Артикул
Название
Примечание
Количество
35-1753T91
VALVE
KIT - valve, priority remote, no longer available, order component parts separately, Includes: Ref. 1 - 38 and 42 - 77 o Fig. 8-84
1шт.
2-3792T1
SEAL KIT
- seal, valve section, Includes: Ref. 1 - 4
1шт.
1
238-6211
O-RING,0.139" Thk x 0.796" ID, -211, Cl 6, 90 Duro
1шт.
2
238-5119
O-RING,0.103" Thk x 0.924" ID, -119, Cl 5, 75 Duro
1шт.
3
238-6214
O-RING,0.139" Thk x 0.984" ID, -214, Cl 6, 90 Duro
2шт.
4
D77566
SHIM,.0030" Thk
Sections, Control valve .0030" Thk
3шт.
1986840C1
VALVE
ASSEMBLY - remote control, with load check, replaces A52404 valve assembly, Includes: Ref. 5 - 38
1шт.
5
NSS
NOT SOLD SEPARAT
BODY - valve
1шт.
6
NSS
NOT SOLD SEPARAT
SPOOL - valve
1шт.
7
A47105
PLUG
- expansion
1шт.
8
238-5116
O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro
2шт.
9
A47205
SEAL,22.61mm ID x 32.13mm OD x 2.67mm Thk
FILTER - spool
1шт.
10
A47188
COVER
- dust
1шт.
11
86019274
SCREW,Hex, 1/4"-20 x 1/2", G5
- retainer
2шт.
12
A47196
RETAINER
- dust guard
1шт.
13
A48925
PLUG
- flow control
1шт.
14
A48929
SHAFT
- adjusting
1шт.
15
A52412
TUBE
- flow control
1шт.
16
A52411
PISTON
SPOOL - flow control
1шт.
17
19711R1
PIN,3.17mm OD x 31.75mm L, Coiled
1шт.
18
138-1816
LOCK PIN,1/8" x 1", Slotted, Stainless
Pin, 1/8" x 1, Slotted, Stainless
1шт.
19
D71056
RING,Split, 4.47mm ID x 7.21mm OD x 1.32mm Thk
- backup
1шт.
20
238-5008
O-RING,0.07" Thk x 0.18" ID, -8, Cl 5, 75 Duro
-008, 70 Duro, .176" ID x .070" Thk
1шт.
21
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk
1шт.
22
A48959
SPRING
- outer, flow control
1шт.
23
A48960
SPRING
- inner, flow control
1шт.
24
A52410
PIN
- spring guide
1шт.
28
A47204
PLUG
BODY - shuttle
1шт.
29
238-6008
O-RING,0.07" Thk x 0.176" ID, -8, Cl 6, 90 Duro
1шт.
30
237-6003
O-RING,0.064" Thk x 0.301" ID, -903, Cl 6, 90 Duro
3-1, .301" ID x .064" Thk
1шт.
31
211-1006
BALL,3/16" Dia
- chrome alloy steel, 3/16 inch, grade 24
1шт.
32
A47209
SPOOL
SHUTTLE ASSEMBLY - primary, Includes: Ref. 34 - 38
1шт.
35
238-6010
O-RING,0.07" Thk x 0.239" ID, -10, Cl 6, 90 Duro
1шт.
36
238-6009
O-RING,0.07" Thk x 0.208" ID, -9, Cl 6, 90 Duro
1шт.
A52421
PLUG
- expansion, not shown
1шт.
38
A52422
VALVE
CHECK ASSEMBLY - load, remote valve, parts list Figure 8-86, continued
1шт.
34
237-6004
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
4-1, 90 Duro, .351" ID x .072" Thk
1шт.
Выбрано товаров: 37
