Запчасти Case IH 880F (60) - FOOT THROTTLE CONTROL (U584), (OPTIONAL EQUIPMENT) Engine Controls & Instruments
№
Артикул
Название
Примечание
Количество
K911141
FOOT THROTTLE CONTROL (U584) (Optional Equipment)
1шт.
1
K913191
LEVER
HAND LEVER
1шт.
2
K85546
DISC
FRICTION DISC
1шт.
3
K626740
WASHER
BELLEVILLE WASHER
1шт.
K19475
WASHER
5/8 in.
1шт.
4
K623003
NUT
NYLON NUT, 5/8 BSF
1шт.
5
K910157
WASHER
STOP PAD
2шт.
6
K603925
SCREW,Pan, 1/4" - 20 x 5/8"
1/4 UNC x 1/2 in.
2шт.
K607000
NUT
1/4 UNC
2шт.
K19480
SPRING WASHER
SPRING WASHER, 1/4 in.
2шт.
7
K900025
LEVER
1шт.
8
K600005
BOLT
1/4 UNC x 1 3/8 in.
2шт.
K607000
NUT
1/4 UNC
2шт.
K19480
SPRING WASHER
SPRING WASHER, 1/4 in.
2шт.
9
K900024
PIN
PIVOT PIN
2шт.
10
K966550
CLIP
E' CLIP, 1/4 in.
20шт.
11
K913295
ROD
-lever to cross shaft
1шт.
12
K625260
SPRING
1шт.
K607000
NUT
1/4 UNC
1шт.
425-144
JAM NUT,Jam, 1/4"-20, G5
LOCKNUT, 1/4 UNC
1шт.
13
K908778
CLIP
special
2шт.
14
K900015
PEDAL
ACCELERATOR PEDAL
1шт.
219-8
LUBE NIPPLE,1/4" - 28 NPTF
NIPPLE, LUBE, , ANF 1/4"-28 NPT x .54" lg
1шт.
K626662
WASHER
COPPER WASHER-grease nipple
1шт.
15
K620500
BOLT
special, 1/4 BSF x 1 1/8 in.
1шт.
K966191
NUT
LOCKNUT, 1/4 BSF
10шт.
16
K900016
CLUTCH
EXTENSION-clutch cross shaft
1шт.
17
K600417
BOLT
STUD, 3/8 UNC x 3 3/4 in.
1шт.
18
K88751
WASHER
special
1шт.
425-106
NUT,3/8"-16, Cl 5
1шт.
492-11038
LOCK WASHER,3/8"
1шт.
19
K30332
SPRING
1шт.
20
K900017
BRACKET
ANCHOR BRACKET-spring
1шт.
21
K603002
BOLT (SPREADER)
SETSCREW, 7/16 UNC x 7/8 in.
1шт.
K19483
SPRING WASHER
SPRING WASHER, 7/16 in.
1шт.
22
K913296
ROD
-pedal to cross shaft
1шт.
K626662
WASHER
1/4 in.
1шт.
23
K912143
LEVER
-cross shaft
1шт.
24
K913227
SHAFT
CROSS SHAFT
1шт.
25
K923228
CABLE
-inner and outer (throttle control)
1шт.
27
K621900
UNIVERSAL JOINT
BALL JOINT
2шт.
K607000
NUT
1/4 UNC
2шт.
K19480
SPRING WASHER
SPRING WASHER, 1/4 in.
2шт.
28
K624938
SPRING
1шт.
29
K617500
NUT
-spring anchor
1шт.
Выбрано товаров: 46
