Запчасти Case IH CX100 (08-19) - ASSISTOR RAM AND PIPES (08) - HYDRAULICS

Схема запчастей Case IH CX100 - (08-19) - ASSISTOR RAM AND PIPES (08) - HYDRAULICS
9
19
8
3
25
15
23
2
12
13
20
4
17
5
26
1
18
16
6
11
22
10
7
10
21
14
24
18a

Артикул

Название

Примечание

Количество

1

225289A1

SLEEVE

1шт.

2

496-21066

WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk

1шт.

3

326-1052

BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 8

1шт.

4

3129039R1

PLATE

1шт.

5

326-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 8

1шт.

6

235430A1

CYLINDER ASSY.

50 mm, See Page(s) 8-53

1шт.

7

218-5057

HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB

Incl. 8

1шт.

9

225165A3

PIN

1шт.

10

310995A1

ROCKER ARM

Left, With Assistor Ram

1шт.

10

310996A1

ROCKER ARM

Right, With Assistor Ram

1шт.

10

292068A1

ROCKER ARM

Without Assistor Ram

2шт.

11

838-3645

PIN,M6 x 45, Coiled

6 x 45 mm

1шт.

11

838-3840

PIN,8mm OD x 40mm L, Coiled

8 x 40 mm

2шт.

12

225045A2

HOSE

675 mm

1шт.

13

218-754

CAP,37 Degree, 9/16"-18

Without Assistor Ram

1шт.

14

248489A2

SUPPORT

1шт.

15

122756A3

POTENTIOMETER,1000 Ohm, 8V

1K, Serial No. JJE1015980, Position

1шт.

15

393795A1

POTENTIOMETER,1000 Ohm, 8V

Serial No. JJE1015981, Position

1шт.

16

893-11010

LOCK WASHER,Ext Tooth, M10

1шт.

17

192231A1

NUT

1/4 in

1шт.

18

291212A2

LEVER

1шт.

18b

878-2056

SET SCREW,M5 x 6mm

1шт.

19

291213A2

STEM

2шт.

20

131-889

PUSH-ON NUT,5/16", Push-on

1/8 in

2шт.

22

627-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd

2шт.

23

225163A1

PIN

2шт.

24

1331994C1

SPACER

2шт.

26

896-11008

WASHER,9mm ID x 17mm OD x 2mm Thk

9 x 17 x 2 mm

2шт.

25

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

2шт.

21

895-15008

WASHER,9mm ID x 20mm OD x 1.6mm Thk

2шт.

8

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

Выбрано товаров: 31
