Запчасти Case IH 1170 (236) - CAB, ACOUSTICAL COVERS, HINSON (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 1170 - (236) - CAB, ACOUSTICAL COVERS, HINSON (09) - CHASSIS/ATTACHMENTS
4
5
6
2
3
1

Артикул

Название

Примечание

Количество

1

A42537

COVER

- headliner

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

2

A42602

COVER

- fender panel, R.H.

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

3

A42603

COVER - fender panel, L.H.

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

4

A61141

PROTECTIVE COVER

COVER - console

1шт.

5

A61142

COVER

- fuel tank

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

6

A42536

FILLER - corner, filler

2шт.

To Be Attached With Adhesive 345 - 22

1шт.

Выбрано товаров: 11
