Артикул
Название
Примечание
Количество
1
A59158
SUPPORT
- front end axle
1шт.
2
13-1240
BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5
Front end support Hex, 3/4"-10 x 2 1/2", G5
4шт.
3
A34651
LOCK WASHER
- lock (3/4" external teeth)
4шт.
5
A35216
COVER
PLUG - (2-1/4" diameter)
1шт.
6
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
1шт.
7
92-6
LOCK WASHER,3/8"
1шт.
8
195-25
WASHER,3/8"
- (13/32 x 13/16 x 5/64")
1шт.
9
A59660
SPACER
- front axle pivot pin
1шт.
10
A60568
PIN,31.67mm OD x 158.5mm L
- pivot, front axle
1шт.
15
B18131
WASHER,32.16mm ID x 55.63mm OD x 3.17mm Thk
- thrust, front axle pivot pin
2шт.
16
A62028
PACKAGE, REPAIR
SUPPORT ASSY. - front, axle pivot (Order A66039) (includes ref. 17)
1шт.
17
A59613
BUSHING,31.7mm ID x 38.18mm OD x 32mm L
- (1-1/4 x 1-1/2 x 1-1/4")
2шт.
18
13-1244
BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5
Supports to front end casting Hex, 3/4"-10 x 2 3/4", G5
8шт.
19
92-12
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
8шт.
20
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease (1/8" P.T., straight)
1шт.
21
A60592
AXLE ASSY. - center section (includes ref. 22 - 26)
1шт.
22
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease (1/8" P.T., straight)
1шт.
23
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
1шт.
24
A59660
SPACER
- pivot pin (13/32 x 9/16 x 9/32")
1шт.
25
195-25
WASHER,3/8"
- (13/32 x 13/16 x 5/64")
1шт.
26
A59628
PIN
- pivot, rear support
1шт.
31
A59614
SUPPORT
ASSY. - rear, axle pivot (includes ref. 32)
1шт.
32
A59615
BUSHING,31.81mm ID x 38.2mm OD x 38.3mm L
- (1-1/4 x 1-1/2 x 1-1/2")
1шт.
33
A62313
SHAFT
AXLE - end section (L.H.) (10 holes)
1шт.
33
A62312
SHAFT
AXLE - end section (R.H.) (10 holes)
1шт.
34
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease (1/8" P.T., straight)
2шт.
35
A64756
STEP BOLT
BOLT - shoulder, end section to center section (Replaced A59172)
4шт.
36
A65435
LOCK NUT
- flanged, two-way lock
4шт.
39
13-1224
BOLT,Hex, 3/4" - 10 x 1-1/2", Gr 5
Front wheel spindle Hex, 3/4"-10 x 1 1/2", G5
2шт.
40
A65598
WASHER
- front wheel spindle (Replaced A59653)
2шт.
41
A57323
ARM
- steering, front wheel (R.H.)
1шт.
41
A57322
ARM
- steering, front wheel (L.H.)
1шт.
45
A24639
SHIM,.1345" Thk
Spindle (#10 gauge) .1345" Thk
1шт.
45
A24642
SHIM,.0598" Thk
Spindle (#16 gauge) .0598" Thk
1шт.
45
A24643
SHIM,.0359" Thk
Spindle (#20 gauge) .0359" Thk
1шт.
45
A24645
SHIM,.0149" Thk
Spindle (#28 gauge) .0149" Thk
1шт.
46
A7849
GUARD
SHIELD - dust, spindle, upper
2шт.
47
A57273
OIL SEAL
- oil, spindle, upper (2 x 2-3/8 x 3/16")
2шт.
48
A28230
NEEDLE BEARING,Needle, 50.78mm ID x 60.34mm OD x 25.4mm W
BEARING - needle, spindle, lower & upper
4шт.
49
A27602
THRUST BEARING,2.041" ID x 2.9475" OD x 0.635"
BEARING - thrust, spindle, lower
2шт.
50
A62915
SPINDLE
- wheel (w/o groove on front wheel spindle) (See Inset) (1st Used Tractor Ser. No. 8693001)
2шт.
51
A62316
SPINDLE
- wheel (w/groove on front wheel spindle) (See Inset) (Used prior to tractor ser. no. 8693001) (Order 1-A62915 & 1-A62918)
2шт.
Выбрано товаров: 42
