(338) - COMPRESSOR CLUTCH

Запчасти Case IH 1175 (338) - COMPRESSOR CLUTCH (09) - CHASSIS

Схема запчастей Case IH 1175 - (338) - COMPRESSOR CLUTCH (09) - CHASSIS
16
26
2
27
25
20
24
15
3
23
15
19
20
28
22
11
5
7
21
12
14
29
6
4
9
8
28
17
13
10
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

A66057

CLUTCH

ASSY. - (Warner Electric #I-1436-14) (Replaces A64956), Includes: Ref. 2 - 6

1шт.

2

NSS

NOT SOLD SEPARAT

PULLEY ASSY. - rotor

1шт.

3

A44568

ELECTRIC CLUTCH

FIELD ASSY. - pulley

1шт.

4

121-3

SERRATED BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

4шт.

5

114-100

BOLT,Hex, 5/16" - 24 x 1-1/4", Gr 5

- 5/16 x 1-1/4" N.F. hex.

1шт.

6

A27343

BUSHING

SPACER - clutch attaching bolt

1шт.

A64956

CLUTCH

ASSY. - (Warner Elec. #I-1405-17) (Order A66057), Includes: Ref. 12 - 16

1шт.

12

NSS

NOT SOLD SEPARAT

PULLEY ASSY. - rotor

1шт.

13

A42941

COIL

FIELD ASSY. - pulley

1шт.

14

113-6

BOLT,Hex, 1/4" - 20 x 3/8", Gr 5, Full Thd

4шт.

15

114-100

BOLT,Hex, 5/16" - 24 x 1-1/4", Gr 5

- 5/16 x 1-1/4" N.F. hex.

1шт.

16

A27343

BUSHING

SPACER - clutch attaching bolt

1шт.
