Запчасти Case IH 880UE (30) - TRANSMISSION / DRIVESHAFT & GEARS / LAYSHAFT / BEVEL PINION SHAFT Gearbox
№
Артикул
Название
Примечание
Количество
K923116
BOX
TRANSMISSION, 6-speed (complete, 880/UE with differential)
1шт.
K961021
TRANSMISSION (complete with, 880/UF differential)
1шт.
K961062
TRANSMISSION, 12-speed (complete, 880/UE with differential)
1шт.
1
K905675
SPARE PART
END PLATE - front 6-speed
1шт.
K908303
SPARE PART
END PLATE - front 12-speed
1шт.
2
K961022
NO LONGER SERVICED
END PLATE - rear (complete with bearing caps)
1шт.
3
K608604
STUD, special - cap 961022
4шт.
4
425-1010
NUT,5/8"-11, G5
961022 5/8"-11, G5
4шт.
5
K626389
BEARING WASHER
TAB WASHER 961022
4шт.
6
K906240
BAR
SPACING BAR - top 6-speed
2шт.
K908389
BAR
SPACING BAR - top 12-speed
2шт.
7
K906241
BAR
SPACING BAR - bottom 6-speed
2шт.
K908390
BAR
SPACING BAR - bottom, left-hand 12-speed
1шт.
K908391
BAR
SPACING BAR - bottom, right-hand 12-speed
1шт.
8
K607331
NUT
NYLOC NUT
6шт.
9
K910522
STUD
DOWEL
2шт.
10
K601306
BOLT
special
4шт.
11
K903454
BOLT
BUSH - end plates
4шт.
K88929
SHIM,.003" Thk
6-speed .003" Thk
1шт.
12
K966345
SHIM,.005" Thk
6-speed .005" Thk
1шт.
K88931
SHIM,.007" Thk
6-speed .007" Thk
1шт.
13
K19081
BALL BEARING
6-speed
1шт.
15
K12922
RING, SNAP
CIRCLIP 6-speed
1шт.
16
K906606
GEAR
RANGE PINION (19/30 teeth) 6-speed
1шт.
K906606
GEAR
RANGE PINION (19/30 teeth) 12-speed
1шт.
17
K13809
RING, SNAP
CIRCLIP
1шт.
18
K85241
CARRIER
BUSH - reverse gear
1шт.
19
K963536
GEAR
REVERSE GEAR (25 teeth) and bush
1шт.
20
K24773
BUSHING
Bearing - reverse gear
1шт.
21
K908940
WASHER
THRUST WASHER
1шт.
22
K34594
PIN
1шт.
23
K903455
DRIVE SHAFT
(6-speed) 880/UE
1шт.
K908370
DRIVE SHAFT
(12-speed) 880/UE
1шт.
24
K913176
SHAFT
LIVE PTO CARDAN SHAFT (6-speed) 880/UE
1шт.
K913176
SHAFT
LIVE PTO CARDAN SHAFT (12-speed) 880/UE
1шт.
25
K89181
COUPLING, BREAK AWAY
COUPLING SLEEVE 880/UE
1шт.
26
K600141
BOLT
1/4 UNC x 1 7/8 in. 880/UE
1шт.
231-1444
NUT,1/4"-20, GB
SLOTTED NUT, 1/4 UNC 880/UE
1шт.
K19522
PIN
SPLIT PIN 880/UE
1шт.
27
K903456
DRIVE SHAFT
880/UF
1шт.
28
P30369
O-RING
COUPLING SLEEVE 880/UF
1шт.
29
K600317
BOLT
5/16 UNC x 2 1/4 in. 880/UF
1шт.
K607101
NUT
SLOTTED NUT, 5/16 UNC 880/UF
1шт.
K19522
PIN
SPLIT PIN 880/UF
1шт.
30
K908161
GEAR
LAYSHAFT WITH INTEGRAL GEARS
1шт.
K88921
SHIM,.003" Thk
1шт.
K88922
SHIM,.005" Thk
1шт.
K88923
SHIM,.007" Thk
1шт.
K88924
SHIM,.010" Thk
1шт.
31
K19158
ROLLER
BEARING
2шт.
32
K623317
LOCK NUT
NYLOC NUT, 1 1/8 BSF, left-hand
2шт.
33
K14687
WASHER
1 1/8 in.
1шт.
34
K24546
BEARING, ROLLER
TAPER ROLLER BEARING
2шт.
35
K81984
BUSHING
DISTANCE PIECE
1шт.
K81985
SHIM,.002" Thk
1шт.
36
K966329
SET
SHIM, .003 in.
1шт.
K966330
SHIM,.005" Thk
1шт.
37
K905677
BEARING
HOUSING 6-speed
1шт.
K908380
BEARING
HOUSING 12-speed
1шт.
38
K30449
SHIM
S - sets: .003 in. (3), .005 in. (1), 015 in. (1), .030 in. (1)
1шт.
39
413-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
SETSCREW, 3/8 UNC x 1 1/4 in. 6-speed
6шт.
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
SETSCREW, 3/8 UNC x 1 in. 12-speed
6шт.
492-11038
LOCK WASHER,3/8"
6шт.
40
K906604
GEAR
DRIVEN GEAR - high and medium (31/40 teeth)
1шт.
41
K906605
GEAR
DRIVEN GEAR - low (47 teeth)
1шт.
42
K621438
RING, SNAP
CIRCLIP, 1 7/8 in.
1шт.
43
K19138
BEARING, ROLLER
ROLLER BEARING
1шт.
44
K600008
BOLT
1/4 UNC x 1 3/4 in.
1шт.
231-1444
NUT,1/4"-20, GB
NUT, LOCK, 1/4"-20, GB
1шт.
45
K929086
WASHER
SPECIAL WASHER
2шт.
46
K962047
GEAR
BEVEL PINION AND SPIRAL GEAR (7/43 teeth)
1шт.
K908499
BUSHING
DISTANCE PIECE - bevel pinion, 12-speed
1шт.
Выбрано товаров: 73
