Артикул
Название
Примечание
Количество
1
A60207
VALVE
ASSY. - steering (See Figure 123)
1шт.
2
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
CONNECTOR Assy - 3/4" P.T.,1/2" tube, Incl. Ref 3
4шт.
4
A59928
TUBE - return, steering valve to tee (used w/o cooler)
1шт.
5
A60402
TUBE - upper, cooler to steering valve (used w/cooler)
1шт.
6
A60403
TUBE - lower, cooler to tee (used w/cooler)
1шт.
7
218-5242
TEE,3/4" - 16 Male JIC x 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
ASSY. - adjustable, 3/4" P.T., 1/2" tube, Includes: Ref. 8
1шт.
8
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
"O"-RING - 5/8 x 3/8 x 3/32"
1шт.
9
A60772
TUBE
- tee junction to trans. cover
1шт.
15
218-5351
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
CONNECTOR ASSY. - male, Includes: Ref. 16
1шт.
16
218-5005
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk
1шт.
17
A59904
TUBE
- pressure, relief valve to steering valve
1шт.
18
A59905
VALVE
ASSY. - steering system relief (See Figure 119)
1шт.
19
A59903
TUBE - pressure, filter to steering system relief valve
1шт.
20
218-5136
ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
ASSY. - 45 adjustable, Incl. Ref 21
1шт.
O
1шт.
22
G32017
FILTER
ASSY. - steering, power valve system (25 micron) (See Figure 119) (Replaces A60721)
1шт.
23
321-1763
DECAL
- "Warning" oil filter (red wrapper)
1шт.
24
A60857
CLAMP - hydraulic oil filter to bracket (Order A65004)
1шт.
25
A60854
BRACKET - mounting, oil filter
1шт.
26
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
2шт.
27
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
- 3/4 x 1-1/2" N.C. hex
2шт.
28
92-6
LOCK WASHER,3/8"
4шт.
29
25-106
NUT,3/8"-16, G5
- 3/8" N.C. hex
4шт.
34
49833
CLAMP
- oil filter, Serial Range: tubes-firewall
1шт.
35
13-410
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd
1шт.
37
95-4
WASHER,1/4"
- 5/16 x 3/4 x 1/16"
1шт.
38
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Assy, Adjustable, Includes: Ref. 39 90º, 3/4"-16, 37º x 3/4"-16, O-Ring
1шт.
40
A61860
HOSE
TUBE -, Serial Range: pump-filter
1шт.
41
HYD CONNECTOR,3/4" - 16 Male JIC x 7/8" - 14 Male ORB
Assy, 7/8" P.T., 1/2" tube, Incl. Ref, 42 3/4"-16, 37º x 7/8"-14, O-Ring
1шт.
43
REF
INSTRUCTION
PUMP ASSY. - hydraulic dual (See Figure 243)
1шт.
3
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
"O"-RING - 1/2 x 21/32 x 3/32"
1шт.
21
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
"O"-RING - 1/2 x 21/32 x 3/32"
1шт.
39
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
"O"-RING - 1/2 x 21/32 x 3/32"
1шт.
42
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
"O"-RING - 1/2 x 21/32 x 3/32"
1шт.
Выбрано товаров: 34
