Запчасти Case IH 4568 (02-02) - MISCELLANEOUS, SERVICE PACKAGES Accessories & Attachments / Miscellaneous

69924C92

SEAL KIT

PACKAGE, axle overhaul, o-ring, Consists of

2шт.

297459R1

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

7/8 OD tube, oil level and fill plug

2шт.

296247R1

O-RING,16-1, 90 Duro, 1.171" ID x .116" Thk

1 in. OD tube, front axle below

1шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk, 1/4 OD tube, Front axle oil level plug

1шт.

530789R1

O-RING,6.712" ID x 0.139" Width

O-RING, bull pinion brg & oil seal. ret.

2шт.

3061207R1

O-RING,0.139" Thk x 6.234" ID, -259, Cl 5, 75 Duro

6-1/4 x 6-1/2 x 1/8, pinion shaft cage

1шт.

382432R1

O-RING,1.984" ID x 0.139" Width

2 x 2-1/4 x 1/8, suction tube

1шт.

368269R1

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

3/4 OD tube, front axle elbow, small

1шт.

301016R1

O-RING,0.118" Thk x 1.720" ID, -924, Cl 6, 90 Duro

1-1/2 in. OD tube, front axle elbow, large

2шт.

400223C91

GASKET

PACKAGE, transmission gasket service, Consists of

1шт.

399614C1

GASKET

dr gear brg cap

1шт.

399615C1

GASKET

mainshaft rear brg cap

1шт.

399616C2

GASKET

cntrshft rear brg cap

2шт.

10705V

GASKET

PTO aperture cover

1шт.

343368C1

GASKET

PTO aperture

1шт.

399613C1

GASKET

clutch hsg

1шт.

399617C1

GASKET

shifter hsg

1шт.

697881R1

GASKET

shifter lever hsg

1шт.

983897R1

GASKET, remote cover

1шт.

432242C1

GASKET

shift cyl hsg

1шт.

138735C1

GASKET, shift cyl cap

1шт.

522399C1

GASKET, control lever hsg

1шт.

688292C91

PACKAGE

engine coolant heater, Consists of

1шт.

HEATER (NSS)

1шт.

71150C1

CABLE

CORD, engine coolant heater

1шт.

INSTRUCTIONS (NSS)

1шт.
