Артикул
Название
Примечание
Количество
1
60-7274T1
HARNESS
- electronic depth control
1шт.
2
60-7222T1
GAUGE ASSY.
GAUGE - display, seven segment
1шт.
3
60-6120T1
LARGE PLATE
PLATE - mounting, controller
1шт.
4
495-11034
WASHER,5/16", SAE
5/16" SAE (flat, 11/32 x 11/16 x 1/16")
3шт.
5
231-1445
NUT,5/16"-18, GB
NUT - hex, self-locking, 5/16 inch NC
7шт.
6
60-7281T2
KIT
CONTROLLER - three point hitch, electronic
1шт.
7
495-11028
WASHER,1/4", SAE
(flat, 9/32 x 5/8 x 1/16") 1/4", SAE
2шт.
8
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC
2шт.
9
A186061
POTENTIOMETER,10,000 Ohm, 8V
Electrical 10,000 Ohm, 8V
1шт.
10
425-106
NUT,3/8"-16, Cl 5
P.I.N JEE0069308 and after 3/8"-16, G5
2шт.
11
60-7018T1
IGNITION SWITCH
SWITCH - rocker
1шт.
12
1964672C1
LIGHT
- indicator, amber, 14 volt
1шт.
14
246245A1
VALVE
ASSEMBLY - control, three point hitch, parts list Figure 8-96
1шт.
15
163-55
SCREW,Hex, #10 - 24 x 1 1/4", Gr 5
- machine, hex head, No. 10 NC x 1-1/4 inch
2шт.
16
22-823
MOUNT
MOUNT - adhesive back, strap
2шт.
17
22-824
CABLE TIE,3/16" x 7 1/4"
STRAP - tie, 7 inch
1шт.
18
60-6066T1
FOAM
SEAL - foam
2шт.
19
60-6065T1
ANGLE BAR
ANGLE - retaining, foam
2шт.
20
90-7749T1
SPACER
Joint
2шт.
21
122756A3
POTENTIOMETER,1000 Ohm, 8V
Single, 1K 1000 Ohm, 8V
1шт.
23
495-31022
WASHER,#10
2шт.
60-7019T1
IGNITION SWITCH
SWITCH ASSEMBLY - toggle, Includes: Ref. 24 & 25
1шт.
24
60-7016T2
HARNESS
- three point hitch
1шт.
25
60-7167T1
HARNESS
- switch, three point hitch
2шт.
26
60-7039T1
IGNITION SWITCH
SWITCH - toggle, three point hitch
2шт.
60-7280T91
HOUSING
Potentiometer, P.I.N. JEE0069308 and After, See Figure 4-78 for Prior to P.I.N. JEE0069308, Includes: Ref. 30 - 47
1шт.
30
19-5860
SNAP RING,#75, Ext
Ring, Snap, #75, Ext
1шт.
31
60-6186T1
SUPPORT
Mount, Potentiometer
1шт.
32
122756A3
POTENTIOMETER,1000 Ohm, 8V
Single, 1K, Raise and Lower 1000 Ohm, 8V
1шт.
33
31-2475
GROMMET
- wire
1шт.
34
60-6177T1
BALL BEARING,0.7874" ID x 1.8504" OD x 0.5512"
BEARING - ball
2шт.
35
60-6167T3
BEARING HOUSING,1.654" ID x 3.25" OD x 2.928"
Housing, Potentiometer
1шт.
36
60-6169T2
RETAINER
Housing
1шт.
37
495-11028
WASHER,1/4", SAE
(flat, 9/32 x 5/8 x 1/16") 1/4", SAE
2шт.
38
493-21026
LOCK WASHER,Int Tooth, 1/4"
WASHER - internal tooth lock, 1/4 inch
2шт.
39
425-106
NUT,3/8"-16, Cl 5
2шт.
40
60-7159T2
LEVER
- actuating
1шт.
41
H433283
BALL JOINT
JOINT - ball, linkage
2шт.
43
86625057
NUT,#10-24, GB
NUT, LOCK, #10-24, GB
2шт.
45
60-6175T1
TRUSS ROD
ROD - actuating
1шт.
46
60-6185T1
LARGE PLATE
PLATE - mounting, housing
1шт.
47
60-7277T1
BRACKET
Mount, Potentiometer Assembly
1шт.
48
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(Flat, 13/32 x 13/16 x 1/16") 3/8", SAE
2шт.
49
426-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 8
- hex, 3/8 NC x 1-1/2 inch, grade 8
2шт.
Выбрано товаров: 45
