Запчасти Case IH 6588 (08-26) - ELECTRICAL, CRANKING MOTOR, DELCO-REMY, HEAVY DUTY SEALED, ILLUSTRATION NOT AVAILABLE (06) - ELECTRICAL

1990322

MOTOR, ELECTRIC

MOTOR CRANKING, 245346C91, Replaces 1113489

1шт.

1985315

FRAME

commutator end, Consists of

1шт.

1955994

BUSHING

1шт.

1985247

WICK

oil reservoir

1шт.

1985246

CUP

oil reservoir

1шт.

1985333

SCREW

& WASHER, commutator frame

1шт.

1985303

PLATE

BRUSH PLATE ASSY, Consists of

1шт.

1985889

BRUSH

4шт.

1985314

SPRING

brush

4шт.

1985712

SCREW

brush att

4шт.

1985713

INSULATOR

conductor

1шт.

1985714

CABLE

CONDUCTOR

1шт.

453661

SCREW

brush plate

2шт.

1985248

INSULATOR

brush plate

2шт.

1968998

SCREW

field coil lead to brush holder

2шт.

1986361

FIELD COIL ASSY, (4 coils)

1шт.

1914873

INSULATOR

field coils

2шт.

1985318

GROMMET

field coil

1шт.

1986367

SHOE

POLE SHOE

4шт.

1968396

SCREW

pole shoe

8шт.

1985320

RING,0.103" Thk x 4.737" ID, -158, Cl 5, 75 Duro

O-RING, on motor frame

1шт.

1985617

WASHER

thrust

1шт.

1986374

ARMATURE

1шт.

1965947

SPACER

between armature & lever hsg

1шт.

1985335

HOUSING

LEVER HOUSING ASSY, Consists of

1шт.

1985234

BUSHING

lever hsg

1шт.

1985247

WICK

oil reservoir

1шт.

1985246

CUP

oil reservoir

1шт.

1937718

SEAL

oil

1шт.

1985235

WASHER

brake

1шт.

1985304

O-RING

between housing & lever

1шт.

1916272

O-RING

between lever hsg & frame

1шт.

1945356

PLUG

inspection, lever hsg

1шт.

1964857

GASKET

inspection plug, lever hsg

1шт.

1914869

SCREW

lever housing

5шт.

1985237

LEVER

SHIFT LEVER ASSY

1шт.

1948529

SHAFT

shift lever

1шт.

1894642

RING

O-RING, shift lever shaft (3/8 OD)

1шт.

1894643

O-RING

shift lever shaft (1/2 OD)

1шт.

9416374

RING

retaining, shift lever shaft

1шт.

1986368

DRIVE

MOTOR, drive

1шт.

1851960

O-RING

between dr hsg & lever hsg

1шт.

1986351

HOUSING

drive end, Consists of

1шт.

1955994

BUSHING

1шт.

1985247

WICK

oil reservoir

1шт.

1985246

CUP

oil reservoir

1шт.

1948537

SCREW

drive housing

6шт.

1985982

STOP

pinion

1шт.

1986928

RING

retaining, pinion stop

1шт.

280136

NUT,3/8"-16, G8

Field coil connect to switch 3/8"-16, G8

1шт.

1987678

CLIP

field coil, Serial Range: connect-switch

1шт.

1115589

SOLENOID SWITCH

1шт.

1985332

SCREW

& WASHER, switch

3шт.

1985240

PLUNGER

solenoid

1шт.

1948519

WASHER

plunger assy

1шт.

1985243

BOOT

plunger

1шт.

1948520

RETAINER

plunger spring

1шт.

1948521

SPRING

plunger

1шт.

1948526

RETAINER

plunger spring

1шт.

9416374

RING

retaining, plunger assy

1шт.

9412305

NUT

plunger rod guide adjusting

1шт.
