Запчасти Case IH 880A (010) - CYLINDER HEAD (01) - ENGINE

Схема запчастей Case IH 880A - (010) - CYLINDER HEAD (01) - ENGINE
4
3
16
24
25
2
22
10
18
12
20
8
1
5
17
14
19
6
9
15
7
26
13
23
21
11

Артикул

Название

Примечание

Количество

K962566

CYLINDER

- head (with valve inserts and plugs)

1шт.

Engine No. 24645 onward (Livedrive)

1шт.

Engine No. 2984 onward (Non-Livedrive)

1шт.

1

K962583

X

CYLINDER - head (with valve inserts and plugs), supersedes 961731

1шт.

Engine No. 1001 to 24644 (Livedrive)

1шт.

Engine No. 1001 to 2983 (Non-Livedrive)

1шт.

2

K914384

GASKET

-, Serial Range: head-block

1шт.

3

K921488

COVER

- cylinder head (supersedes 907323)

1шт.

4

K907338

GASKET,3.97mm Thk

-, Serial Range: cover-head

1шт.

5

K608118

STUD

- 5/16 UNC x 3 7/16 in. cover

2шт.

6

K608111

STUD

- 5/16 UNC x 3 in cover

2шт.

K14988

WASHER

- copper asbestos, 5/16 in. cover

4шт.

7

K607252

NUT

- domed, 5/16 UNC cover

4шт.

8

K617581

NUT

- 1/2 UNF, special cylinder head

4шт.

9

K600870

BOLT

- 1/2 UNC x 4 1/4 in., special cylinder head

9шт.

10

K906898

NUT

- 1/2 UNF--lifting cylinder head

2шт.

K900431

PLUG

- taper

3шт.

11

K623810

PLUG

- welch, 1 in.

1шт.

12

K19591

PLUG

- flanged, 1/8 BSP

1шт.

K16732

WASHER

- copper, 3/8 in.

1шт.

K608203

STUD

- 3/8 UNC x 1 7/16 in.--exhaust manifold

5шт.

K608214

STUD

- 3/8 UNC x 2 in.--exhaust manifold

1шт.

13

K608107

STUD

- 5/16 UNC x 2 11/16 in.--injector

6шт.

9635082

NUT,5/16" - 18, Gr 5

- 5/16 UNC

6шт.

K19481

SPRING WASHER

WASHER - lock, spring, 5/16 in

6шт.

K921246

INSERT

- inlet seat

3шт.

Engine No. 24645 onward (Livedrive)

1шт.

Engine No. 2984 onward (Non-Livedrive)

1шт.

K921247

INSERT

- exhaust--exhaust seat

3шт.

Engine No. 24645 onward (Livedrive)

1шт.

Engine No. 2984 onward (Non-Livedrive)

1шт.

14

K905202

INSERT

- inlet seat

3шт.

K62034

INSERT

- exhaust seat

3шт.

15

K921489

COVER

- engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

16

K626901

O-RING,40554" ID x 40575" OD x 0.12"

- O-ring, 1 5/8 in. int. dia., engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

17

K920676

PIPE

HOSE - engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

18

K920677

BREATHER

BOLT - 1/2 UNF, engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

19

K13069

HOSE

- clip, engine breather (replaces 621668)

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

20

K909672

DISTRIBUTOR

- distance piece, engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

425-158

JAM NUT,Jam, 1/2"-20, G5

LOCKNUT - 1/2 UNF, Engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

K626443

WASHER

- copper, 1/2 in., engine breather

1шт.

Engine No. 355001/15561, 355002/2556 onward

1шт.

K907108

NO LONGER SERVICED

COVER - engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K626901

O-RING,40554" ID x 40575" OD x 0.12"

- O-ring, 1 5/8 in. int. dia.

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K907110

BREATHER

- element, engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K917044

BREATHER

- pipe, engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K909671

CONNECTION - engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K909672

DISTRIBUTOR

- distance piece, engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K626443

WASHER

- copper, 1/2 in. engine breather

2шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

K617371

NUT

- domed, 1/2 UNF engine breather

1шт.

Engine No. 355001/1001 to 355001/15560, 355002/1001 to 355002/2555\

1шт.

21

K912198

PIPE - water outlet

1шт.

22

K68951

O-RING,0.103" Thk x 2.112" ID, -138, Cl 5, 75 Duro

-138, 90 Duro, 2.112" ID x .103" Thk

1шт.

23

K900368

THERMOSTAT

1шт.

K910411

GASKET

1шт.

K19481

SPRING WASHER

WASHER - lock, spring, 5/16 in

2шт.

24

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

SETSCREW - 5/16 UNC x 1 in.

2шт.

25

K904195

FITTING

- connection--by-pass

1шт.

K902765

PIPE

- oil, cylinder, Serial Range: block-head

1шт.

26

K619525

PLUG

- 5/8 UNF temperature gauge aperture

1шт.

K626444

WASHER

- copper, 5/8 in. temperature gauge aperture

1шт.

Выбрано товаров: 75
