Артикул
Название
Примечание
Количество
1
A66425
STRAP
ASSEMBLY - fuel tank mounting (Replaces A62055)
2шт.
2
95-6
WASHER,3/8"
- 7/16 x 1 x 5/64"
4шт.
3
25-106
NUT,3/8"-16, G5
- 3/8" NC hex
4шт.
4
A62055
STRAP
ASSEMBLY - fuel tank mounting (Order A66425)
4шт.
5
75-49
SCREW - 1/4 x 9/16" rd. hd.
2шт.
6
95-4
WASHER,1/4"
- 5/16 x 3/4 x 1/16"
2шт.
7
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
2шт.
8
25-104
NUT,1/4"-20, G5
2шт.
9
A66153
COVER
- fuel tank (without cab) (Replaces A59270)
1шт.
11
A64866
GUARD
MOLDING - fuel tank cover (Replaces A59498)
1шт.
13
195-104
WASHER,3/8"
- 7/16 x 1 x 3/32"
8шт.
15
A66664
COVER
- fuel tank (with cab) (Replaces A62681 and A66157)
1шт.
16
A39892
PLUG,33/64"
- 21/32" button
1шт.
17
113-209
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
8шт.
18
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
8шт.
19
113-102
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
- 5/16 x 3/8" NC hex
3шт.
20
92-5
LOCK WASHER,5/16"
3шт.
21
9635082
NUT,5/16" - 18, Gr 5
3шт.
22
113-286
BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd
- 3/8 x 3/4" NC hex
2шт.
23
195-81
WASHER
- 7/16 x 7/8 x 3/32"
2шт.
24
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, 3/8"-16, G5
2шт.
25
A62687
SHIM,.11" Thk
Cover .11" Thk
1шт.
Выбрано товаров: 23
