Запчасти Case IH 6788 (10-20) - HYDRAULICS, RESERVOIR AND FILTER (07) - HYDRAULICS

Схема запчастей Case IH 6788 - (10-20) - HYDRAULICS, RESERVOIR AND FILTER (07) - HYDRAULICS
9
12
19
14
18
17
16
6
13
8
3
10
11
4
12
5
1
15
2
7

Артикул

Название

Примечание

Количество

1

22278R1

O-RING,0.103" Thk x 1.674" ID, -131, Cl 5, 75 Duro

1-11/16 x 1-7/8 x 3/32

1шт.

2

382257R2

GASKET

oil filter cover

1шт.

3

138170C1

FRAME

ASSY, filter

1шт.

NLS

NO LONGER SERVICED

8шт.

4

285253R1

O-RING,0.139" Thk x 5.484" ID, -254, Cl 5, 75 Duro

5-1/2 x 5-3/4 x 1/8 filter frame

1шт.

5

9410358

PLUG

9/16-18 hyd str-th o-ring boss

1шт.

6

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, 15/32 OD tube

1шт.

7

133685C2

MANIFOLD

suction line

1шт.

8

293726R1

O-RING,0.139" Thk x 2.234" ID, -228, Cl 5, 75 Duro

2-1/4 ID x 1/8

1шт.

9

133686C1

SUPPORT

suction line manifold

1шт.

10

133728C1

RETAINER

filter cartridge

1шт.

11

142785C91

VALVE

ASSY, by-pass

1шт.

12

133736C1

FILTER, ELEMENT

ELEMENT, filter

2шт.

12

1263437C1

FILTER, ELEMENT

ELEMENT, 3 inch filter, For clean-up use only, See service manual

2шт.

13

FRAME ASSY, rear, Refer to rear frame, covers and connections listing group 7

1шт.

14

142847C1

HOSE

suction

1шт.

15

301016R1

O-RING,0.118" Thk x 1.720" ID, -924, Cl 6, 90 Duro

1-1/2 OD tube

1шт.

16

145462C1

COVER

filter frame

1шт.

480288C1

STUD

2шт.

120376

NUT,5/16"-18, G5

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

17

290045R1

FLANGE

split

2шт.

17427R1

BOLT, 7/16 x 1 pln type 1

4шт.

18

382243R1

COVER ASSY

COVER, pump opening

1шт.

179838

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd

3/8 x 7/8 pln type 5

12шт.

179839

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

19

382244R4

GASKET

pump opening cover

1шт.

Выбрано товаров: 27
