Запчасти Case IH 885 (3-12) - FUEL TANK AND LINES, 885, 885G AND 885H TRACTORS (03) - FUEL SYSTEM
№
Артикул
Название
Примечание
Количество
1
K913384
LEVER
- hand
1шт.
2
K85546
DISC
- friction
1шт.
3
K626740
WASHER
- flat, Belleville, 5/8 inch
1шт.
K19475
WASHER
- flat, 5/8 inch
1шт.
4
K623003
NUT
- Nyloc, 5/8 BSF, no longer available
1шт.
5
K910157
WASHER
PAD - stop
2шт.
6
K605633
SCREW
- hex, 1/4 NC x 1/2 inch
2шт.
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC (Replaces nut K607043)
2шт.
493-41026
LOCK WASHER,Ext Tooth, 1/4"
WASHER - external-tooth lock, 1/4 inch
4шт.
7
K89372
LEVER
- throttle control
1шт.
8
413-422
BOLT,Hex, 1/4" - 20 x 1-3/8", Gr 5
- hex, 1/4 NC x 1-3/8 inch (Replaces bolt K600144)
1шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, (Replaces washer K19480) 1/4"
1шт.
K626662
WASHER
- flat, 1/4 inch (Replaces washer K19470)
1шт.
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC (Replaces nut K607000)
1шт.
9
K621904
BALL JOINT
BALL - end, 1/4 inch NF
2шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, (Replaces washer K19480) 1/4"
2шт.
129-121
NUT,1/4"-28, G5
(Replaces nut K617000) 1/4"-28, G5
2шт.
10
K943480
SHAFT
ROD - control, hand lever to cross shaft
1шт.
11
K908778
CLIP
- special
1шт.
12
K621903
BALL JOINT
SOCKET - end, 1/4 inch NF
1шт.
425-154
JAM NUT,Jam, 1/4"-28, G5
- hex jam, 1/4 inch NF (Replaces nut K617050)
1шт.
13
K928177
LEVER
- throttle control
1шт.
14
K943480
SHAFT
- cross
1шт.
K19472
WASHER
- special, 3/8 inch
1шт.
100-3337
SNAP RING,E-Type, 0.3" OD
Ring, Retaining, (Replaces ring A27795) #37, .300" Dia, E-Type
1шт.
15
K943483
BRACKET
- guide , no longer available
2шт.
16
413-410
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
- hex, 1/4 NC x 5/8 inch, bracket to tank support
4шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, , Bracket to tank support 1/4"
4шт.
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch, bracket to tank support (Replaces nut K607000)
4шт.
17
K928178
LEVER
- throttle control
1шт.
18
135-735
GROOVED PIN,5/32" x 3/4", Type E
Pin, Grooved, (Replaces pin K623747) 5/32" x 3/4", Type E
2шт.
19
K943877
ROD
- cross, Serial Range: shaft-pedal
1шт.
K626662
WASHER
- flat, 1/4 inch (Replaces washer K19470)
4шт.
20
K624928
SPRING
- throttle control
1шт.
21
K942651
SHIM
BRACKET - anchor
1шт.
22
K940308
PEDAL
- accelerator
1шт.
219-8
LUBE NIPPLE,1/4" - 28 NPTF
NIPPLE, LUBE, , straight, taper (Replaces fitting K13176) 1/4"-28 NPT x .54" lg
1шт.
K626662
WASHER
- flat, 1/4 inch (Replaces washer K626440)
1шт.
K626738
WASHER
SHIM - throttle control, 0.030 inch
1шт.
K626716
WASHER
- special, 7/8 inch, no longer available
1шт.
23
100-1187
SNAP RING,#87, Ext
Ring, Snap, (Replaces K34454) #87, Ext
1шт.
24
K610252
BOLT
- hex, 1/4 NF x 1-1/16 inch, tractor serial number 11005914 and after, no longer available
1шт.
25-154
JAM NUT,Jam, 1/4"-28, G5
1шт.
24
K620500
BOLT
- special, 1/4 BSF, tractor serial numbers, Serial Range: prior-11005914
1шт.
K19440
NUT
- lock, 1/4 BSF, if used
1шт.
25
K943463
CABLE
- throttle control, inner and outer
1шт.
26
K605605
SCREW
- hex, 1/4 NC x 5/8 inch, cable to tank support, no longer available
1шт.
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC, cable to tank support (Replaces nut K607000)
1шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, , Cable to tank support (Replaces washer K19480) 1/4"
1шт.
27
K12189
SCREW
- hex, 2 BA x 1/2 inch
1шт.
492-11010
LOCK WASHER,#10
WASHER, LOCK, (Replaces washer K19488) #10
1шт.
K11109
NUT
- hex, 2 inch BA
1шт.
28
K621901
BALL JOINT
SOCKET - end, N0. 10 NF
1шт.
29
K624926
SPRING
- return, cross shaft
1шт.
30
K624938
SPRING
- return, pump lever
1шт.
31
K617500
NUT
- special, 1/4 inch NF, spring anchor, no longer available
1шт.
32
K621901
BALL JOINT
SOCKET - end, No. 10 NF
1шт.
33
K621904
BALL JOINT
BALL - end, 1/4 inch NF
1шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, (Replaces washer K19480) 1/4"
1шт.
25-114
NUT,1/4"-28, G5
- hex, 1/4 inch NF (Replaces nut K617000)
1шт.
Выбрано товаров: 63
