Запчасти Case IH 880UE (60) - FOOT THROTTLE CONTROL (U584) (OPTIONAL EQUIPMENT) Engine Controls & Instruments

Схема запчастей Case IH 880UE - (60) - FOOT THROTTLE CONTROL (U584) (OPTIONAL EQUIPMENT) Engine Controls & Instruments
8
26
12
9
18
25
10
1
15
5
17
16
7
10
19
6
24
26
2
4
11
21
29
3
20
27
23
22
27
13
9
28
14

Артикул

Название

Примечание

Количество

1

K913191

LEVER

HAND LEVER

1шт.

2

K85546

DISC

FRICTION DISC

1шт.

3

K626740

WASHER

BELLEVILLE WASHER

1шт.

K19475

WASHER

5/8 in.

1шт.

4

K623003

NUT

NYLOC NUT, 5/8 BSF

1шт.

5

K910157

WASHER

STOP PAD

2шт.

6

K603925

SCREW,Pan, 1/4" - 20 x 5/8"

1/4 UNC x 1/2 in.

2шт.

K607000

NUT

1/4 UNC

2шт.

K19480

SPRING WASHER

SPRING WASHER, 1/4 in.

2шт.

7

K900025

LEVER

1шт.

8

K600005

BOLT

1/4 UNC x 1 3/8 in.

2шт.

K607000

NUT

1/4 UNC

2шт.

K19480

SPRING WASHER

SPRING WASHER, 1/4 in.

2шт.

9

K900024

PIN

PIVOT PIN

2шт.

10

K966550

CLIP

E' CLIP, 1/4 in.

20шт.

11

K913295

ROD

- lever to cross shaft

1шт.

12

K625260

SPRING

1шт.

K607000

NUT

1/4 UNC

1шт.

425-144

JAM NUT,Jam, 1/4"-20, G5

LOCKNUT, 1/4 UNC

1шт.

13

K908778

CLIP

special

2шт.

14

K900015

PEDAL

ACCELERATOR PEDAL

1шт.

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg

1шт.

K626662

WASHER

COPPER WASHER - grease nipple

1шт.

15

K620500

BOLT

special, 1/4 BSF x 1 1/8 in.

1шт.

K966191

NUT

LOCKNUT, 1/4 BSF

10шт.

16

K900016

CLUTCH

EXTENSION - clutch cross shaft

1шт.

17

K600417

BOLT

STUD, 3/8 UNC x 3 3/4 in.

1шт.

18

K88751

WASHER

special

1шт.

425-106

NUT,3/8"-16, Cl 5

1шт.

492-11038

LOCK WASHER,3/8"

1шт.

19

K30332

SPRING

1шт.

20

K900017

BRACKET

ANCHOR BRACKET - spring

1шт.

21

K603002

BOLT (SPREADER)

SETSCREW, 7/16 UNC x 7/8 in.

1шт.

K19483

SPRING WASHER

SPRING WASHER, 7/16 in.

1шт.

22

K913296

ROD

- pedal to cross shaft

1шт.

K626662

WASHER

1/4 in.

1шт.

23

K912143

LEVER

- cross shaft

1шт.

24

K913227

SHAFT

CROSS SHAFT

1шт.

25

K923228

CABLE

- inner and outer (throttle control)

1шт.

26

225-14210

NUT,#10-32

2шт.

27

K621900

UNIVERSAL JOINT

BALL JOINT

2шт.

K607000

NUT

1/4 UNC

2шт.

K19480

SPRING WASHER

SPRING WASHER, 1/4 in.

2шт.

28

K624938

SPRING

1шт.

29

K617500

NUT

- spring anchor

1шт.

Выбрано товаров: 45
