Запчасти Case IH 880B (125) - SERVICE PARTS, PISTONS AND RINGS Service Parts

K921786

NO LONGER SERVICED

PISTON - assembly (complete with rings) (s/s 917804)

3шт.

K921787

PISTON - (not supplied separately) (supersedes 917805), 921786 .020 in. oversize

1шт.

K917806

X

PISTON - ring--No. 1 compression, 921786 .020 in. oversize

1шт.

K917807

NO LONGER SERVICED

PISTON - ring--Nos. 2 and 3 compression, 921786 .020 in. oversize

2шт.

K917808

SCRAPER

- piston ring--scraper, 921786 .020 in. oversize

1шт.

K921788

NO LONGER SERVICED

PISTON - assembly (complete with rings) (s/s 917809)

3шт.

K921789

PISTON - (not supplied separately) (supersedes 917810), 921788 040 in. oversize

1шт.

K917811

SET OF RINGS

- piston--No. 1 compression, 921788 040 in. oversize

1шт.

K917812

PISTON

- ring--Nos. 2 and 3 compression, 921788 040 in. oversize

2шт.

K917813

SCRAPER

- piston ring--scraper ,921788 040 in. oversize

1шт.

K917818

PISTON RING SET

RING SET - piston pack sets of 12 rings standard

1шт.

K917819

NO LONGER SERVICED

PISTON - ring pack sets of 12 rings .020 in. oversize

1шт.

K917820

NO LONGER SERVICED

PISTON - ring pack sets of 12 rings .040 in. oversize

1шт.

K917821

SET OF RINGS

- oil control pack sets of 12, standard rings

1шт.

K917822

X

OIL - control ring pack sets of 12, .020 in. oversize rings

1шт.

K917823

SET,PISTON RINGS+0.4

SET - piston rings, oil control pack sets of 12, .040 in. oversize rings

1шт.

K914346

RING

- sealing standard

3шт.

K917824

RING

- sealing .020 in. oversize bore

3шт.

K917825

RING

- sealing .040 in. oversize bore

3шт.

K961712

NO LONGER SERVICED

BEARING - main and big end pack, standard, crankshaft

1шт.

K961713

NO LONGER SERVICED

BEARING - main and big end pack, .010 in. undersize (less thrust washers), crankshaft

1шт.

K928557

BEARING LINER

- main, upper and lower, 961713 (supersedes 912630/1, crankshaft

8шт.

K912638

HALF-BEARING, CRANKS

BEARING SET - big end (halves) 961713, crankshaft

6шт.

K961714

NO LONGER SERVICED

BEARING - main and big end pack, .020 in. undersize (less thrust washers), crankshaft

1шт.

K928558

HALF-BEARING, CRANKS

BEARING LINER - main, upper and lower, 961714 (supersedes 912632/3), crankshaft

8шт.

K912639

HALF-BEARING, CRANKS

BEARING SET - big end (halves) 961714, crankshaft

6шт.

K961715

X

BEARING - main and big end pack, .030 in. undersize (less thrust washers), crankshaft

1шт.

K928559

HALF-BEARING, CRANKS

BEARING LINER - main, upper and lower, 961715 (supersedes 913939/40), crankshaft

8шт.

K913941

HALF-BEARING, CRANKS

BEARING LINER - big end (halves) 961715, crankshaft

6шт.

K928560

THRUST WASHER

DISC - thrust washer--upper, .005 in. oversize (replaces 908078), crankshaft bearings

2шт.

K928561

WASHER

- thrust, lower, .005 in. oversize (replaces 908079), crankshaft bearings

2шт.

K928562

WASHER, THRUST

WASHER - thrust, upper, .020 in. oversize (replaces 908080), crankshaft bearings

2шт.

K928563

RING

- thrust washer--lower, .020 in. oversize (replaces 908081), crankshaft bearings

2шт.

K928986

VALVE

- inlet and exhaust, .010 in. oversize stem, Engine No. 24645 (Livedrive) 2984 (Non-Livedrive) onward

6шт.

K928987

VALVE

- inlet and exhaust, .020 in. oversize stem, Engine No. 24645 (Livedrive) 2984 (Non-Livedrive) onward

6шт.

K914880

VALVE STEM

- inlet, .010 in. oversize stem, Engine No. 1001 to 24644 (Livedrive) 1001 to 2983 (Non-Livedrive)

3шт.

K908083

NO LONGER SERVICED

VAVLE - exhaust, .010 in. oversize stem, Engine No. 1001 to 24644 (Livedrive) 1001 to 2983 (Non-Livedrive)

3шт.

K915367

VALVE STEM

-inlet, .020 in. oversize stem, Engine No. 1001 to 24644 (Livedrive) 1001 to 2983 (Non-Livedrive)

3шт.

K915365

NO LONGER SERVICED

VALVE - exhaust, .020 in. oversize stem, Engine No. 1001 to 24644 (Livedrive) 1001 to 2983 (Non-Livedrive)

3шт.

K14411

HALF-BUSHING

HALF BUSH - stub axle .020 in. undersize, axle

1шт.

K14412

HALF-BUSHING

HALF BUSH - stub axle .040 in. undersize, axle

1шт.

K961769

PISTON ASSY. - ram, insert .020 in. oversize, cylinder

1шт.

K928986

VALVE

- inlet and exhaust .010 in. oversize, ram cylinder piston

6шт.

K928987

VALVE

- inlet and exhaust .020 in. oversize, ram cylinder piston

6шт.

K961892

GASKET KIT

KIT - engine gasket pack, service

1шт.

K961929

GASKET KIT

KIT - gasket pack--decarbonising, service

1шт.

K961770

KIT

- water pump repair pack, service

1шт.

K960595

PADDING

- brake lining (4) and rivet pack (for 903512 shoes), service

1шт.

K962283

BRAKE

- lining (4) and rivet pack (for 905264 shoes), service

1шт.

K962101

NO LONGER SERVICED

WIRING KIT - pack (complete set of harness and leads), 530001 to 544390, service

1шт.

K962322

WIRING KIT - pack (complete set of harness and leads), 544391 onward, service

1шт.

K962586

GASKET KIT

KIT - gasket, seal pack ('O' rings, anti-extrusion rings, etc.), servicd

1шт.

K960998

NO LONGER SERVICED

SEALANT - Loctite c.c. bottle, paste

10шт.

K961673

LOCQUIC - primer oz. Aerosol, sealant and paste

6шт.

K961061

MOLYBDENUM - disulphide anti-scuffing paste, lb. tin, sealant

1шт.

K961060

NO LONGER SERVICED

MOLYBDENUM - disulphide anti-scuffing paste, oz. tube, sealant

2шт.

K961838

PAINT

- (orchid white) pint Aerosol, sealant and paste

2-Janшт.

K961839

PAINT

- (polychromatic chocolate) pint Aerosol, sealant and paste

2-Janшт.

K961840

PAINT - (poppy red) pint Aerosol, sealant and pate

2-Janшт.

K961970

SPARE PART

ENGINE - unit (less dynamo, starter and clutch), AD3/55A, reconditioned service (United Kingdom only)

1шт.

K961971

ENGINE - unit (less dynamo, starter and clutch), AD3/55B, reconditioned service (United Kingdom only)

1шт.

K961753

CRANKSHAFT - bearings (less thrust washers), reconditioned service units (United Kingdom only)

1шт.

K961944

SPARE PART

TRANSFER - air cleaner, plates

1шт.

K962001

DECAL

- transfer--negative earth, plates and transfers

1шт.

K917242

DECAL

- instruction plate--quadrant, transfers

1шт.

K624090

RIVET

- 1/8 x 3/16 in., plates and transfers

2шт.

K915179

DECAL

- instruction plate--selector panel, transfers

1шт.

K614943

SCREW

- No. 10 UNF x 3/8 in., plates and transfers

2шт.

K962053

NO LONGER SERVICED

TRANSFER - lever positions (three-way valve), plates

1шт.

K924803

INDICATOR

- transfer--road speeds (MPH), 9/50 final drives, 6-speed, plates

1шт.

K924818

INDICATOR

- transfer--road speeds (KPH), 9/50 final drives, 6-speed, plates

1шт.

K924795

INDICATOR

- transfer--road speeds (MPH), 9/50 final drives, 12-speed, plates

1шт.

K924808

INDICATOR

- transfer--road speeds (KPH), 9/50 final drives, 12-speed, plates

1шт.

K924804

INDICATOR

- transfer--road speeds (MPH), 11/49 final drives, 6-speed, plates

1шт.

K924820

INDICATOR

- transfer--road speeds (KPH), 11/49 final drives, 6-speed, plates

1шт.

K924796

INDICATOR

- transfer--road speeds (MPH), 11/49 final drives, 12-speed, plates

1шт.

K924810

INDICATOR

- transfer--road speeds (KPH), 11/49 final drives, 12-speed, plates

1шт.

K921368

DECAL

- transfer--hydraulic filter warning lamp, plates

1шт.

K961999

PRODUCT GRAPHIC

- transfer--'To stop, lift rod and release', plates

1шт.

K917765

DECAL

- gear selection chart 12-speed, plates and transfers

1шт.

K24775

SCREW - self-tapping screw 12-speed, plates and transfers

1шт.

K921551

PRODUCT GRAPHIC

- transfer--'For correct belt speed use high PTO gear', plates

1шт.

K923679

NO LONGER SERVICED

TRANSFER - bonnet louvre, plates

1шт.

K962479

PRODUCT GRAPHIC

- transfer pack--bonnet, plates

1шт.

K961939

PRODUCT GRAPHIC

- transfer--'David Brown', left-hand 962479, plates

1шт.

K961941

PRODUCT GRAPHIC

- transfer--'David Brown', right-hand 962479, plates

1шт.

K961940

PRODUCT GRAPHIC

- transfer--'Selectamatic 880', left-hand, 962479, plates

1шт.

K961942

PRODUCT GRAPHIC

- transfer--'Selectamatic 880', right-hand, 962479, plates

1шт.

K961946

PRODUCT GRAPHIC

- transfer--'Livedrive' 6-speed, plates

1шт.

K961947

DECAL

- transfer--'Livedrive' 12-speed, plates

1шт.

K915177

PLATE

- transfer--hydraulic lift control, plates

1шт.

K962000

DECAL

- transfer--'Lift-lower', plates

1шт.

K961931

PRODUCT GRAPHIC

- transfer--gear positions (power take-off), plates

1шт.

K916308

PRODUCT GRAPHIC

- transfer--linkage settings, plates

1шт.

K913302

TOOLBOX - tools

1шт.

K602736

SCREW

SETSCREW - 1/4 UNC x 7/8 in., toolbox and tools

1шт.

K607043

NUT

- 1/4 UNC, toolbox and tools

1шт.

K609440

PLUG

- 5/8 UNC x 5/8 in.--toolbox to frame, tools

2шт.

280431

NUT,1/2"-13, G5

Toolbox and tools 1/2"-13, G5

2шт.

K919894

SPECIAL WRENCH

WRENCH - special, drain plug, toolbox and tools

1шт.

K922741

WALLET - tool, U1119 (918595) (toolkit--optional equipment), toolbox

1шт.

K38618

WHEEL

- brace, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K906963

SCREW

- peg--engine timing, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627607

SPANNER - 1 1/8 x 15/16 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627603

TOOL

- spanner, 3/4 x 5/8 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627604

TOOL

- spanner, 9/16 x 1/2 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627608

TOOL

- spanner, 7/16 x 5/16 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K922742

TOOL

- wrench, 10 in., adjustable, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627609

SPANNER - box, 15/16 x 3/4 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K627610

TOOL

- box spanner, 9/16 x 1/2 in. AF, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K19806

BAR

- tommy, 5/16 x 6 in., U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K922744

SCREW

DRIVER - reversible, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K19803

SCREWDRIVER - U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.

K922743

TOOL

- pliers, 7 in., insulated, U1119 (918595) (toolkit--optional equipment), toolbox and tools

1шт.
