBLY - rear, no longer available, order floodlamp A151886, Ref. 36

1шт.

28

K962620

LIGHT SWITCH

SWITCH - floodlamp

1шт.

K961082

NUT

- switch retaining, no longer available

1шт.

29

K962621

COVER ASSY

COVER - rubber, switch

1шт.

30

K963843

CONTACT

PLATE - center, includes contacts (Replaces plate K963547)

1шт.

31

K962334

LENS

- floodlamp

1шт.

32

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

- hex, 1/2 NC x 1-1/4 inch (Replaces bolt K603141)

1шт.

33

K627067

BUSHING

SPACER - distance, no longer available

1шт.

493-21052

LOCK WASHER,Int Tooth, 1/2"

WASHER - internal tooth lock, 1/2 inch (Replaces washer K626510)

1шт.

425-108

NUT,1/2" - 13, Gr 5

NUT, (Replaces nut K607047) 1/2"-13, G5

1шт.

34

K955726

BRACKET

- support, floodlamp, no longer available

1шт.

34

K953060

BRACKET

- support, floodlamp, no longer available

1шт.

35

K602846

SCREW,5/16" - 18 x 5/8", Gr S

BOLT - hex, 5/16 NC x 5/8 inch, bracket to cab, tractor serial number 11010300 and after

2шт.

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, , bracket to cab, tractor serial number 11010300 and after (Replaces washer K19481) 5/16"

2шт.

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC, bracket to cab, tractor S/N 11010300 and after (Replaces nut K607044)

2шт.

K955727

GROMMET

- floodlamp cable, bracket to cab, tractor serial number 11010300 and after, no longer available

1шт.

35

413-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5

Bracket to fender, Tractor S/N'S prior to 11010300 (Replaces bolt K603138) Hex, 1/2"-13 x 1", G5, Full Thd

1шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, , Bracket to fender, tractor serial numbers prior to 11010300 (Replaces washer K626345) 1/2"

1шт.

425-108

NUT,1/2" - 13, Gr 5

NUT, , Bracket to fender, tractor S/N's prior to 11010300 (Replaces nut K607047) 1/2"-13, G5

1шт.

K627705

GROMMET

- floodlamp, 1/2 inch, bracket to fender, tractor serial numbers prior to 11010300, no longer available

1шт.

36

A151886

LAMP

FLOODLAMP - rear, with on/off switch (Replaces floodlamp assembly K943977)

1шт.

37

K962600

SCREW

- headlamp, not shown

1шт.

38

K962601

NUT

- headlamp screw, not shown

1шт.

39

K962602

SPRING

- headlamp, not shown

2шт.

40

K962603

SUPPORT

BRACKET - headlamp, not shown

2шт.

Выбрано товаров: 62
