(234) - CAB, ACOUSTICAL COVERS, BETTENDORF

Запчасти Case IH 1170 (234) - CAB, ACOUSTICAL COVERS, BETTENDORF (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 1170 - (234) - CAB, ACOUSTICAL COVERS, BETTENDORF (09) - CHASSIS/ATTACHMENTS
2
6
3
1
4
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

F63326

PROTECTIVE COVER

COVER - headliner

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

2

F63296

PROTECTIVE COVER

COVER - fender panel , R.H.

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

3

F63295

COVER

- fender panel, L.H.

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

4

A61141

PROTECTIVE COVER

COVER - console

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

5

A61142

COVER

- fuel tank

1шт.

To Be Attached With Adhesive 345 - 22

1шт.

6

F63195

COVER

- corner filler

2шт.

To Be Attached With Adhesive 345 - 22

1шт.
