Артикул
Название
Примечание
Количество
1
70-6341T92
FRAME
MOUNT ASSEMBLY - lower link, Includes: Ref. 2
1шт.
2
90-6971T2
SPACER
BEARING - inner race
4шт.
5
426-1440
BOLT,Hex, 7/8" - 9 x 2-1/2", Gr 8
- hex, 7/8 NC x 2-1/2 inch, grade 8
10шт.
6
496-11094
WASHER,0.94" ID x 1.75" OD x 0.13" Thk
- flat, 15/16 x 1-3/4 x 1/8 inch, hardened
20шт.
7
425-1014
NUT,7/8"-9, G5
NUT, 7/8"-9, G5
10шт.
8
70-6466T1
ARM
- lower link, draft
2шт.
9
70-5501T1
PIN
- draft arm
2шт.
10
70-3082T2
LARGE PLATE
BLOCK - pin retaining
2шт.
11
426-816
BOLT,Hex, 1/2" - 13 x 1", Gr 8
- hex, 1/2 NC x 1 inch, grade 8
4шт.
17
70-6513T1
LARGE PLATE
PLATE - wear
2шт.
18
426-836
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 8
- hex, 1/2 NC x 2-1/4 inch, grade 8
4шт.
19
70-5973T2
PIN
- upper
2шт.
20
70-5721T1
LARGE PLATE
PLATE - wear, left-hand
2шт.
20
70-5720T1
LARGE PLATE
PLATE - wear, right-hand, not shown
2шт.
26
426-1020
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 8
- hex, 5/8 NC x 1-1/4 inch, grade 8
3шт.
27
495-11066
WASHER,5/8", SAE
- flat, 21/32 x 1-5/16 x 3/32 inch
2шт.
28
70-5967T1
SPACER,16.7mm ID x 22.2mm OD x 11.2mm
- pin
2шт.
32
70-1735T1
PIN
- drawbar pull
1шт.
33
70-1731T1
PIN
- drawbar retaining
1шт.
34
19-1041
LOCK PIN,7/16" x 2"
PIN - klik, locking
2шт.
35
70-5667T2
PIN
- drawbar
2шт.
36
517758R91
SPLIT PIN/SAFETY PIN
PIN - klik, locking
2шт.
37
70-6355T1
CONDUIT
CHANNEL - drawbar
1шт.
38
496-21066
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
- flat, 21/32 x 1-5/16 x 5/32 inch, hardened
8шт.
39
426-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 8
- hex, 5/8 NC x 2 inch, grade 8
8шт.
40
70-5797T1
PIN
- retainer, drawbar channel
1шт.
44
70-6913T1
DRAWBAR
- extendable
1шт.
For tractors with PTO assemblies, Ref. 45, 46 and 47 are mounted below Ref. 44.
1шт.
P/N 70-6913T1, is a heat-treated drawbar. See NTR SB 017 98 for more information.
1шт.
45
70-6265T1
LARGE PLATE
PLATE - hammerstrap
1шт.
46
70-6264T2
LARGE PLATE
BLOCK - spacer, 1-1/2 inch thick
2шт.
47
70-6263T2
LARGE PLATE
PLATE - spacer block
1шт.
48
70-6249T1
LATCH
- mount, machined
1шт.
49
90-7494T1
SCREW,#0 - 8 x 9 1/4""
BOLT - hex, special, 1 NC x 9-1/4 inch
2шт.
50
425-1016
NUT,1"-8, G5
- hex, 1 inch NC
2шт.
54
1965315C2
LEVER
- hammerstrap
1шт.
55
527-204
CLEVIS PIN,M12 x 43
PIN - clevis, 10 x 43 mm
1шт.
56
432-816
COTTER PIN,1/8" x 1"
1/8" x 1"
1шт.
Выбрано товаров: 38
