Артикул
Название
Примечание
Количество
1
A62210
PLUG
CAP - steering wheel lock knob
1шт.
2
D26115
O-RING,0.139" Thk x 2.109" ID, -227, Cl 5, 75 Duro
RING - retaining, medallion (2-1/8 x 2-3/8 x 1/8")
1шт.
3
25-146
JAM NUT,Jam, 3/8"-16, G5
- knob to shaft, 3/8" N.C. hex., jam
1шт.
4
A61293
KNOB
- steering wheel lock
1шт.
5
A14567
JAM NUT
- steering wheel to shaft (13/16" N.F. hex.)
1шт.
6
A65544
STEERING WHEEL
1шт.
7
A61292
SHAFT
- lock, telescoping
1шт.
8
A61212
WEDGE
- telescoping lock
4шт.
9
A59819
NUT
COLLAR - lock wedge (5/16" N.C. tapped hole)
1шт.
10
A59812
SHAFT - steering, outer
1шт.
11
A60896
RING, SNAP
RING - snap, lock wedge retainer
1шт.
15
A59821
PIN
- lock, shaft guide
1шт.
17
138-173
LOCK PIN,3/8" x 1 3/8", Slotted
PIN, 3/8" x 1 3/8", Slotted
1шт.
A61737
COLUMN ASSY. - steering, Includes Ref: 18 - 21
1шт.
18
NSS
NOT SOLD SEPARAT
COLUMN - steering (Order A61737)
1шт.
19
A59808
BEARING
- steering column
1шт.
20
A59809
BUSHING,12.8mm ID x 15.93mm OD x 25.4mm L
- steering column pivot stud
2шт.
21
A61736
WIPER SEAL
- wiper, steering column
1шт.
22
A61910
BOOT
- steering column
1шт.
23
A59842
BUMPER
SNUBBER - steering column pivot
2шт.
24
A59163
STUD
- pivot, 5/8" N.C. thrd.
2шт.
25
425-1410
JAM NUT,Jam, 5/8"-11, G5
- 5/8" N.C. hex., jam
4шт.
30
A59822
SUPPORT - tilt steering plunger
1шт.
31
13-510
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5, Full Thd
3шт.
32
92-5
LOCK WASHER,5/16"
3шт.
33
95-5
WASHER,3/8" x 7/8" x .083"
- 3/8 x 7/8 x 5/64"
1шт.
34
113-129
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5, Full Thd
- 5/16 x 1-1/4" N.C. hex.
1шт.
35
25-145
JAM NUT,Jam, 5/16"-18, G5
- 5/16" N.C. hex., jam
1шт.
36
A61739
PLUNGER
- tilt steering
1шт.
37
138-61
LOCK PIN,1/8" x 1", Slotted
PIN, 1/8" x 1", Slotted
1шт.
38
A59843
PIN - tilt plunger to lever link
2шт.
39
A59830
LINK -, Serial Range: plunger-lever
2шт.
40
132-5
COTTER PIN,1/16" x 1/2"
Pin, Split (Cotter), 1/16" x 1/2"
2шт.
41
A59835
CLIP - tilt plunger tension spring
1шт.
46
A30707
SPRING
- tension, 2-3/16" free length
1шт.
47
A59831
BOLT - pivot, 5/16" N.C. hex., shoulder
1шт.
48
A60719
LEVER - tilt
1шт.
49
A61683
BUTTON
KNOB - tilt lever
1шт.
50
A59832
WASHER - spring, 7/16 x 39/64 x 3/64"
1шт.
51
25-145
JAM NUT,Jam, 5/16"-18, G5
- 5/16" N.C. hex., jam
1шт.
52
92-5
LOCK WASHER,5/16"
1шт.
53
A62319
PUMP ASSY. - steering hand (See Fig. 106)(12:1 ratio)
1шт.
56
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
"O" RING - 1/2 x 21/32 x 3/32"
1шт.
53
A60202
PUMP ASSY. - steering hand (See Fig. 108)(18:1 ratio)
1шт.
54
166-26
12 PT SCREW,Flg, 5/16" - 18 x 1", Gr 8
SCREW - 5/16 x 1" N.C. cap
4шт.
55
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
CONNECTOR, HYD., , Assy, Pump to hose, Incl. Ref 56 3/4"-16, 37º x 3/4"-16, O-Ring
2шт.
Выбрано товаров: 47
