Запчасти Case IH 780 (088) - BONNET (12) - CHASSIS

1

K961886

PLATE

- bonnet assembly 961886

1шт.

2

K962015

COVER

- hatch 961886

1шт.

3

K917746

LEVER

- hatch fastener 961886

1шт.

K917748

GROMMET

- hatch 961886

1шт.

4

K917749

FASTENER

- retaining spring 961886

1шт.

K11405

RIVET

- 1/8 x 3/8 in. (replaces, 961886 19785)

2шт.

K19945

WASHER - 1/8 in. 961886

2шт.

5

K902243

NO LONGER SERVICED

MOTIF - 961886

1шт.

6

K916776

SPRING

- retainer--motif 961886

1шт.

K914804

PLUG

- plastic, 3/8 in. 961886

4шт.

7

K914063

BEAD

- 961886

1шт.

K624151

RIVET

- 1/8 x 1/8 in. 961886

11шт.

8

K624914

SPRING

- 961886

2шт.

9

K88680

GRIP

- finger 961886

2шт.

10

K923669

NO LONGER SERVICED

STRIP - sealing, bonnet to radiator, 961886 (replaces 913201)

1шт.

11

K915203

STRIP

- clamping 961886

1шт.

K624153

RIVET

- 1/8 x 1/4 in. 961886

6шт.

12

K913139

BUTTON

- rubber 961886

2шт.

13

K921809

NO LONGER SERVICED

LOUVRE

1шт.

K916539

PLATE

- louvre side-mounted headlamps

1шт.

K915733

BUSHING

- retaining, louvre plate side-mounted headlamps

5шт.

14

K608125

STUD

- 5/16 UNC x 1 3/4 in. (replaces 608127)

1шт.

15

K913740

GROMMET

1шт.

K19471

WASHER

- 5/16 in.

1шт.

16

K607201

NUT

- wing, 5/16 UNC

1шт.

17

K914347

INSERT

- exhaust pipe aperture

1шт.

18

K914302

FENDER

- shell, left-hand, agricultural tractors

1шт.

18

K922120

FENDER LEFT HAND - fan, U.S.A. only, agricultural tractors

1шт.

19

K914247

FENDER

- shell, right-hand, agricultural tractors

1шт.

19

K922118

MUDGUARD - fan fender, right-hand U.S.A. only, agricultural tractors

1шт.

20

K603049

BOLT

- setscrew, 7/16 UNC x 7/8 in. fenders to axle, agricultural tractors

6шт.

K626344

WASHER, LOCK

WASHER - lock, spring, 7/16 in. fenders to axle, agricultural tractors

6шт.

21

K603139

SCREW

SETSCREW - 1/2 UNC x 7/8 in. fenders to axle, agricultural tractors

2шт.

K626345

LOCK WASHER

WASHER - lock, spring, 1/2 in. fenders to axle, agricultural tractors

2шт.

K626314

WASHER

- 7/16 in. fenders to axle, agricultural tractors

6шт.

22

K602733

SCREW

SETSCREW - 1/4 UNC x 5/8 in. fenders to platforms, agricultural tractors

3шт.

K607043

NUT

- 1/4 UNC fenders to platforms, agricultural tractors

3шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. fenders to platforms, agricultural tractors

3шт.

K19470

WASHER

- 1/4 in. fenders to platforms, agricultural tractors

3шт.

23

K907214

NO LONGER SERVICED

BRACKET - reflector, fenders--agricultural tractors

2шт.

K19930

GROMMET,3/8" ID x 5/8" Groove Dia

- mudguards, fenders--agricultural tractors

4шт.

K24589

GROMMET

- mudguards, fenders--agricultural tractors

1шт.

K66892

REFLECTOR

- red, fenders--agricultural tractors

2шт.

K624150

RIVET

- 3/16 x 1/4 in., fenders--agricultural tractors

2шт.

24

K972807

FRAME

- platform, right-hand four-wheel brakes, fenders--agricultural tractors

1шт.

24

K921689

FRAME

- platform, left-hand, fenders--agricultural tractors

1шт.

24

K913494

FRAME

- platform, right-hand, fenders--agricultural tractors

1шт.

K19930

GROMMET,3/8" ID x 5/8" Groove Dia

- fenders--agricultural tractors

2шт.

25

K603003

SCREW

SETSCREW - 7/16 UNC x 1 in. platforms to frame, fenders--agricultural tractors

9шт.

K19483

SPRING WASHER

- spring, 7/16 in. platforms to frame, fenders--agricultural tractors

9шт.

26

K915422

SUPPORT

- stirrup U.K. only, fenders--agricultural tractors

1шт.

27

K602736

SCREW

SETSCREW - 1/4 UNC x 7/8 in. U.K. only, fenders--agricultural tractors

2шт.

K607043

NUT

- 1/4 UNC U.K. only, fenders--agricultural tractors

2шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. U.K. only, fenders--agricultural tractors

2шт.

28

K915004

MIRROR

- driving, bracket, right-hand, fenders--agricultural tractors

1шт.

28

K926980

MIRROR

- driving, bracket, left-hand, U1308 (925830), fenders--agricultural tractors

1шт.

K915007

PLATE

BACKPLATE - U1308 (925830), fenders--agricultural tractors

1шт.

K612731

SCREW

SETSCREW - 1/4 UNF x 1/2 in. U1308 (925830), fenders--agricultural tractors

2шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. U1308 (925830), fenders--agricultural tractors

2шт.

29

K923910

FENDER

- full, left-hand 11-28 in. tyres, agricultural tractors

1шт.

29

K923909

FENDER

- full, right-hand 11-28 in. tyres, agricultural tractors

1шт.

K913952

SEAT

- rail--fender U1313 (925859), agricultural tractors

8шт.

K914525

CLAMP

- plate U1313 (925859), fenders--agricultural tractors

8шт.

K603880

BOLT

U-BOLT - 1/4 UNC U1313 (925859), fenders--agricultural tractors

8шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. U1313 (925859), fenders--agricultural tractors

16шт.

K607043

NUT

- 1/4 UNC U1313 (925859), fenders--agricultural tractors

16шт.

30

K923911

BLOCK

- packing piece, fenders--agricultural tractors

2шт.

K600889

BOLT

- 1/2 UNC x 3 3/4 in., fenders--agricultural tractors

6шт.

K603141

SCREW

SETSCREW - 1/2 UNC x 1 1/4 in., fenders--agricultural tractors

8шт.

K626345

LOCK WASHER

WASHER - lock, spring, 1/2 in., fenders--agricultural tractors

14шт.

31

K923914

FENDER

- support bracket, left-hand, agricultural tractors

1шт.

31

K923913

SUPPORT

- bracket, right-hand, fenders--agricultural tractors

1шт.

32

K924323

BRACKET

- extension, left-hand, fenders--agricultural tractors

1шт.

32

K924322

BRACKET

- extension, right-hand, fenders--agricultural tractors

1шт.

K602733

SCREW

SETSCREW - 1/4 UNC x 5/8 in. extension bracket to frame platform, fenders--agricultural tractors

4шт.

K607043

NUT

- 1/4 UNC extension bracket to frame platform, fenders--agricultural tractors

4шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. extension bracket to frame platform, fenders--agricultural tractors

4шт.

K603925

SCREW,Pan, 1/4" - 20 x 5/8"

SETSCREW - 1/4 UNC x 5/8 in. extension bracket to full fender, agricultural tractors

8шт.

K607043

NUT

- 1/4 UNC extension bracket to full fender, agricultural tractors

8шт.

K626341

SPRING WASHER

WASHER - lock, spring, 1/4 in. extension bracket to full fender, agricultural tractors

8шт.

K603141

SCREW

SETSCREW - 1/2 UNC x 1 1/4 in. full fender to rear axle case, agricultural tractors

4шт.

K626345

LOCK WASHER

WASHER - lock, spring, 1/2 in. full fender to rear axle case, agricultural tractors

4шт.

K627713

PLUG

- seat holes--left-hand full fender, agricultural tractors

9шт.

K627711

PLUG

- 17/32 in. dia., fenders--agricultural tractors

5шт.

K627712

PLUG

- 5/16 in. dia., fenders--agricultural tractors

1шт.

K627714

PLUG

- 5/32 in. dia., fenders--agricultural tractors

8шт.

K624090

RIVET

- 1/8 in. x 3/16 in.--lubrication plate to full fender, agricultural tractors

4шт.
