Артикул
Название
Примечание
Количество
1
G35514
CYLINDER
ASSEMBLY - front steering, Includes: Ref. 2 - 19
2шт.
2
G34039
ROD
ASSEMBLY - piston 15-1/2" (393.7 MM) Long, Includes: Ref. 3
1шт.
3
G32050
BUSHING,25.63mm ID x 31.85mm OD x 15.75mm L
- rod eye
2шт.
4
D23649
SNAP RING,2.625", Int, #262
Ring Snap, , gland 2.625", Int, #262
1шт.
G35381
GLAND
ASSEMBLY - cylinder, Includes: Ref. 5 - 10
1шт.
5
G33955
WIPER SEAL,25.37mm ID x 38.13mm OD x 7.92mm Thk
SCRAPER - rod
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
6
G35372
SEAL
- rod, 1" ID x 1-1/4" OD x 1/4" wide (25.4 x 31.8 x 6.4 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
8
G33953
BACK-UP RING,2.407" ID
RING - backup, 2-13/32" (61.1 MM) ID
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
9
A29884
O-RING,0.139" Thk x 2.359" ID, -229, Cl 5, 75 Duro
- 2-3/8 x 2-5/8 x 1/8" (60.3 x 66.7 x 3.2 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
10
NSS
NOT SOLD SEPARAT
GLAND - cylinder (Order G35381)
1шт.
11
G34872
RING
- retaining, wire
1шт.
12
G100714
RING
- wear, piston, 2-1/2 x 2-3/4 x 3/8" (63.5 x 70 x 9.5 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
13
R15365
O-RING,0.989" ID x 1.129" OD x 0.07"
- rod seal, 1 x 1-1/8 x 1/16" (25.4 x 31.8 x 1.2 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
14
F62076
O-RING,0.139" Thk x 1.984" ID, -226, Cl 5, 75 Duro
- piston, 2 x 2-1/4 x 1/8" (50.8 x 57.2 x 3.2 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
15
G33140
RING,59.68mm ID x 64.26mm OD x 3.94mm Thk
- seal, 2-17/32 x 2-23/32 x 5/32" (64.3 x 69.1 x 4 MM)
1шт.
Part of cylinder seal kit, P/N G35382
1шт.
16
G35510
PISTON
- cylinder
1шт.
17
G35009
WASHER
- 17/32 x 1-1/16 x 7/64" (13.5 x 27 x 2.8 MM)
1шт.
18
28-824
BOLT,Hex, 1/2" - 20 x 1-1/2", Gr 8
- 1/2 x 1-1/2 x 1-1/2" NC hex. (Grade 8)
1шт.
19
G35515
TUBE,18.20" L
- cylinder
1шт.
G35382
KIT
- cylinder seal, Includes: ref. nos. 5, 6, 8, 9, 12, 13, 14, 15
1шт.
Выбрано товаров: 28
