Запчасти Case IH 770A (098) - LAMP ASSEMBLIES (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 770A - (098) - LAMP ASSEMBLIES (06) - ELECTRICAL SYSTEMS
27
18
14
20
12
7
1
17
25
26
4
24
6
2
13
3
16
10
9
15
22
11
21
23
8
5
19

Артикул

Название

Примечание

Количество

K921082

LAMP

HEADLAMP - assembly (orchid white), l.h. (s/s 915865), 582001 onward

1шт.

K921083

LAMP

HEADLAMP - assembly (orchid white), r.h. (s/s 915866), 582001 onward

1шт.

K912015

NO LONGER SERVICED

HEADLAMP - assembly (red), left-hand, Serial Range: 580001-581999

1шт.

K912016

NO LONGER SERVICED

HEADLAMP - assembly (red), right-hand, Serial Range: 580001-581999

1шт.

1

K962349

BEZEL

- rim (orchid white) 921082 921083 912015 912016

1шт.

1

K961610

NO LONGER SERVICED

RIM - (red) 921082 921083 912015 912016

1шт.

2

K960879

BEZEL

- rim catch 921082 921083 912015 912016

1шт.

3

K960898

GASKET

- lens to rim 921082 921083 912015 912016

1шт.

4

K960892

LENS

- 921082 921083 912015 912016

1шт.

5

K960874

GASKET

- lens to reflector 921082 921083 912015 912016

1шт.

6

K960876

SPRING

- retainer 921082 921083 912015 912016

4шт.

7

K961615

NO LONGER SERVICED

REFLECTOR - 921082 921083 912015 912016

1шт.

8

K961611

NO LONGER SERVICED

PIECE - centre and contacts 921082 921083 912015 912016

1шт.

K960873

GROUND STRAP

STRAP - ground, lead--earth 921082 921083 912015 912016

1шт.

9

K960880

SCREW

- rim retaining 921082 921083 912015 912016

1шт.

10

K961612

HOUSING

- screw catch--rim retaining 921082 921083 912015 912016

1шт.

11

K961613

PEDESTAL

- 921082 921083 912015 912016

1шт.

12

K961614

NUT

- 9/16 in. 921082 921083 912015 912016

1шт.

K921081

LAMP

FLOODLAMP - rear (orchid white), 582001 onward (supersedes 914107)

1шт.

K913946

NO LONGER SERVICED

FLOODLAMP - rear assembly (red), Serial Range: 580001-581999

1шт.

13

K961080

NO LONGER SERVICED

SWITCH - 921081 913946

1шт.

K961082

NUT

- switch 921081 913946

1шт.

14

K961081

COVER ASSY

- rubber, switch 921081 913946

1шт.

15

K961616

NO LONGER SERVICED

PIECE - centre and contacts 921081 913946

1шт.

K961771

NO LONGER SERVICED

LEAD - feed 921081 913946

1шт.

1

K962349

BEZEL

RIM - (orchid white) 921081 913946

1шт.

1

K961610

NO LONGER SERVICED

RIM - (red) 921081 913946

1шт.

2

K960879

BEZEL

- rim catch 921081 913946

1шт.

3

K960898

GASKET

- lens to rim 921081 913946

1шт.

4

K962334

LENS

- (replaces 960892) 921081 913946

1шт.

5

K960874

GASKET

- lens to reflector 921081 913946

1шт.

6

K960876

SPRING

- retainer 921081 913946

4шт.

7

K961615

NO LONGER SERVICED

REFLECTOR - 921081 913946

1шт.

9

K960880

SCREW

- rim retaining 921081 913946

1шт.

10

K961612

HOUSING

- screw catch--rim retaining 921081 913946

1шт.

16

K910853

BRACKET - 921081 913946

1шт.

17

K603141

SCREW

SETSCREW - 1/2 UNC x 1 1/4 in. bracket to mudguard (replaces 603136), 921081 913946

1шт.

K627067

BUSHING

- distance piece bracket to mudguard 921081 913946

1шт.

K626510

WASHER

- shakeproof, 1/2 in. bracket to mudguard, 921081 913946

2шт.

280431

NUT,1/2"-13, G5

Bracket to mudguard 921081 913946 1/2"-13, G5

1шт.

18

K610050

BOLT

- 1/4 UNF x 2 1/4 in. 921081 913946

1шт.

K626552

WASHER

- shakeproof, 1/4 in. 921081 913946

2шт.

19

K912300

COLLAR

- distance piece 921081 913946

1шт.

K626704

WASHER - spring, 1/4 in.--double coil 921081 913946

1шт.

K607215

NUT

- wing, 1/4 UNF 921081 913946

1шт.

K921080

STOP LIGHT

LIGHT - stop, side/rear lamp (orchid white), left-hand (s/s 914109), 582001 onward

1шт.

K921079

LAMP

- side/rear (orchid white), right-hand (s/s 914108), 582001 onward

1шт.

K912396

NO LONGER SERVICED

LAMP - side/rear assembly (red), left-hand, Serial Range: 580001-581999

1шт.

K912395

NO LONGER SERVICED

LAMP - side/rear assembly (red), right-hand, Serial Range: 580001-581999

1шт.

20

K960887

LENS

- clear 921080 921079 912396 912395

1шт.

21

K960888

LENS

- red 921080 921079 912396 912395

1шт.

22

K960889

MOUNTING PARTS

- lens, black rubber 921080 921079 912396 912395

2шт.

23

K961772

BULB

- holder 921080 921079 912396 912395

1шт.

K961827

MOUNTING - rubber, bulb holder 921080 921079 912396 912395

1шт.

K915874

HEADLAMP

- assembly

2шт.

24

K962146

BEAM

- sealed unit, 12 volt, 40/40 watt, 915874

1шт.

25

K961759

MOUNTING PARTS

- rubber 915874

1шт.

K915141

LAMP

HEADLAMP - assembly

2шт.

24

K962145

BEAM

- sealed unit, 12 volt, 35 watt 915141

1шт.

25

K961759

MOUNTING PARTS

- rubber 915141

1шт.

26

K962345

KIT

- mounting (2 spire nuts, 2 screws, 2 springs and bracket)

2шт.

27

K604041

SCREW

- No. 8 UNC x 3/4 in.

4шт.

K607040

NUT

- No. 8 UNC

4шт.

K626340

RING

- spring washer, 3/16 in.

4шт.

Выбрано товаров: 64
