Артикул
Название
Примечание
Количество
1
242241A2
HYD TUBE,.5" OD, 450, 168 mm Length
1шт.
2
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Includes 3
2шт.
3
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
4
242243A4
HYD TUBE,.5" OD, 575, 217 mm Length
Supply
1шт.
5
328387A1
HYD TUBE
Differential
1шт.
6
218-5351
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
3/4 fl x 9/16 Or, Includes 7
1шт.
7
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
8
242242A3
HYD TUBE,.5" OD, 324.14, 40.71 mm Length
P.T.O.
1шт.
9
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Includes 3
1шт.
10
218-753
CAP,37 Degree, 1/2"-20
2WD
1шт.
11
244880A6
HYD TUBE,0.5" OD, 1002, 421.42 mm Length
Return
1шт.
11b
315890A1
HYD TUBE
Return, With Creep Speed
1шт.
12
246610A3
HYD TUBE,3" OD, 221.7, 124.3 mm Length
Lubrication
1шт.
13
218-980
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
Not Illustrated
1шт.
14
218-5057
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
Incl. 15
2шт.
15
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
16
240704A2
SUPPORT ASSY.
1шт.
17
240661A1
FIXING BRACKET
1шт.
18
844-8025
BOLT,Hvy Hex, M8 x 25mm, Cl 8.8
1шт.
19
242236A6
PIPE,1.25" OD, 522, 218 mm Length
Control Valve
1шт.
20
515-23317
CLAMP,31.75mm ID, 10.3mm Bolt Hole, P Type
1шт.
21
413-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
1шт.
22
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(13/32 x 13/16 x 1/16")
1шт.
23
425-106
NUT,3/8"-16, Cl 5
1шт.
24
278418A1
HOSE ASSY.
815 mm
1шт.
25
201-100
HYD CONNECTOR,9/16" - 18 Male ORFS x 7/16" - 20 Male ORB
9/16 fc x 7/16 Or, Includes 26,27
2шт.
26
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
28
258505A1
HYDRAULIC HOSE
1150 mm, Left, Brake
1шт.
29
231031A2
HOSE
510 mm, Right, Brake
1шт.
30
318793A2
HYD TUBE
4WD
1шт.
31
318794A1
PIPE,0.3125" OD, 473.62, 163.32 mm Length
4WD
1шт.
32
123627A1
FITTING
4WD
1шт.
33
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
4WD
1шт.
34
218-5229
ELBOW,90 Degree, 1/2"-20, 37 Degree x 1/2"-20, 37 Degree Fem Sw
1/2 fl x sw, 4WD
1шт.
35
218-5105
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
Includes 36
2шт.
36
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
37
225044A1
PIPE
1шт.
38
336233A1
PIPE
1шт.
39
218-5065
HYD CONNECTOR,1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
Includes 40
2шт.
40
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
41
218-5231
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
1шт.
42
224137A2
PIPE
Draft Control, Without Trailer Brake
1шт.
42
248275A2
HYD TUBE
Draft Control, With Trailer Brake, See Page(s) 7-13
1шт.
43
218-5107
90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB
7/8 fl x adj Or, Incl. 44
1шт.
44
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
45
218-5232
ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw
1шт.
46
218-5062
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
7/8 fl x Or, Includes 47
1шт.
47
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
48
224140A2
PIPE
Unloading
1шт.
49
258506A1
HYD TUBE,0.25" OD, 79.3, 69.1 mm Length
P.T.O.
1шт.
50
218-5103
90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB
7/16 fl x adj Or, Includes 51
1шт.
51
237-6004
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
52
218-5180
TEE,7/16" - 20 Male JIC x 7/16" - 20 Male JIC x 7/16" - 20 Male ORB
1/4 in, Includes 53
1шт.
53
237-6004
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
54
218-752
CAP,37 Degree, 7/16"-20
1шт.
55
218-5123
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
1-1/16 fl x 7/8 Or, Includes 56
1шт.
56
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
57
226915A1
HOSE
600 mm, Diff Lock
1шт.
58
224156A1
LARGE HOSE,9.52 mm ID x 650.00 mm, SAE 100R6 Class 3
HOSE,LARGE
1шт.
59
214-1506
HOSE CLAMP,11.18mm - 19.81mm
2шт.
60
217-387
FITTING,3/8" Hose Barb x 9/16" - 18 Male ORB
3/8 stem x 9/16 Or
1шт.
61
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
62
463-33812
SCREW,Hex Wash Hd, 3/8"-16 x 3/4"
3/8 x 3/4 in
2шт.
63
218-335
CAP,37 Degree, 1 1/16"-12
Without Auxiliary Valves
1шт.
65
313810A1
PIPE,88.9 mm Length
Without Auxiliary Valves
1шт.
66
66766C1
PLUG
Without Auxiliary Valves
1шт.
67
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
Without Auxiliary Valves
2шт.
68
315891A1
HYD TUBE
With Creep Speed
1шт.
69
318539A1
HYD TUBE,0.375" OD, 350, 120 mm Length
With Creep Speed
1шт.
64
238-6021
O-RING,15/16 X 1 - 1/16, Cl 6
Without Auxiliary Valves
1шт.
Выбрано товаров: 71
