Запчасти Case IH 1070 (0502) - CONTROL CONSOLE, 1ST USED TRACTOR SERIAL NUMBER 8693001 (09) - CHASSIS/ATTACHMENTS

1

A64582

CONSOLE ASSY - control

1шт.

2

A64558

COVER

- control console (w/Power Shift) (Includes decal)

1шт.

See figure 548 for decal kit

1шт.

3

A64559

COVER

- control console (w/Mechanical Shift) (Includes decal)

1шт.

See figure 548 for decal kit

1шт.

4

113-1

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

6шт.

5

13-614

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd

1шт.

5

13-630

BOLT,Hex, 3/8" - 16 x 1-7/8", Gr 5

- 3/8 x 1-7/8" NC hex

1шт.

6

13-648

BOLT,Hex, 3/8" - 16 x 3", Gr 5

- 3/8 x 3" NC hex

1шт.

7

193-46

LOCK WASHER,Ext-Int Tooth, 3/8"

WASHER - Shakeproof, 3/8" internal/external

3шт.

8

92-6

LOCK WASHER,3/8"

1шт.

9

25-106

NUT,3/8"-16, G5

- 3/8" NC hex

3шт.

10

A59994

SPACER

- DOM sensing & PTO (See Insets)

1шт.

11

A27785

CIRCLIP,#62, .480" Dia, E-Type

Ring, Retaining, , spacer retainer (see insets) #62, .480" Dia, E-Type

1шт.

12

A65472

SPACER

- console (Replaces T32627)

1шт.
